- Page 1 MIC-3037 1U high 2-slot CompactPCI enc/osure...
- Page 2 All other product names or trademarks are properties of their respective owners. CE Notification The MIC-3037, developed by Advantech Co., Ltd., has passed the CE test for environment specifications when shielded cables are used for external wiring. We recommend the use of shielded cables.
- Page 3 MIC-3037 User's Manual...
- Page 4 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 5 If any of these items are missing or damaged, contact your distributor or sales representative immediately. Technical Support and Sales Assistance If you have any technical questions about the MIC-3037 or any other Advantech products, please visit our support website at: • http://www.advantech.com.tw/support...
-
Page 6: Table Of Contents
1.4 Dimensions ................... 5 1.5 Ordering Information ..............6 2. Installation ................7 2.1 Initial Inspection ................8 2.2 The MIC-3037 Illustration ............9 2.3 Installation Procedures .............. 10 2.3.1 Card Installation and Removal ............10 2.3.2 Before Operating the System ............12 3. - Page 7 A.5 Peripheral Slot P2 Connector ........... 28 A.6 Alarm Board Interface Connector (CN3) ........29 A.7 Fan Module Connectors (FAN 1~4) ........... 29 A.8 ATX Power Connector (ATX1) ..........30 A.9 Power Switch Connector (JP2) ..........30 MIC-3037 User's Manual...
- Page 8 Figures Figure 1-1: MIC-3037 dimensions ..............5 Figure 1-2: Inside View of MIC-3037 and MIC-3377/M ........6 Figure 2-1: Front view of MIC-3037 ..............9 Figure 2-2: Rear view of MIC-3037 ..............9 Figure 2-3: Installing a card into the chassis ..........11 Figure 3-1: Slot numbering of the backplane ..........
- Page 9 Table A-1: System slot P1 connector ............24 Table A-2: System slot P2 connector ............25 Table A-3: System slot P3 connector ............26 Table A-4: Peripheral slot P1 connector ............27 Table A-5: Peripheral slot P2 connector ............28 MIC-3037 User's Manual...
-
Page 10: General Information
General Information Chapter 1 General Information... -
Page 11: Introduction
2-slot backplane, the MIC-3037 supports one single-slot SBC (such as Advantech’s MIC-3377/M) and one single-slot peripheral. The MIC-3037 does not provide the space for any devices because of the increasing demands for the space efficiency on some specific applications, such as CT and networking. Users may use a DOM (Dick On Module) on the CPU board for data storage. -
Page 12: Specifications
1.3 Specifications 1.3.1 General • Construction: Aluminum frame and galvanized sheet steel • 2-slot space (8 TE), including one system slot and one peripleral slot • "Hot swappable” platform complies with PICMG 2.1 R 1.0 Hot Swap Specification • Dimensions (W x H x D, mounting flanges not included): 440 x 44 x 231 mm (17.3"... -
Page 13: Power Supply
• Minumum load: +3.3 V @ 1.0 A, + 5V @ 2 A, +12 V @ 1.0 A • Max output: 185 W for +5V, +3.3 V and +12 V, 110 W for +5 V and +3.3 V • MTBF: 100,000 hours @ 70% load • Safety: UL/CUL/CE/FCC MIC-3037 User's Manual... -
Page 14: Dimensions
1.4 Dimensions Figure 1-1: MIC-3037 dimensions Chapter 1 General Information... -
Page 15: Ordering Information
• MIC-3377/M: Single-slot 6U CompactPCI Pentium III processor board with VGA and dual LANs ® • MIC-3357: Single-slot 6U CompactPCI Pentium MMX processor board with VGA and three LANs (Available in August 2001) Figure 1-2: Inside View of MIC-3037 and MIC-3377/M MIC-3037 User's Manual... -
Page 16: Installation
Installation Chapter 2 Installation... -
Page 17: Initial Inspection
It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the MIC-3037, check it for signs of shipping damage (damaged box, scratches, dents, etc.). If it is damaged or fails to meet specifications, notify our service department or your local representa- tive immediately. -
Page 18: The Mic-3037 Illustration
2.2 The MIC-3037 Illustration The MIC-3037 is designed to be installed and maintained easily. Figure 2-1 and Figure 2-2 illustrate important components on the front and rear side of the enclosure. Power On/Off Rack Mount bracket Peripheral Slot System Slot... -
Page 19: Installation Procedures
3. Insert the card into the chassis by sliding the both edges of the card into the card guides. 4. Push the card into the slot gently by sliding the card along the card guide until the handles meet the rectangular holes of the cross rails. MIC-3037 User's Manual... -
