- Page 1 Wilo-Multivert MVI 16.../ MVI 32.../ MVI 52.../ MVI 70.../ MVI 95... Einbau- und Betriebsanleitung Installation and operating instructions Notice de montage et de mise en service Istruzioni di montaggio, uso e manutenzione...
- Page 2 MVI 16... /MVI 32... /MVI 52... Fig. 1...
- Page 3 MVI 70... /MVI 95... Fig. 1...
- Page 4 Fig. 2 Fig. 3 Fig. 4...
- Page 5 CE-Konformitätserklärung ......2-3 Déclaration de conformité CE ......2-3 1.
- Page 6 : Direction basse-tension 93/68/EWG Angewendete harmonisierte Normen, insbesondere: EN 809 Applied harmonized standards, in particular: EN 60034-1 Normes harmonisées, notamment: Dortmund, 11.04.2005 Erwin Prieß WILO AG Quality Manager Nortkirchenstraße 100 44263 Dortmund Document: 2060375.1...
- Page 7 91/263/EWG, 92/31/EWG, 89/336/EWG όπως τροποποιήθηκε 93/68/EWG 91/263/EWG 92/31/EWG, 93/68/EWG Alçak gerilim direktifi 73/23/EWG ve takip Οδηγία χαµηλής τάσης EG–73/23/EWG όπως eden, 93/68/EWG τροποποιήθηκε 93/68/EWG Kısmen kullanılan standartlar: Εναρµονισµένα χρησιµοποιούµενα πρότυπα, ιδιαίτερα: WILO AG Nortkirchenstraße 100 Erwin Prieß Quality Manager 44263 Dortmund...
-
Page 8: General Information
Only use branded goods with corrosion protection-inhibitors, follow manufac- turer’s instructions. ) If other and also aggressive chemical fluids are to be pumped, be sure to follow catalogue instructions and first obtain the approval of WILO. Principal dimensions and connection dimensions (Table 2, see also Fig. 3):... - Page 9 ENGLISH 2.4 Safety precautions for the operator 1.2.2 Type key Existing regulations for the prevention of accidents must be followed. MVI 16 08 3 / 16 / E / 3 - 400 - 50 - 2 / XX / X Dangers caused by electrical energy are to be excluded.
- Page 10 ENGLISH – Installation and operating instructions – Check that the mains current and voltage comply with the data on the rating plate. 4.3 Accessories – Pump/installation must be earthed in compliance with regulations. see catalogue or data sheet – All motors must be fitted with a motor safety switch by the customer to prevent the motor from overheating.
- Page 11 ENGLISH On pumps equipped with greaser under bearing box (table below), see For pumps with a star or triangular circuit starting current, the greasing instructions written on sticker put on it: connections of two coils must be interchanged, e.g. U1 with V1 and U2 with V2.
-
Page 12: Problems, Causes And Solutions
If the fault cannot be remedied, please contact your plumbing and heating specialist or your nearest WILO customer services or representative. Subject to technical alterations! - Page 13 Spain Finland Poland Belarus Kazakhstan WILO Ibérica S.A. WILO Finland OY WILO Polska Sp. z.o.o. WILO Bel OOO TOO WILO Central Asia 28806 Alcalá de Henares 02320 Espoo 05-090 Raszyn k/Warszawy 220035 Minsk 480100 Almaty (Madrid) T +358 9 26065222...
- Page 14 WILO AG Österreich WILO AG Wilo-Service-Center Zentrale Wien: Belarus, Belgien, Bulgarien, China, Dänemark, Finnland, Frankreich, Auftragsbearbeitung Nortkirchenstraße 100 WILO Handelsgesellschaft mbH Nortkirchenstraße 100 44263 Dortmund Eitnergasse 13 Griechenland, Großbritannien, 44263 Dortmund 1230 Wien Irland, Italien, Kanada, T 0231 4102-0 –Kundendienststeuerung...
