Aztech DSL1215FUN(L) Speci?Cations

DSL1215FUN(L)
ADSL2/2+ 2FXS 1FXO Wireless-N
4-Port Gateway with USB Host
The Aztech DSL1215FUN(L) ADSL2/2+ 2FXS 1FXO Wireless-N 4-Port Gateway with USB Host is an
integrated access device, which supports ADSL2/2+, 802.11b/g/n wireless, 4-Port fast Ethernet
switch, 100Mbps WAN port for ber ONT, Voice-over-IP and USB 2.0 Host. This Aztech next generation
gateway supports ITU G.992.3 (ADSL2), G.992.5 (ADSL2+) and RE-ADSL Ready; and it has a solid
interoperability performance with various brands of DSLAM. Aztech DSL1215FUN(L) also supports
Annex M standard, which support up to 3Mbps on the uplink.
The Aztech DSL1215FUN(L) is able to deliver low cost calls through the broadband, up to 2 simultane-
ous calls could be handled at the same time with full population of FXS ports. Additional feature PSTN
backup keeps the telephone line alive without AC power.
Targeted at providing good quality and high de nition IPTV services to end users, Aztech
DSL1215FUN(L) Residential Gateway is an intelligent 4 port 10/100 Auto MDI/MDIx Managed Switch.
Security is provided via a double SPI (Stateful Packet Inspection) and Full Cone NAT support rewall.
Hardware accelerated AES/WEP/WPA/WPA2 based encryption/MAC Address Filtering for Wireless
links. Multiple session VPN Pass-through and DMZ support provide additional security support for
telecommuters as well as allow exibility while maintaining security against malicious hackers.
Choices of Dynamic DNS server give users the exibility of hosting a web or an FTP server with
various domain names.
Aztech DSL1215FUN(L) supports IEEE 802.11b/g/n wireless and USB 2.0 Host port for printing and le
sharing applications.
Aztech DSL1215FUN(L) could function as a Broadband Home Router by connecting the 100Mbps
Ethernet WAN port with an ONT. It extends the fast ber connection to the house. It also supports
multiple-VLAN management for delivering triple play services.

Features

• Broadband connectivity via ADSL or Ethernet WAN port
• Connect the Ethernet WAN port of your Home Wireless
Gateway to an ONT and experience the faster ber
connection to your home.
• Supports the latest Wireless-N technology with
wireless speed up to 300Mbps.
• Comes with 2 FXS ports for Voice over IP applications
coupled with 1 FXO port as PSTN Failover Backup.
• With Micro Filter on-board, the external FXO port could
be eliminated, yet the phone calls are always ltered to
eliminate noise from high frequency signals
• Additional two high-speed USB 2.0 host with speed up
to 480Mbits/second.
• Use one Integrated Home Wireless Gateway to deliver
Triple-Play
Internet,Voice over IP and IPTV to your home or o ce.
• Transform into The Digital Home era where internet-
working of computers and gadgets are made possible
by UPnP Technologies.
Head Office Head Office Hong Kong Office Hong Kong Office
AZTECH TECHNOLOGIES PTE LTD. AZTECH SYSTEMS LTD. AZTECH SYSTEMS (H.K) LTD. AZTECH SYSTEMS (H.K) LTD.
31 Ubi Road 1, Aztech Building 31 Ubi Road 1, Aztech Building Rooms 2-10, 3rd Floor, Core Building 1 Rooms 2-10, 3rd Floor, Core Building 1
Singapore 408694 Singapore 408694 No. 1 Science Park East Avenue No. 1Science Park East Avenue
Tel: (65) 6594 2288 Fax: (65) 6749 1198 Tel: (65) 6594 2288 Fax: (65) 6749 1198 HongKong Science Park HongKong Science Park
Shatin, New Territories, Hong Kong Shatin,New Territories, Hong Kong
Tel: (852) 2757 1177 Fax: (852) 2753 0578 Tel: (852) 2757 1177 Fax: (852) 2753 0578
Services including high-Speed
Malaysia Office Malaysia Office
AZ-TECHNOLOGY SDN BHD. AZ-TECHNOLOGY SDN BHD.
No 901, 9th Floor, Block B No 901, 9th Floor, Block B
Kelana Business Centre Kelana Business Centre
97, Jalan SS7/2, Kelana Jaya 47301 97, Jalan SS7/2, Kelana Jaya 47301
Petaling Jaya, Selangor Petaling Jaya, Selangor
Tel: (60)(3) 7804-8450 Fax: (60)(3) 7804-8457 Tel: (60)(3) 7804-8450 Fax: (60)(3) 7804-8457
ADSL
FXO 2 x FXS 4 x Ethernet 10/100
(Auto MDI/MDIx)
China Office China Office USA Office
AZTECH COMMUNICATION DEVICE (DG) LTD. AZTECH COMMUNICATION DEVICE (DG) LTD. AZTECH LABS, Inc.
Jiu Jiang Shui Village, Chang Ping Town Jiu Jiang Shui Village, Chang Ping Town 4005 Clipper Court, Fremont
Dong Guan City, Dong Guan City, CA 94538, U.S.A.
Guang Dong Province, China. Guang Dong Province, China. Tel: (1)(510) 683-9800 Fax: (1)(510) 683-9803
Tel: (86)(769) 8393-6688 Fax: (86) (769) 8393-1138 Tel: (86)(769) 8393-6688 Fax: (86) (769) 8393-1138
WAN
www.aztech.com www.aztech.com
USA Office Germany Office Germany Office
AZTECH LABS, Inc. AZTECH SYSTEMS GmBH. AZTECH SYSTEMS GmBH.
4005 Clipper Court, Fremont Kreuzberger Ring 22, 65205 Wiesbaden Kreuzberger Ring 22, 65205 Wiesbaden
CA 94538, U.S.A. Germany. Germany.
Tel: (1)(510) 683-9800 Fax: (1)(510) 683-9803 Tel: (49)(0) 611-45020-0 Fax: (49)(0) 611-45020-100 Tel: (49)(0) 611-45020-0 Fax: (49)(0) 611-45020-100
Power Reset
USB
