MAG TOOLS A Series Operating Instructions & Parts Manual

Long chassis service jack w/air, capacity 10 ton
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Operating Instructions & Parts Manual
Model Number
JSA1000AH
Series A
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
!
ADVERTENCIA
• Leer, comprender, y seguir las instrucciónes antes
de utilizar el aparato.
• El manual de instrucciónes y la información de
seguridad deben estar comunicado en lengua del
operador antes del uso.
• No seguir estas indicaciónes puede causar daños
personales o materiales.
Long Chassis Service
U.S. Patent No's. 5,946,912 • 5,341,723
MAC TOOLS
505 N. Cleveland Ave., Suite 200
Westerville, OH 43082
a division of Stanley Black & Decker
Jack w/Air
Capacity
10 Ton
!
WARNING
To avoid crushing and related injuries:
NEVER work on, under or around a
load supported only by a hydraulic
jack. ALWAYS use a matched pair of
adequately rated jack stands.
Printed in PRC
JSA1000AH-M0_092017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A Series and is the answer not in the manual?

Questions and answers

Related Manuals for MAG TOOLS A Series

Summary of Contents for MAG TOOLS A Series

  • Page 1 Long Chassis Service Jack w/Air Operating Instructions & Parts Manual Model Number Capacity JSA1000AH 10 Ton Series A U.S. Patent No's. 5,946,912 • 5,341,723 This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

  • Page 2: Safety And General Information

    SAFETY and GENERAL INFORMATION Save these instructions. For your safety, read, understand, and follow the information provided with and on this jack before using. The owner and operator of this equipment shall have an understanding of this jack and safe operating procedures before attempting to use.
  • Page 3 PREPARATION Assembly Always secure the handle into the handle sleeve by means of the bolt lock washer and nut provided. Tighten securely to prevent accidental removal of handle while in use. Before Use 1. Verify that the product and application are compatible. 2.

  • Page 4: Operation

    OPERATION Lifting Only attachments and/or adapters supplied by the manufacturer shall be used. Lift only on area of the vehicle as specified by the vehicle manufacturer. Note: The jack is equipped with handle position lock. To adjust the handle, release lock device by pulling the lever up, then back until lever is locked into place.

  • Page 5: Troubleshooting

    MAINTENANCE Lubrication A periodic coating of light lubricating oil to pivot points, axles and hinges will help to prevent rust and assure that wheels, casters and pump assemblies move freely. To help ensure trouble free operation, an inline air dryer and oiler is recommended.
  • Page 6 Figure 2 - Replacement Parts Illustration for Model JSA1000AH Series A...
  • Page 7 Replacement Parts List for Model JSA1000AH Series A: Item Part No. for ATD-7396 Description B120-10003-000 Filter G100-40003-000 Reservoir G62S-03300-200 Filler Screw Assy. 5901-00082-000 O-ring, D7.1 x 2.65 G251-20004-000 Release Valve B300-14002-000 Washer G651-31002-000 Pump Cylinder G651-31001-000 Pump Piston G100-50000-000 Universal Joint Assy. 5405-12039-000 5405-02028-000 Retaining Pin...

  • Page 8: One-Year Limited Warranty

    ONE YEAR LIMITED WARRANTY For a period of one (1) year from date of purchase, MAC Tools (a division of Stanley Black & Decker) will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage.

This manual is also suitable for:

Jsa1000ah
