I N S TA L L AT I O N I N S T R U C T I O N S
L I S T E D F I R E - R A T E D B A C K C A N
F O R S O N A N C E S Y M P H O N Y
I N - W A L L

Introduction

Thank you for purchasing the Sonance Model #91907
fire-rated 6½" Rectangular speaker backcan†.
†The Intertek Listed* fire-rated speaker backcan is a compo-
nent in the Sonance In-wall Speaker System (WHI Design
Listing DII/PV 60-02), comprised of an Intertek Listed fire-
rated metal backcan (Sonance Model #91907), and a
Sonance Symphony ® in-wall speaker (or equivalent speaker)
or a metal coverplate to protect the exposed opening.
N O T E : T
H E I N C L U S I O N O F A
R E C TA N G U L A R F O O T P R I N T I N
)
S P E A K E R O R A M E TA L C O V E R P L AT E T O P R O T E C T T H E E X P O S E D
O P E N I N G I S R E Q U I R E D I N T H I S A S S E M B LY T O A C H I E V E T H E
1 - -
H R F I R E R E S I S TA N C E R AT I N G

Box Contents

The Backcan box should contain the following:
(1) Intertek Listed Sonance Fire Rated Backcan
(2) Snap2it™ wire clamps

Installation in a Wall

1. Select locations in the wall for the Sonance Symphony
In-Wall Speaker per the speaker's instruction manual.
2. Run speaker wire to desired speaker locations.
N : A
O T E LWAY S C H E C K
R U N N I N G W I R E S T H R O U G H WA L L S
3. Open one of the knockouts in the Backcan and install one
of the Snap2it™ wire clamps into the open knockout.
N : A S
O T E S E C O N D N A P
-
F O R D A I S Y C H A I N E D I N S TA L L AT I O N S
B
O U T O N T H E A C K C A N W I L L N E E D T O B E R E M O V E D F O R
T H I S T Y P E O F I N S TA L L AT I O N
4. Attach the Backcan at the desired wall elevation to the
vertical studs through the pre-drilled holes in the flange of
the speaker Backcan using a minimum of four (4) #8 x 1¼-
inch long mechanical fasteners: one applied to each corner.
See Figure 1 .
5. Insert speaker wire through the Snap2it™ clamp and into
the backcan. Leave enough slack to easily connect the
speaker.
6. Cut a hole in the gypsum board‡ to match the rectangular
opening in the Backcan.
S P E A K E R S
S S
O N A N C E Y M P H O N Y
- (
WA L L S P E A K E R O R E Q U I VA L E N T
.
L O C A L B U I L D I N G C O D E S
.
2 ™
I T W I R E C L A M P I S I N C L U D E D
. A
S E C O N D K N O C K
.
®
‡ Gypsum Board Wall Assembly consisting of any gypsum
board wall assembly, one-hour rated in accordance with
ASTM E119, UL 263, NFPA 251, or CAN/ULC S 101.
7. Apply the gypsum board over the Backcan so that the hole
is aligned with the Backcan opening. See Figure 2 .
Follow the instructions included with the speaker for the
remainder of the installation, or install a metal face plate to
close the backcan opening.
*See Intertek Director y of Listed Building Products at:
http://etlwhidirector y.etlsemko.com/WebClients/ITS/DLP/Pr
® 6 ½ "
oducts.nsf/$$Search?OpenForm
F 1 : A
I G U R E T TA C H I N G
B
T H E A C K C A N T O T H E
W S
A L L T U D S
®
B E F O R E
F 2 : I
I G U R E N S TA L L I N G
G Y P S U M B O A R D O N T H E
- (
WA L L A L I G N C U T O U T
W I T H S P E A K E R O P E N I N G
B )
O N A C K C A N
