Allen-Bradley 1771-OBN Installation Instructions

To The Installer
Pre installation
Considerations
DC (10 30V) Output Module
Cat. No. 1771 OBN
Installation Instructions
This document provides information on:
important pre-installation considerations
power supply requirements
installing the module
connecting the wiring
using the indicators on the module for troubleshooting
module specifications
The 1771-OBN dc output module is a source output and requires a sink
input. A sink input provides a path to ground and a source output provides
a positive voltage path.
Use this module in all 1771 I/O chassis except 1771-A1, -A2 and 1771-A4
chassis. Refer to the table below for processor compatibility.
Table A
Processor Compatibility Chart
System Type Use with Processors:
Local
Mini PLC 2/02
Mini PLC 2/16 (cat. no. 1772 LX, LXP)
Mini PLC 2/17 (cat. no. 1772 LW, LWP)
PLC 5/15
Remote (with a 1771 ASB
PLC 2/20
remote I/O adapter)
PLC 2/30 (cat. no. 1772 LP3)
PLC 3
PLC 3/10 (cat. no. 1775 LP4, LP8)
PLC 5/15, Series B and later (cat. no. 1785 LT)
Do not place this module in the same I/O chassis as the 1771-IX
thermocouple module. You can use this module in the same chassis as the
1771-IXE thermocouple module.
®
(cat. no. 1772 LZ, LZP)
®
, Series B and later (cat. no. 1785 LT)
®
(cat. no. 1772 LP2)
®
(cat. no. 1775 L1, L2, L3, L4)
