AudioArts Engineering Lightning Technical Manual page 15

USB 1 & 2 Out – RJ-45
The signals are analog stereo; unbalanced.
Pin 1 – HI
Pin 2 – SH
Pin 3 – HI
Pin 6 – SH
Headphone Out – RJ-45
The signals are analog stereo; balanced.
Pin 1 – HI
Pin 2 – LO
Pin 3 – HI
Pin 6 – LO
Pin 1 – HI
Pin 2 – LO
Pin 3 – HI
Pin 6 – LO
Digital In – RJ-45
The signal is AES digital.
Pin 1 – HI
Pin 2 – LO
D/A Out – RJ-45
The signal is analog stereo; balanced.
Pin 1 – HI
Pin 2 – LO
Pin 3 – HI
Pin 6 – LO
Bluetooth In / Out – RJ-45
The signals are analog stereo; unbalanced.
Pin 1 – HI
Pin 2 – SH
Pin 3 – HI
Pin 6 – SH
Pin 1 – HI
Pin 2 – SH
Pin 3 – HI
Pin 6 – SH
A L / June 2018
udioArts ightning
I N S T A L L A T I O N A N D P O W E R
USB LT OUT
USB RT OUT
HDPN PRE LT OUT
HDPN PRE RT OUT
HDPN LT OUT
HDPN RT OUT
AES IN
LINE LT OUT
LINE RT OUT
BT LT IN
BT RT IN
BT LT OUT
BT RT OUT
