The data given in the tables are achieved with Gilson
standard length series pipette tips. If you are using other
10 µL extended length series pipette tips, you will need
to recalibrate your pipette to comply with specifications.
Multichannel models
Model Volume Volume
range (µL) (µL)
8X-10µl 0.5-10
12X-10µl
8X-20µl 2-20
12X-20µl
8X-200µl 20-200
12X-200µl
8X-300µl 20-300
12X-300µl
The data given in the tables conform to the
ISO8655-2 Standard. With a precise pipetting
technique (see Chapter 7 - General guidelines
for good pipetting) the 2µl single channel model
may be used to aspirate volumes as low as
0.1 µL and the 10µl single channel model as low
as 0.5 µL.
15A- SPARE PARTS FOR SINGLE
MODELS
Description
A
Push button
B
Connecting nut
C
Piston assembly
D
Seal + O-ring
E
Tip holder
F1 F2
Tip-ejector assembly
F2
Ejector adapter
SPECIFICATIONS - Error limits
Systematic error
(µL) (%)
0.5 ± 0.09 ± 17.6
10 ± 0.22 ± 2.2
2 ± 0.11 ± 5.5
20 ± 0.40 ± 2.0
20 ± 0.55 ± 2.8
200 ± 2.20 ± 1.1
20 ± 1.10 ± 5.5
300 ± 3.30 ± 1.1
Quantity
5
5
1
5
5
5
1
USER'S
USER'S
GUIDE
GUIDE
Random error
(µL) (%)
≤ 0.04 ≤ 8.8
≤ 0.11 ≤ 1.1
≤ 0.09 ≤ 4.4
≤ 0.17 ≤ 0.8
≤ 0.28 ≤ 1.4
≤ 0.55 ≤ 0.3
≤ 0.39 ≤ 1.9
≤ 1.10 ≤ 0.4
2µl
FE07004
FE07001
FE07040
FE07050
FE07013
FE07059
FE07034
