User Manual
INTERNET
WAN
Rear Panel
The rear panel provides buttons, connection ports, POTS ports and antennas.
Refer to the following for detailed instructions.
LABEL
ON/OFF
ANTENNA
12VDC
PORT
ETHERNET
PORTS
1-4
POTS PORT
DSL PORT
Page 8 of 44
OFF
Steady green
Steady green
Blinking green
DESCRIPTION
Press to power on or off the modem router.
Fixed Wi-Fi Antenna. For the best Wi-Fi
performance, we recommends that the outside two antennas be
outward at about 30 degrees
12V 1.0A DC Input port
Connecting computers and other Ethernet devices (RJ45)
Connecting the telephone cable.
Connecting the modem router to an ADSL line (RJ11)
No connection to the Internet
Internet connection established
Connected to the modem
Transmitting/Receiving data
