AC (120V) Isolated Output Module,
16 Outputs
Cat. No. 1771 ODD
Installation Instructions
This document provides information on:
important pre-installation considerations
installing the module
installing and connecting the wiring
replacing the fuse
using the module indicators for troubleshooting
module specifications
An output from this module can drive an Allen-Bradley Size 5 motor
starter, provided its supply voltage does not drop below 92V ac. The
maximum load current the module can deliver is 2A per channel, not to
exceed 8A total per module.
Your module's outputs can drive the following motor starter combinations:
16 size 3 motor starters (1 per output)
10 size 4 motor starters (1 per output)
7 size 5 motor starters (1 per output)
The switching device in the output circuit is a solid-state triac. There is a
small leakage current in the off state due to both triac and capacitive
characteristics. The maximum leakage current per output is 3mA at 138V
ac. Nominal leakage current is 1.5mA. The on-state voltage drop across
the output terminals will not exceed 1.5V ac at 2A.
