6/32 Bosch Rexroth AG

About this manual

1 About this manual
This manual contains information about the safe and appropriate transport,
installation, commissioning, maintenance, disassembly and independent
troubleshooting of simple malfunctions of the HAB..-4X bladder-type accumulator.
Please read this manual thoroughly, particularly chapter 2 on "Principle safety
instructions", before working with the HAB..-4X bladder-type accumulator.
1.1

Related documentation

The HAB..-4X bladder-type accumulator is a machine and system component.
Please also observe the manuals of the other machine and system
f
components as well as the documentation provided by the machine or system
manufacturer.
Please also observe the following documentations:
f
Table 1: Related documentation
Documentation Content
Data sheet RE 50170 Technical data, operating conditions, limits of performance,
project planning information concerning HAB..-4X bladder-type
accumulators
Data sheet RE 07008 General information on hydraulic products
Data sheet RE 07900 General information on the installation, commissioning and
maintenance of hydraulic systems
Data sheet RE 90220 General information on hydraulic fluids on mineral oil basis
You can find this operating manual as well as the related documentation in the
media directory under www.boschrexroth.com\various\utilities\mediadirectory.
Please also observe the generally valid legal and other relevant provisions
f
of the European and/or national legislation as well as the provisions on the
prevention of accidents and on environmental protection valid in your country.
1.2

Abbreviations used

Table 2: Abbreviations
Abbreviation Meaning
Type HAB..-4X HAB bladder-type accumulator, series 4X
RD Rexroth document in the German language
Rx Rexroth document in a different language
1.3

Signs and symbols used

This manual uses the following signs and symbols:
Activity symbol: The text following this sign describes activities that can be
f
performed in any order.
1.
Numbered activities: The text following this sign describes activities that are to
be performed in the order indicated.
Type HAB..-4X | RE 50170-B/10.08
