  • Page 2 GRAPHIC EQ MQ 3229 3229...

  • Page 3: Table Of Contents

    PCB-PART LIST..........12 MISCELLAN OUS ITEMS ......17 POWER REQUIREME T CLASSIFICATION ...20 DIME SIONS ..........21 Phonic reserves the right to improve or alter any information supplied within this document without prior notice. V2.1 08/29/02 MQ 3229 SERVICE MANUAL Page 2 PHONIC CORPORATION...

  • Page 4: Panel Layout

    PANEL LAYOUT MQ 3229 SERVICE MANUAL PHONIC CORPORATION Page 4 Page 3...

  • Page 5: System Block Diagram

    SYSTEM BLOCK DIAGRAM SYSTEM BLOCK DIAGRAM MQ 3229 SERVICE MANUAL PHONIC CORPORATION Page 4 Page 4...

  • Page 6: Main Board Pcb

    MAIN BOARD PCB-FRONT MAIN BOARD PCB-FRONT PHONIC CORPORATION MQ 3229 SERVICE MANUAL Page 5...
  • Page 7 R137 R125 R129 R126 R130 C113 C115 U102 R128 R132 R124 R120 C109 C111 R118 R122 R117 R121 R109 R113 R114 R110 C105 C107 U101 R112 R116 R106 R105 R101 R102 C160 PHONIC CORPORATION MQ 3229 SERVICE MANUAL Page 6...
  • Page 8 REAR BOARD PCB REAR BOARD PCB 7805 7815 7915 PHONIC CORPORATION MQ 3229 SERVICE MANUAL Page 7...
  • Page 9 SWITCH & IN/ OUT SCHEMATICS SWITCH & IN/ OUT SCHEMATICS SWITCH SCHEMATICS IN/OUT SCHEMATICS PHONIC CORPORATION MQ 3229 SERVICE MANUAL Page 8...

  • Page 10: Ch1/2-29 Band(1) Schematics

    CH1/2-29 BAND(1) SCHEMATICS CH1/2-29 BAND(1) SCHEMATICS MQ 3229 SERVICE MANUAL PHONIC CORPORATION Page 4 Page 9...

  • Page 11: Ch1/2-29 Band(2) Schematics

    CH1/2-29 BAND(2) SCHEMATICS CH1/2-29 BAND(2) SCHEMATICS PHONIC CORPORATION MQ 3229 SERVICE MANUAL Page 10...

  • Page 12: Power Supply Schematics

    POWER SUPPLY SCHEMATICS POWER SUPPLY SCHEMATICS PHONIC CORPORATION MQ 3229 SERVICE MANUAL Page 11...

  • Page 13: Pcb-Part List

    CHIP RES. 19.1K F 0603 R103.113.143.153.183.193 008-23722-400-0 CHIP RES. 23.7K F 0603 R134.174.214 008-24912-400-0 CHIP RES. 2.49K F 0603 R107.117.147.157.187.197 008-30122-400-0 CHIP RES. 30K1 F 0603 R138.178 008-31602-400-0 CHIP RES. 316 F 0603 PHONIC CORPORATION MQ 3229 SERVICE MANUAL Page 12...
  • Page 14 CHIP RES. 15K J 0805 R135.175.215.229 008-01542-600-0 CHIP RES. 150K J 0603 R223.224 008-02032-600-0 CHIP RES. 20K J 0603 R219.220.233 008-02232-600-0 CHIP RES. 22K J 0603 R217.218.221.222 008-02732-600-0 CHIP RES. 27K J 0603 PHONIC CORPORATION MQ 3229 SERVICE MANUAL Page 13...
  • Page 15 CHIP C/C 0.1MF K 50V 0805 C171 039-10606-900-0 CHIP E/C 10MF M 16V 4*4.5 C163.164.166.169.170.173 039-22606-900-0 CHIP E/C 22MF M 16V 4*5.4 C119-138 039-33325-220-0 CHIP C/C 0.033MF K 50V 0603 +/-10% PHONIC CORPORATION MQ 3229 SERVICE MANUAL Page 14 Page 4...
  • Page 16 CF RES. 10K J 0.0625W T R2.13 000-22206-400-0 CF RES. 2K2 J 0.0625W T 000-33306-400-0 CF RES. 33K J 0.0625W T R5.16 000-33406-400-0 CF RES 330K J 0.0625W Y 000-47406-400-0 CF RES. 470K J 0.0625W T PHONIC CORPORATION MQ 3229 SERVICE MANUAL Page 15...
  • Page 17 E/C 22MF Z 16V 5*11 T 030-47638-0A0-0 E/C 47MF Z 25V 6.3*11 T C9.16 042-22124-050-0 C/C2 220PF J 50V 5 T C10.11.17.18 046-68204-060-0 M/C 0.0068MF J 50V 5 T 290-03170-200-0 PCB MQ3229 (B) REAR MQ 3229 SERVICE MANUAL PHONIC CORPORATION Page 16...
  • Page 18 S/SW KNOB AA073229 BLACK VR BRACKET 550-20037-520-0 CHASSIS MQ3229 551-60016-000-0 LITTLE BRACKET PPC1100/1200 SECC 551-60028-100-0 LF/RT BRACKET 551-60029-200-0 R/FRAME BRKT 551-60047-200-0 L/FRAMER BRKT 552-20052-420-0 PCB FIXED 552-20053-300-0 FIXED MQ3229 560-20900-201-0 CARTON MQ3229 SIZE:585*332*465 A=B MQ 3229 SERVICE MANUAL PHONIC CORPORATION Page 17...
  • Page 19 L &L-LIB*2 R FRAME&BACK*2 L FRAME&BACK*2 RCA/J*2 591-43008-200-0 T/P PAN SCR. D3.0*8 BLK EARTH BOSS*1 600-00602-010-0 HEX. NUT M6.0*2.0 NI 610-00301-516-0 FIBER WAS. D3.0*D8.0*1.5 611-20006-000-0 EQ/VR SPRING 611-20007-000-0 S/SW SPRING MQ 3229 SERVICE MANUAL PHONIC CORPORATION Page 18 Page 4...
  • Page 20 511-20570-200-F BACK PANEL MQ3229 516-20410-200-F TOP COV MQ3229 517-20510-201-F BOT COV MQ3229 551-60016-000-F LITTLE BRKT PPC1100/1200 PMX2300 PCR2213 551-60028-100-F FL/RT BRKT MQ3229 551-60029-100-F R FRAME BRKT MQ3229 551-60047-100-F L FRAMEL BRKT MQ3229 MQ 3229 SERVICE MANUAL PHONIC CORPORATION Page 19...
  • Page 21 070-20448-800-0 X'MER AC115/230V 280-3E065-000-0 FUSE T315MA 250V SMK S 370-11010-821-0 P/CORD 240V10A 6F 3P SAA 070-20448-800-0 X'MER AC115/230V 280-50161-000-0 FUSE 0.5A 250V UL S 370-08010-721-0 P/CORD 120V 10A 6F 3PUL/CSA MQ 3229 SERVICE MANUAL PHONIC CORPORATION Page 20 Page 4...
  • Page 22 DIMENSIONS DIMENSIONS 430.00/16.93 428.00/16.85 482.00/18.98 Measurement are shown in mm/inch. MQ 3229 SERVICE MANUAL PHONIC CORPORATION PHONIC CORPORATION Page 16 Page 21...
