- Page 1 User Manual Cordless Reciprocating Saw · 20V Lithium-Ion Battery Manual del Usuario Cordless Reciprocating Saw 20V LITHIUM-ION BATTERY Spanish Spanish Spanish CON BATERÍA DE IONES DE LITIO DE 20V English..1 Español..20 AFTER SALES SUPPORT 1866 902 9690 support@merotecusa.com...
-
Page 2: Table Of Contents
Cordless Reciprocating Saw · 20V Lithium-Ion Battery Contents Getting started..............Safety symbols..............Safety instructions.............. Parts list................Technical data ..............Assembly................Operation................Cleaning, maintenance and storage........ Troubleshooting ..............AFTER SALES SUPPORT 1866 902 9690 support@merotecusa.com... -
Page 3: Getting Started
Cordless Reciprocating Saw · 20V Lithium-Ion Battery Getting Started Carefully remove the machine from its packaging. Identify all the parts packaged in the carton against the parts list. Remove all protective materials and place parts on a non-abrasive sur- face to avoid scratching. Please contact our customer service center (Monday-Friday 8:30AM- 5:00PM ET) at 1-866-902-9690. -
Page 4: Safety Symbols
Cordless Reciprocating Saw · 20V Lithium-Ion Battery Safety Symbols Safety Symbols Some of these following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely. -
Page 5: Safety Instructions
Cordless Reciprocating Saw · 20V Lithium-Ion Battery Safety Instructions Safety Instructions General Power Tool Safety Warnings WARNING! Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term ″power tool″... - Page 6 Cordless Reciprocating Saw · 20V Lithium-Ion Battery Safety Instructions Do not overreach. Keep proper footing and balance at all times. This enables better control ● of the power tool in unexpected situations. Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves ●...
- Page 7 Cordless Reciprocating Saw · 20V Lithium-Ion Battery Safety Instructions for one type of battery pack may create a risk of fire when used with another battery pack. Use power tools only with specifically designated battery packs. Use of any other battery ●...
- Page 8 Cordless Reciprocating Saw · 20V Lithium-Ion Battery Safety Instructions The battery Charger gets hot during use. The Charger’s heat can build up to unsafe levels and create a fire hazard if it does not receive adequate ventila- tion, due to an electrical fault, or if it is used in a hot environment. Do not place the Charger on a flammable surface.
- Page 9 Cordless Reciprocating Saw · 20V Lithium-Ion Battery Safety Instructions 13. The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this prod- uct, but must be supplied by the operator.
- Page 10 Cordless Reciprocating Saw · 20V Lithium-Ion Battery Safety Instructions Grounding WARNING! To prevent electric shock and death from incorrect grounding wire connection: Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. Do not modify the power cord plug provided with the Charger.
- Page 11 Cordless Reciprocating Saw · 20V Lithium-Ion Battery Safety Instructions Charging procedure IMPORTANT: The battery pack is not fully charged at the factory. Before attempting to charge them, thoroughly read all of the safety instructions. (1) To assure that the charger you use are applicable to the battery pack. (2) Plug the charger plug into the charging hole of the battery pack.
- Page 12 Cordless Reciprocating Saw · 20V Lithium-Ion Battery Safety Instructions rence and does not indicate a problem. 4. If the batteries do not charge properly—(1) Check current at receptacle by plugging in a lamp or other appliance. (2) Check to see if receptacle is connected to a light switch which turns power off when you turn out the lights.
-
Page 13: Parts List
Cordless Reciprocating Saw · 20V Lithium-Ion Battery Parts List Application The reciprocating saw is designed for cutting wood, plastics and metals. It is for domestic use only, not for commercial, industrial or trade use. Parts List Fig.A 1. Saw blade 4. -
Page 14: Technical Data
(Monday-Friday 8:30AM-5:00PM ET) at 1866 902 9690. Technical Data Model number 55903 Rated voltage 20V d.c. No load speed 0-3000 Battery Workzone 20V 1.5Ah Lithium-Ion 2.56 in (65 mm), wood Cutting capacity 0.24 in (6 mm), metal AFTER SALES SUPPORT 1866 902 9690 support@merotecusa.com... -
Page 15: Assembly
Cordless Reciprocating Saw · 20V Lithium-Ion Battery Assembly Assembly 1 Install/remove the battery Insert the battery into the reciprocating saw as Fig. 1. Make sure that the battery is clicked into the locked position. To remove the battery, depress the release button on the battery and push the battery out at the same time. -
Page 16: Operation
Cordless Reciprocating Saw · 20V Lithium-Ion Battery Operation 3 Change the position of the pivot shoe Loosen the two cap screws at the bottom of the front handle with the hex key provided. (Fig. 4) Move the pivot shoe (2) in or out to the position required. -
Page 17: Cleaning, Maintenance And Storage
Cordless Reciprocating Saw · 20V Lithium-Ion Battery Cleaning, maintenance and storage 3 Plunge cutting Clearly mark the line of cut. Choose a convenient starting point inside the area to be cut out. Place the tip of the blade over that point. Rest the pivot shoe on the workpiece and hold firmly in position. -
Page 18: Troubleshooting
Cordless Reciprocating Saw · 20V Lithium-Ion Battery Troubleshooting Disposal Dispose electrical appliances according to the regulations and requirements of your local council. If electrical appliances are disposed in landfills or dumps, hazardous substances may leak into the ground water and get into the food chain, damaging your health and well-being. - Page 19 Cordless Reciprocating Saw · 20V Lithium-Ion Battery DISTRIBUTED BY ∙ DISTRIBUIDO POR: ALDI INC., BATAVIA, IL 60510 www.aldi.us AFTER SALES SUPPORT • SERVICIO POSVENTA support@merotecusa.com 1866 902 9690 AFTER SALES SUPPORT MODEL: PT160501 PRODUCT CODE: 55903 06/2018 YEAR WARRANTY 1866 902 9690 support@merotecusa.com AÑOS DE GARANTÍA...
