D-Link DSL-245GR Quick Installation Manual page 21

DSL-245GR
Wi-Fi Client
This configuration step is available for the Wi-Fi mode.
1. On the Wi-Fi Сlient page, click the WIRELESS NETWORKS button
and select the network to which you want to connect in the opened
window. When you select a network, the Network name (SSID) and
BSSID fields are filled in automatically.
If you cannot find the needed network in the list, click the UPDATE LIST
icon ( ).
2. If a password is needed to connect to the selected network, fill in the
relevant field. Click the Show icon (
password.
If you connect to a hidden network, select the band where the hidden network
operates from the Frequency band list and enter the network name in the
Network name (SSID) field. Then select a needed value from the Network
authentication list and then, if needed, enter the password in the relevant
field.
3. Click the NEXT button.
Quick Installation Guide
) to display the entered
21
