Summary of Contents for Stanton DJLab.2
- Page 1 DJLab.2 OWNER'S MANUAL S T A N T O N MA G N E T I C S , I N C information@stantondj.com + 1 954- 689-8833 w w w . s t a n t o n d j . c o m...
-
Page 2: Important Safety Instructions
IMPORTANT TO SAFETY 13. Unplug this apparatus during lightning storms or when 14. Refer all servicing to qualified Stanton service center. 15. This appliance shall not be exposed to dripping or CAUTION: To reduce the risk of electric shock, do not remove the cover (or back). -
Page 3: Line Voltage Selection
LINE VOLTAGE SELECTION 115V The desired voltage of your turntable may be set with the VOLTAGE SELECTOR switch on the rear panel of the main unit, using a screwdriver. Do not twist the VOLTAGE SELECTOR switch with excessive force as this may cause damage. If the VOLTAGE SELECTOR switch does not move smoothly contact a qualified serviceman. - Page 4 1) Input fader - Controls individual source levels/volume (channels) in the mix. 2) Input toggle switch - Selects which source will be active based on what you have connected to the rear panel input section (phono/line). 3) Channel EQ - Adjusts the high, mid and low frequency levels of the input channels for good sound.
-
Page 5: Quick Setup Diagram
QUICK SETUP DIAGRAM Study this setup diagram. Make sure all faders are at "zero" and all devices are off. First, connect all input sources. Next, connect your microphone and monitor headphones. Finally, connect the stereo outputs to the power amplifier(s) and/or audio receivers such as tape decks. -
Page 6: Specifications
M.201 INPUT / OUTPUT IMPEDANCE & SENSITIVITY: LINE -14dB/10K OHM ±2dB PHONO -50dB /47K OHM ±2dB -60dB /2.2K OHM ±2dB MASTER 1K OHM PHONES 0dB/33 OHM ±2dB (LOAD=32 OHM) MAX. OUTPUT (THD=1%) MASTER MORE THAN +14dBV MAX PHONES MORE THAN +21dBV MAX CHANNEL BALANCE WITHIN 3dB FREQUENCY RESPONSE:... -
Page 7: Before Use
*Check that the following parts are included in the package with the main unit: Turntable platter Slip mat 45-rpm adaptor Counterweight 500B cartridge and headshell Operating instructions RCA cables with ground wire Target light T.60 TURNTABLE CONTENTS BEFORE USE AC cord 10) Cloth dust cover *Notes: Do not connect the AC power plug before... - Page 8 The average stylus pressure of the cartridge body is 1.5-2 g. If you use a non-Stanton cartridge, please follow that manufacturer’s instructions. 8. Install the cloth dust cover to the main unit.
-
Page 9: Operation
4. Remove the stylus protector, release the arm • For best results & proper care of your equipment use Stanton Vinyl Cleaner (VC-1) for your records and Stylus Cleaner Kit for styli (SC-4). • Clean the stylus periodically with a soft brush to prevent the accumulation of dust. - Page 10 T.60 POWER SOURCE AC 100V, 50/60Hz (For Japan) AC 110V, 60Hz (For Taiwan) AC 120V, 60Hz (For U.S.A.,Canada,Mexico) AC 220V, 50Hz (For United Arab Emirates,Chile,Argentina) AC 220V, 60Hz (For Philippines) AC 230V, 50Hz (For Europe,New Zealand,South Africa,Singapore,Israel) AC 240V, 50Hz (For Australia,U.K.) POWER CONSUMPTION 7.5 Watts DIMENSIONS 452 (W) x 370 (D) x 86 (H) mm...
- Page 11 Stanton dealer’s return policy. Stanton assumes no risk and shall be subject to no liability for damages or loss resulting from the specific use or application made of the merchandise. Stanton's liability for any claim, whether based on breach of contract, negligence, infringement of any rights of any party, or product liability, and relating to the merchandise shall not exceed the price received by Stanton from your purchase of such merchandise.
- Page 12 c u t a l o n g d o t t e d l i n e...
- Page 13 Stanton Magnetics, Inc. 3000 SW 42nd Street Hollywood, FL 33312 U.S.A. PLACE STAMP HERE...
