DSL-245GR
PPTP + Static IP or L2TP + Static IP: Enter authorization data provided by
your ISP (the username (login) in the Username field and the password in
the Password field). Click the Show icon (
password. If authorization is not required, select the Without authorization
checkbox. In the VPN server address field, enter the IP or URL address of
the PPTP or L2TP authentication server. Also fill in the following fields: IP
address, Subnet mask, Gateway IP address, and DNS IP address.
2. If your ISP uses MAC address binding, select the Clone MAC address
of your device checkbox.
If the Internet access is provided via a VLAN channel, select the Use
3.
VLAN checkbox and fill in the VLAN ID field.
4. Click the NEXT button.
Quick Installation Guide
) to display the entered
