AUTOMATE
ARC Diagnostic Tool
AUTOMATE
| The ARC Diagnostic Tool is compatible with all ARC products and can
™
assist in the diagnosis of Radio Frequency (RF 433Mhz) issues that can occur in difficult/
problematic environments.
FEATURES:
•
Supports up to 6 ARC Channels
•
Multiple Diagnostic Modes
•
Works at ranges up to 200m [656ft] in open spaces
•
Back-lit Alphanumerical LCD display for advanced diagnostics such as:
•
Signal Strength measurement (RSSI)
•
Data integrity (CRC)
•
Receive/transmit device identifier
™
433 MHz
