Intellian Intelligent Mediator Installation And Operation User Manual page 12

Intelligent Mediator – Marine Satellite Communication System
Tri-band Antenna System with Single Data Center
Antenna 1
Power Box
AC 100~240V
ACU 1 Fiber Cable
TX
AC 100~240V
Intelligent Mediator
AC 100~240V
RX
C-band Modem
(Not supplied)
AC 100~240V
12
Antenna 2
Fiber Link Power Box
ACU 2 Fiber Cable
Rx TX
Ethernet
TX Console(Optional) RX
Ku-band Modem
(Not supplied)
LAN
Antenna 3
Fiber Link Power Box
ACU 3 Fiber Cable
Rx TX
Ethernet
RX2
TX Console(Optional) RX1
Ka-band Modem
(Not supplied)
LAN
Single Data Center
Fiber Link
Rx
Ethernet
Router
(Not supplied)
TX
M&C Server
(Not supplied)
LAN
Above Decks
Below Decks
Ship's
Gyrocompass
(Not supplied)
PC
(Not supplied)
