Summary of Contents for Abus AZSG10005
- Page 1 AZSG10000/AZSG10005/AZSG10010 ABUS Wired Outdoor Siren Installation instructions and user guide Version 1.0...
-
Page 2: Table Of Contents
Contents Introduction ..................................3 Safety information ................................4 Scope of delivery ................................5 Technical data ..................................5 Features ....................................7 Installation ..................................12 Functions and settings: ..............................15 Maintenance ..................................17 Diagnosis ..................................18 Warranty .................................... 18 Disposal .................................... 19 Declaration of conformity ............................... -
Page 3: Introduction
Everything possible has been done to ensure that the content of these instructions is correct. However, neither the author nor ABUS Security-Center GmbH & Co. KG can be held liable for loss or damage caused by incorrect or improper installation and operation or failure to observe the safety instructions and warnings. -
Page 4: Safety Information
Safety information Safety information Explanation of symbols The following symbols are used in this manual and on the device: Symbol Signal Meaning word Caution Indicates a risk of injury or health hazards. Caution Indicates a risk of injury or health hazards caused by electrical voltage. Importa Indicates possible damage to the device/accessories. -
Page 5: Scope Of Delivery
Quick-start guide Installation material Technical data ABUS Wired Outdoor Siren Product name Sounder Product description AZSG10000 (red), AZSG10005 (orange), AZSG10010 (blue) Item number ABUS Security-Center GmbH & Co. KG Manufacturer IV (EN 50131-1:2006 + A1:2009 Section 7) Environmental class IP43... - Page 6 Technical data EN 50131-1:2006+A1:2009 Standards for intrusion EN 50131-4:2009 and panic button devices R&TTE: 1999/5/EC EU Directives EMC: 2004/108/EC RoHS: 2011/65/EC WEEE: 2012/19/EC EuP: 2005/32/EC Low Voltage: 2006/95/EC General Safety: 2001/95/EC This product must be installed by a qualified service engineer. General...
-
Page 7: Features
This outdoor sounder is an outdoor combination alarm device with siren and flashing light for use with alarm panels. It serves as an optical and acoustic alarm. The sounder and alarm panel communicate via cableways, so fixed wiring is required between the two units. The ABUS Wired Outdoor Sounder is intended for wall installation. - Page 8 Features Device description – Sounder Cover and lid fixing screw Slot for backup battery Mounting holes for wall installation Spirit level Tamper switch Mounting hole for tamper mechanism Acoustic alarm Inner housing Cable inlet...
- Page 9 Features Figure 1: Overview of the sounder...
- Page 10 Features Device description – inner housing LEDs for visual alarm (flashing light) Inner housing battery Battery plug Battery level indicator Battery holder Opening for wires Terminal cover Fixing bracket for terminal cover Drop protection for terminal cover 10 LK1 jumper 11 Terminal block 12 Inner housing screws 13 LED display for supply voltage (comfort LED)
- Page 11 Features Figure 2: Overview of the inner housing...
-
Page 12: Installation
Installation Installation Installing the sounder Step 1: Select installation location for the sounder Select an installation location which: is inaccessible to intruders and vandals. is clearly visible, so that it acts as a strong deterrent. can be reached with cabling. Step 2: Open the sounder’s cover ... - Page 13 Installation Step 4: Pre-configuration via jumper If you would like to change o the siren duration from the default value [3 min.], and/or o the circuit monitoring from the default values, and/or o you would like to set the volume differently to the default value, then: ...
- Page 14 Installation Step 5: Connecting the cable Strip the cable to sufficient length and remove insulation from the individual wires in order to connect these. Remove the cover over the screw terminal on the inner housing by pressing together the lateral terminals upwards and lifting up the cover.
-
Page 15: Functions And Settings
Functions and settings: Functions and settings: General Operation Installer Start-up During the initial start-up, it is possible to plug in the battery without activating the sounder. This means that the sounder can be installed and connected in one process, so that you don’t have to go back to it again later when the supply voltage is applied. - Page 16 Functions and settings: Settings Note: the jumpers [LK2] – [LK9] can only be reached if the inner housing has been opened with two screws (Fig. 2 No 12). [LK1] (Fig. 2 No 10) can be reached by opening the terminal cover. The terminals can all be reached by opening the terminal cover.
-
Page 17: Maintenance
Maintenance [LK6] Intermittent If selected, the siren sounds for a maximum of three passes. 50 sec. ON, 40 sec. OFF, 50 sec. ON, 40 sec. OFF, 50 sec. ON and then stops. (Times approximate) [LK7] 15 min. If selected, the siren sounds for a maximum of 15 minutes. [LK8] 3 min. -
Page 18: Diagnosis
In such cases, the warranty ends when the original warranty period of two years expires. All further claims are expressly rejected. ABUS will not be held liable for defects and damage caused by external influences (e.g. transport, use of force, operating errors), inappropriate use, normal wear and tear or failure to observe the instructions in this manual. -
Page 19: Disposal
Declaration of conformity ABUS Security-Center GmbH & Co. KG hereby declares that the device with item number AZSG100XX complies with the essential requirements and other relevant provisions of Directives 2011/65/EC, 2014/30/EC. The declaration of conformity can be obtained from the following address: ABUS Security-Center GmbH &...
