York PHG6A24 Technical Manual

TECHNICAL GUIDE
SINGLE PACKAGE
HEAT PUMP / GAS HEAT
16 SEER – R-410A – 208/230V - 1 PHASE
2 THRU 5 NOMINAL TONS
50 THRU 125 MBH HEAT INPUT
MODELS: PHG6*24 THRU 60
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.upgnet.com and www.york.com
Additional rating information can be found at:
www.ahridirectory.org
WARRANTY SUMMARY*
Extended 10-Years limited parts and compressor warranty
Lifetime gas heat exchanger warranty with registration.
* Extended warranty requires online registration within 90 days of purchase for
replacement or closing for new home purchase. See limited warranty certificate
in User's Information Manual for details.
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
These packaged duel fuel cooling/gas heating/heat pumps are
designed for outdoor installation. Only utility and duct
connections are required at the point of installation.
FEATURES
• Operating Efficiency - All PHG6 models provide a minimum
AFUE of 81.0% in gas heating and 16.0 SEER, 12.5 or 12.0
EER and 8.2 HSPF ratings for heat pump cooling/heating
operation. All models meet California Low-Nox requirements
of 40 ng/joule emission level for Air Quality Management Dis-
tricts.
• On Site Flexibility - All model sizes use a compact design
cabinet in one of two footprints. This provides installer flexi-
bility for placing the proper capacity unit on curbs or pads
with the smallest footprint after the internal load has been
determined. Field convertible duct connections from side
shot to down shot allows the installer to have greater flexibil-
ity with less inventory.
• Lower Installation Cost - Installation time and costs are
reduced by easy power and control wiring connections. The
small base dimension means less space is required on the
ground or roof. All units are completely wired, charged with
R-410A refrigerant and tested prior to shipment. Test sta-
tions using a state-of-the-art computerized process system
are used to insure product quality. Refrigerant charge and
component part numbers are verified via computers during
assembly. Vital run test statistics such as system pressure,
motor currents, air velocity and temperature, unit vibration,
and gas system safeties are monitored and recorded by the
system to insure unit performance. Equal size side supply
and return duct connections allow easy connection of ducts
to match low crawl spaces without transition pieces.
• Utility Connections Made Easy - Gas and electric utility
access provided through the bottom or the side of the unit.
Utility connections can be made quickly and with a minimum
amount of field labor. A field supplied and field installed elec-
trical disconnect switch must be installed.
• Convertible Airflow Design - The bottom duct openings are
covered when they leave the factory, ready to be used for a
side supply/side return application. If a bottom supply/bottom
return application is desired, simply remove the two panels
from the bottom of the unit and place them in the side supply/
side return duct openings. No panel cutting is required and
no accessory panel is necessary. Convertible airflow design
allows maximum field flexibility and minimum inventory.
• Condensate Pan - A corrosion-resistant, long-lasting, water-
tight pan is positioned below the indoor coil to collect and
drain all condensate, preventing build-up of stagnant con-
densate. The condensate pan conforms to ASHRAE 62-89
standards (Ventilation for Acceptable Indoor Air Quality).
• Condensate Drain - The 3/4 inch NPT female connection is
rigidly mounted to assure proper fit and leak tight seal.
• Durable Finish - The cabinet is made of G90 galvanized
steel with a powder paint coating for appearance and protec-
tion. The pre-treated galvanized steel provides a better paint-
to-steel bond, which resists corrosion and rust creep. Pow-
der paint finish insures less fading when exposed to sunlight,
and provides superior corrosion resistance (1000 hour salt
spray tested).
5331896-YTG-C-1017
Continued on next page.
