AUTOMATE
Li-ion Solar Charging Power Panel
AUTOMATE | Li-ion Solar charging power panel provides supplemental power to all Li-ion
wirefree motors or rechargeable battery packs.
The monosilicon/crystal solar panel provides power in varied conditions including low
light situations. Panels can also be wired in parallel to provide additional power for
larger applications.
Users can refer to the AUTOMATE Solar Guide for direction related to regional solar
conditions and expected performance.
FEATURES:
•
Plug n' play for all AUTOMATE Li-ion motors & rechargeable battery packs
•
Sleek design allows for unobtrusive placement behind most headrails
•
Parallel wiring options support large shades
•
Monosilicon/crystal technology allow for up to 30% more efficiency than alternatives
•
Low light harvesting technology supports power generation in varied conditions
™
SOLAR
POWERED
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for rollease acmeda AUTOMATE Series
Summary of Contents for rollease acmeda AUTOMATE Series
-
Page 1: Double Sided Adhesive Tape X
AUTOMATE ™ Li-ion Solar Charging Power Panel SOLAR POWERED AUTOMATE | Li-ion Solar charging power panel provides supplemental power to all Li-ion wirefree motors or rechargeable battery packs. The monosilicon/crystal solar panel provides power in varied conditions including low light situations. Panels can also be wired in parallel to provide additional power for larger applications. -
Page 2: Table Of Contents
1. Solar Panel 2. Solar Panel Mounting Bracket 3. Double Sided Adhesive Tape x 2 4. Alcohol Wipe x 2 5. Self Tapping Screw & Drywall Anchor x 2 6. Installation Instructions 2 | Automate ROLLEASE ACMEDA Programming Instructions | MTSOLPAN-B ™... - Page 3 For use with Li-ion motors only. • Do not cut power cables. • Use only Rollease Acmeda hardware. • Do not expose the Solar panel to water or install in humid or damp environments. • Do not drill into motor body or Solar panel body.
-
Page 4: Installation
Ensure solar panel has adequate exposure to sunlight. When selecting a position for solar panel, consider any external obstructions like trees, building, signs, etc. that may limit the amount of sun light reaching onto the solar panel. 4 | Automate Programming Instructions | MTSOLPAN-B ROLLEASE ACMEDA ™... - Page 5 Any partial or total covering of any solar panel cell will affect solar panel performance. Step 3. Connect Solar Panel cable (female) connector to required (male) connector. IMPORTANT! Ensure any cables are kept clear of fabric at all times. 5 | Automate ROLLEASE ACMEDA Programming Instructions | MTSOLPAN-B ™...
-
Page 6: Dimensions
Parameters Value Power output 2.3±0.2 (Under 1 SUN - 1000W/m²) Max Average Voltage output 12.3±0.1 Max Average Current 190±20 375mm (14.769 in) Minimum Lux value to start KLux 10±5 output 6 | Automate Programming Instructions | MTSOLPAN-B ROLLEASE ACMEDA ™... -
Page 7: Trouble Shooting
Battery voltage is low / Solar of Solar panel. Ensure sun Panel issue exposure is adequate. Motor beeps 10 times when in use Solar Panel not providing enough Recharge with AC adapter power (Optional) 7 | Automate Programming Instructions | MTSOLPAN-B ROLLEASE ACMEDA ™... - Page 8 ROLLEASE ACMEDA | AUSTRALIA 110 Northcorp Boulevard, Broadmeadows VIC 3047 T +61 3 9355 0100 | F +61 3 9355 0110 ROLLEASE ACMEDA | USA 200 Harvard Avenue Stamford, CT 06902 6320 T +1 203 964 1573 | F +1 203 964 0513...