Page 20: Figure 2-3: Installing A Card Into The Chassis
Note: If the card is correctly positioned and has been slid all the way into the chassis, the handles should match the rectangular holes. If not, remove the card from the card guide and repeat step 3 again. Do not try to install a card by forcing it into the chassis. -
Page 21: Before Operating The System
Before operating your system, first check your power supply source. Adjust the switch on the power supply to the correct voltage. Two mounting flanges are included for users who would like to install the MIC-3037 on a 19" rack. MIC-3037 User's Manual... -
Page 22: Backplane
Backplane... -
Page 23: General Information
This backplane is used for the 1U-high CompactPCI enclosures, MIC-3035 and MIC-3037, and provides two CompactPCI slots. One slot is assigned to the CPU board and the other slot to one peripheral board. The MIC-3037 supports front I/O wiring, providing simplified system cabling. -
Page 24: Specification
3.3 Specification • Two CompactPCI slots (one system slot and one peripheral slot) • Bus width: 64-bit • 8-layer PCB, 3.0 mm thick • Power connector: One ATX power connector for connecting standard ATX power supply • Complies with CompactPCI Specification PICMG 2.0, Ver.3.0 •... -
Page 25: Slot Assignments
Appendix A gives the pin assignment for all the connectors on the backplane. System Slot 2, (Logical Slot 1): Peripheral Slot 1, (Logical slot 2) CLK0 P1:D6 P1:D6 AD28 P1:C7 IDSEL P1:B9 REQ3# P2:E2 REQ# P1:A6 GNT3# P2:C3 GNT# P1:E5 Table 3-1: System to peripheral slot signal assignment MIC-3037 User's Manual... -
Page 26: Figure 3-1: Slot Numbering Of The Backplane
CompactPCI 64-bit CompactPCI 32-bit Figure 3-1: Slot numbering of the backplane Chapter 3 Blackplane... -
Page 27: Connector And Jumper Locations
ATX power connector 1 FAN 1~4 Fan module connectors Alarm board interface connector Figure 3-2: The connector and jumper locations on the front side FAN4 FAN3 ATX1 FAN2 FAN1 Figure 3-3: The connector and jumper locations on the rear side MIC-3037 User's Manual... -
Page 28: Alarm Board Interface (Cn3)
3.5.4 Screw terminal for external power supply Along the upper and lower edges of the backplane are 4 power pads providing external power supply I/O. These 4 pads facilitate input or output of powers and grounds. Contact Advantech for installation help. Chapter 3 Blackplane... -
Page 29: Clock Routing Configuration
If users would like to reconfigure the backplane to comply with the earlier CompactPCI Specification, PICMG 2.0, version 3.0, which allows the backplane to be backward compatible with CPUs using shared clocks, please contact Advantech for help. MIC-3037 User's Manual... -
Page 30: Pin Assignments
Pin Assignments... -
Page 31: System Slot P1 Connector
A.1 System Slot P1 Connector Table A-1: System slot P1 connector REQ64# ENUM# 3.3V AD[1] V(I/O) AD[0] ACK64# 3.3V AD[4] AD[3] AD[2] AD[7] 3.3V AD[6] AD[5] 3.3V AD[9] AD[8] M66EN C/BE[0]# AD[12] V(I/O) AD[11] AD[10] 3.3V AD[15] AD[14] AD[13] SERR# 3.3V C/BE[1]# 3.3V... -
Page 32: System Slot P2 Connector
A.2 System Slot P2 Connector Table A-2: System slot P2 connector 22 GND 21 GND CLK6 20 GND CLK5 19 GND 18 GND BRSVP2A18 BRSVP2B18 BRSVP2C18 GND BRSVP2E18 GND 17 GND BRSVP2A17 PRST# REQ6# GNT6# 16 GND BRSVP2A16 BRSVP2B16 DEG# GND BRSVP2E16 GND 15 GND BRSVP2A15 FAL#... -
Page 33: System Slot P3 Connector
A.3 System Slot P3 Connector Table -3: System slot P3 connector Pin Z 19 GND 18 GND 17 GND 16 GND 15 GND 14 GND 13 GND 12 GND 10 GND MIC-33037 User's Manual... -
Page 34: Peripheral Slot P1 Connector
A.4 Peripheral Slot P1 Connector Table A-4: Peripheral slot P1 connector REQ64# ENUM# 3.3V AD[1] V(I/O) AD[0] ACK64# GND 3.3V AD[4] AD[3] AD[2] AD[7] 3.3V AD[6] AD[5] 3.3V AD[9] AD[8] M66EN C/BE[0]# GND AD[12] V(I/O) AD[11] AD[10] 3.3V AD[15] AD[14] AD[13] SERR# 3.3V... -
Page 35: Peripheral Slot P2 Connector
A.5 Peripheral Slot P2 Connector Table A-5: Peripheral slot P2 connector Pin Z 22 GND 21 GND 20 GND 19 GND 18 GND BRSVP2A18 BRSVP2B18 BRSVP2BC18 GND BRSVP2E18 GND 17 GND BRSVP2A17 16 GND BRSVP2A16 BRSVP2B16 GND BRSVP2E16 GND 15 GND BRSVP2A15 NRSV 14 GND AD[35]... -
Page 36: Alarm Board Interface Connector (Cn3)
A.6 Alarm Board Interface Connector (CN3) Assignment SDA_EXT SCL_EXT 12~18 19~20 21~30 A.7 Fan Module Connectors (FAN 1~4) Assignment +12 V Appendix A Pin Assignments... -
Page 37: Atx Power Connector (Atx1)
A.8 ATX Power Connector (ATX1) Signal +3.3V +3.3V #FAL +12V +3.3V -12V #PSON A.9 Power Switch Connector (JP2) Signal #PSON MIC-33037 User's Manual...
