Aztech DSL805EW Technical Specification

TECHNICAL SPECIFICATION
DSL805EW
ADSL 2+ Wireless G++ 4 Port Gateway

OVERVIEW

MAIN FEATURES

Shiro Corporation Pte Ltd (A subsidiary of Aztech Systems Ltd) 31 Ubi Road 1 #07-00, Aztech Building Singapore 408694
Tel: (65) 6843 1333 Fax: (65) 6749 3083 Email:
The Shiro DSL805EW ADSL 2+ Wi reless G++ 4 Por t Gateway uses Texas Instruments AR7 with
1350A for wireless combined Chipset solution that fully complies with ANSI T1.413 Issue 2, ITU-T
G.992.1 (G.dmt) and G.992.2 (G.lite), ADSL standard. Shiro DSL805EW also provides future proof
functionality with higher data transmission rates with ADSL2, ADSL2+, and Extended Reach-ADSL
support. This next generation ADSL will be providing up to 12Mbps speed and additional 600 feet
reach for ADSL2 and up to 26Mbps speed for distances up to 5,000 feet for ADSL2+.
ADSL/ATM Support
ANSI T1.413 issue 2, ITU-T G.992.1 (G.dmt) and G.992.2 (G.lite) compliant
G.992.3 (ADSL2), G.992.5 (ADSL2+), RE-ADSL Ready
Rate Adaptive modem at 32 Kbps steps
Dynamic Adaptive Equalization to improve Carrier's service area
Bridge Tap Mitigation support
ATM Layer with Traffic shaping QoS Support (UBR, CBR, VBR-rt, VBR-nrt)
AAL ATM Attributes - AAL5
Supports 8 multiple PVC (up to 16 PVC Bridge Support)
Spectral compatibility with POTS
F4 & F5 OAM Loopback/Send and Receive
Annex B population option
TR-067 compliant

Encapsulation Support

RFC2684 Bridge and Routed LLC and VC Mux support
RFC2364 PPPoA Client support
RFC2516 PPPoE Client support
Transparent Bridge Support
PAP/CHAP/MS-CHAP for Password Authentication Support

Network Support

Static IP, Dynamic RIP routing support
IP/TCP/UDP/ICMP/ARP/RARP Application Support
Network Address Translation (NAT)
Port Mapping/Forwarding/Triggering
Easy setup of Port Forwarding rules for popular Games/Application
NAT Application Level Gateway for popular applications
DHCP Server/Relay/client
DNS Relay Agent
DMZ support
PVC to VLAN Mapping
Multiple Sessions IP Sec and PPTP/L2TP VPN pass through support
PPP Always on with configurable timeout
PPP Dial on Demand
Universal Plug and Play Support
SNMP v1 and v2
Multi NAT support
Easy Connect Support.
DDNS (Dynamic DNS) Support
IGMP Proxy Support (IGMP v1 and v2)
SNTP Support
QoS Support (DSCP, TOS).
PPP/DHCP Auto Detection

WLAN Support

EEE 802.11, 802.11b and 802.11g compliant
Supports 802.11b, 802.11g and 802.11g++ simultaneously
Transmit output power up to 20dBm (standard)
Conforms to Wireless Ethernet Compatibility Alliance (WECA) Wireless Fidelity (Wi-Fi
) Standard
tm
