JSA200EL
2-TON
CAPACITY
EXTRA LOW JACK
OWNER'S MANUAL
SPECIFICATIONS
Maximum Capacity ................................................................2-Ton
Minimum Height .................................................................. 2-3/4"
Maximum Height ......................................................................24"
ASME PASE-2014
Handle Length ................................................................... 45-1/4"
Overall Length ................................................................... 32-1/2"
Overall Width ..................................................................... 14-1/2"
Weight ............................................................................... 97-Lbs.
© 2015 Mac Tools
JSA200EL
6/3/15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MAG TOOLS JSA200EL
Summary of Contents for MAG TOOLS JSA200EL
- Page 1 JSA200EL 2-TON CAPACITY EXTRA LOW JACK OWNER'S MANUAL SPECIFICATIONS Maximum Capacity ..............2-Ton Minimum Height ..............2-3/4" Maximum Height ..............24" ASME PASE-2014 Handle Length ..............45-1/4" Overall Length ..............32-1/2" Overall Width ..............14-1/2" Weight ................97-Lbs. © 2015 Mac Tools...
-
Page 2: Warning Information
• This is a lifting device only. Immediately after lifting, support the vehicle with jack stands capable of sustaining the load before working on the vehicle • Center load on saddle. Be sure setup is stable before working on vehicle • Do not move or dolly the vehicle while on the jack • Do not use any materials that may serve as risers, spacers or extenders between the stock lifting saddle and the load • Do not use any adapters that replace the stock lifting saddle unless approved or supplied by the jack manufacturer • Do not use or modify this product for any other purpose than that for which it was designed without consulting the manufacturer’s authorized representative • Always lower the jack slowly and carefully • This product may contain one or more chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands thoroughly after handling • Failure to heed these warnings may result in serious or fatal personal injury and/or property damage CONSEQUENCES OF NOT AVOIDING HAZARDOUS SITUATIONS WARNING Failure to read this manual completely and thoroughly, failure to understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS, MAINTENANCE INSTRUCTIONS and comply with them, and failure to comply with the METHODS TO AVOID HAZARDOUS SITUATIONS could cause accidents resulting in serious or fatal personal injury and/or property damage. JSA200EL 6/3/15... -
Page 3: Setup Instructions
JSA200EL 2-TON CAPACITY EXTRA LOW JACK SETUP INSTRUCTIONS WARNING Failure to follow these Setup Instructions may result in serious injury or death, and/or property damage. 1. Refer to the exploded view drawing on page 4 to identify jack components. 2. Remove the 2-piece handle from box. Insert narrow portion of top section (#24) into bottom section (#26) and secure with the spring button. 3. Grease the inside of the handle yoke (#19) and remove the handle set screw (#18) from the yoke (#19). Insert the handle (#26) all the way in the handle yoke (#19) until it engages the universal joint assembly (#41). Secure the handle (#26) to the handle yoke (#19) with the handle set screw (#18). 4. Air may become trapped in the hydraulic system during shipping and handling. Trapped air will affect the pumping performance of the jack. If this occurs, follow the air purging procedure below: a) Remove the oil fill screw. -
Page 4: Preventative Maintenance
JSA200EL 2-TON CAPACITY EXTRA LOW JACK OPERATINg INSTRUCTIONS WARNING Failure to follow these Operating Instructions may result in serious injury or death, and/or property damage. 1. Put vehicle transmission in park or in gear and then apply the emergency brake. To raise load: Turn the handle in a clockwise direction until tight. Position the jack under the load. Proceed to pump the handle in order to raise the lift arm to the load. As the saddle at the end of the lift arm gets closer to the load, reposition the jack so the saddle will contact the load firmly and the load is centered on the saddle. Make sure the saddle is correctly positioned. Raise the load to the desired work height. Place jack stands of appropriate... -
Page 5: Proper Storage
JSA200EL 2-TON CAPACITY EXTRA LOW JACK PROPER STORAgE It is recommended that the jack be stored in a dry location with all wheels touching the ground on a relatively level surface. TROUBLESHOOTINg Important: Service jacks are self-contained devices used for lifting, but not sustaining, a partial vehicular load. In accordance with ASME PASE Load Sustaining Test: “A load not less than the rated capacity…shall not lower more than 1/8"... - Page 6 JSA200EL 2-TON CAPACITY EXTRA LOW JACK HYDRAULIC JACK MAINTENANCE gUIDE WARNING Service jacks are designed for lifting purposes only; always support raised load with jack stands. REGULAR MAINTENANCE • MONTHLY or as necessary (depending on usage) 1. Using a grease gun, add grease to grease fitting in the lift arm pivot shaft. (Use a multi-purpose NLGI type grease only.) 2. Lubricate all linkages and pivot points. (Use white lithium spray grease only.) 3. Remove handle; lubricate handle receptacle and handle end. (Use white lithium spray grease only.) 4. Lubricate both rear casters, bearing and both front wheels.
-
Page 7: Parts Diagram
JSA200EL 2-TON CAPACITY EXTRA LOW JACK PARTS DIAgRAM Item No. Part No. Description Qty. Item No. Part No. Description Qty. 1 RS35T01 Retaining Ring (20) 23 RS6602LP23 Spring and Button 2 RS35T02 Washer (20) 24 RS6602LP24 Handle Lever A 3 RS6602LP03 Front Wheel 25 RS20025 Handle Bumper 4 Frame... -
Page 8: Limited Warranty
JSA200EL 2-TON CAPACITY EXTRA LOW JACK LIMITED WARRANTY MAC TOOLS WARRANTS TO ITS CUSTOMERS THAT THE COMPANY’S MAC TOOLS BRANDED PRODUCTS ARE FREE FROM DEFECTS IN WORKMANSHIP AND MATERIALS. Mac Tools will repair or replace its Mac Tools branded products which fail to give satisfactory service due to defective workmanship or materials, based upon the terms and conditions of the following described warranty plans attributed to that specific product. This product carries a ONE-YEAR warranty. During this...
