User manual - English
Manual de usuario - Español
Mode d'emploi - Français
Cooler
Model series 9192 / 9468 / 9469 Order number 33 0916 8900 Version 01.2010
1-28
29-56
57-84
Countertop cooler
Model series 9192
Under-machine cooler
Model series 9468
coffee wakes up the world
User Manual
Under-machine cooler
Model series 9469
Under-counter cooler
Model series 9469
North America English
Advertisement
Table of Contents
Related Manuals for WMF 9192 Series
Summary of Contents for WMF 9192 Series
- Page 1 User manual - English 1-28 coffee wakes up the world Manual de usuario - Español 29-56 Mode d’emploi - Français 57-84 User Manual Countertop cooler Under-machine cooler Model series 9192 Model series 9469 Under-machine cooler Under-counter cooler Model series 9468 Model series 9469 Cooler North America English...
-
Page 2: Chapter 1 Introduction And General Information
Risk of fire or electric shock. Failure to follow safety warnings can lead to serious Do not remove cover. injury. No user-serviceable parts inside. See chapter 5.1: Safety. Repair should be done by authorized service personnel only. Instruction Cross reference User manual for WMF cooler... - Page 3 Introduction and General information Congratulations on choosing your WMF cooler You will be impressed by its technical design and durability. The countertop cooler can hold one 1-gallon and one CaUtIoN ½-gallon US jug, instead of the milk container. Read and...
-
Page 4: Table Of Contents
Two milk types ........... . . 16 2/3.4 Low-level warning display 2/3.5 Switch off the cooler 2/3.6 adjust temperature Chapter 3 Care Cleaning the milk container/milk hose Cleaning the inside of the cooler Defrosting the cooler User manual for WMF cooler... - Page 5 Conditions for usage and installation Chapter 6 Malfunctions Chapter 7 accessories and spare parts Spare parts for countertop coolers 9192 Spare parts for under-machine cooler 9468 Spare parts for under-machine cooler/under-counter cooler 9469 User manual for WMF cooler...
-
Page 6: Chapter 1/1 Parts Of The Countertop Cooler
On / Off switch Milk jug, milk type 1 Front door with seal (Example) Milk jug, milk type 2 (Example) Hose outlet to the machine Universal standpipe Door lock (optional, not shown) Plug&Clean adapter with hose User manual for WMF cooler... -
Page 7: Chapter 2/1 Countertop Cooler Operation 9192
The switch lights up in green. The cooler reaches operating temperature after about 60 minutes. • The cooler keeps the milk cool but cannot cool down hot milk. • Always use milk that is already cool. User manual for WMF cooler... -
Page 8: 2/1.3 Filling The Milk Container
The blue milk hose is for milk type 2 (e.g. Skim milk). ™ Place milk jug in the cooler ™ Close cooler door • The milk nozzle is placed on the milk foamer on the machine. • Do not kink the milk hose. User manual for WMF cooler... -
Page 9: 2/1.5 Low-Level Warning (Optional)
-> colder turn counterclockwise -> warmer * A quarter turn is about 2K. * The stop for the warmest setting has a slight detent. Turning past the detent will switch off the machine. User manual for WMF cooler... -
Page 10: Chapter 1/2 Parts Of The Under-Machine Cooler
Low-level warning, milk type 2 (optional) Door lock Plug & Clean sockets (optional, not shown) (optional) Plug&Clean adapter with hose Cover (optional) Milk container with lid, milk type 1 Optional with low-level warnings in the cooler User manual for WMF cooler... -
Page 11: Chapter 2/2 Under-Machine Cooler Operation 9468
The switch lights up in green. The cooler reaches operating temperature after about 60 minutes. • The cooler keeps the milk cool but cannot cool down hot milk. • Always use milk that is already cool. User manual for WMF cooler... -
Page 12: 2/2.3 Filling The Milk Container
When the low-level is reached, the empty warning on the cooler lights up for that milk type. ™ Fill the corresponding milk container (see Chapter 2 / 2.3) The low-level warning goes out. Keep the interior of the cooler dry. This prevents malfunctions. User manual for WMF cooler... -
Page 13: 2/2.5 Low-Level Warning Display
™ Remove the cap on the back of the cooler turn clockwise -> colder turn counterclockwise -> warmer * A quarter turn is about 2K. * The stop for the warmest setting has a slight detent. Turning past the detent will switch off the machine. User manual for WMF cooler... -
Page 14: Chapter 1/3 Parts Of The Under-Machine/Under-Counter Cooler
(Open front door) Door with door seal Milk container with lid, milk type 1 Hose outlet to the machine Milk container with lid, milk type 2 (optional Door lock Plug&Clean sockets (under-machine cooler) (optional, under-counter cooler) User manual for WMF cooler... -
Page 15: Chapter 2/3 Under-Machine/Under-Counter Cooler Operation 9469
The switch lights up in green. The cooler reaches operating temperature after about 60 minutes. • The cooler keeps the milk cool but cannot cool down hot milk. • Always use milk that is already cool. User manual for WMF cooler... -
Page 16: 2/3.3 Filling The Milk Container
™ Close the front door • Do not kink the milk hoses. • Milk type 1 is always on the right. • The shift button in the display of the machine always switches to milk type 2 (left). User manual for WMF cooler... -
Page 17: 2/3.4 Low-Level Warning Display
™ Remove the cap on the back of the cooler turn clockwise -> colder turn counterclockwise -> warmer * A quarter turn is about 2K. * The stop for the warmest setting has a slight detent. Turning past the detent will switch off the machine. User manual for WMF cooler... -
Page 18: Chapter 3 Care
™ Close door Observe the manual. Do not kink the milk hose. Cleaning the inside of the cooler ™ Stir 5 ml of the WMF special cleaner CaUtIoN (order no. 33 0683 6000) from the measuring bottle Hazard to the into a bucket containing 17 oz (0.5 l) of lukewarm health. -
Page 19: Defrosting The Cooler
Chapter 4 Safety Hazard to the operator At WMF, safety is one of the most essential product features. The effectiveness of safety devices can only be ensured if the following points are observed: • Read the user manuals carefully prior to use. -
Page 20: Hazard To The Device
• After a break in operation of several weeks we recommend thorough cleaning. • If the cooler was not transported in a standing position then it must be given at least 2 hours to stand in a vertical position before switching on. User manual for WMF cooler... -
Page 21: Directives
(National Electrical Code). Duties of the owner/operator The operator of such devices must ensure regular servicing by WMF customer service technicians, their agents or other authorized persons and checking of safety devices. Access to the service area is permitted only for persons with knowledge and practical experience with the unit, especially regarding safety and hygiene. -
Page 22: Warranty Claims
• For malfunctions due to the effect of the weather, chemical, electrochemical or electrical effects, unless attributable to a fault on the part of WMF. • If malfunctions occur as a result of failure to follow handling instructions and regulations, maintenance and care of the unit (e.g., user manuals and maintenance... -
Page 23: Chapter 5 Technical Data
48.5 lbs about 48,5 lbs about 48,5 lbs (16,5 kg) (22 kg ) (22 kg) (22 kg) We reserve the right to make technical modifications. For special models see model label, values given above are for the basic model. User manual for WMF cooler... -
Page 24: Conditions For Usage And Installation
The work must be carried out by authorised installation technicians in compliance with general, country-specific and local regulations. The WMF service engineers may only connect the machine to existing prepared connection points. WMF Customer Service is neither authorized nor responsible for carrying out any work on-site prior to connection. -
Page 25: Chapter 6 Malfunctions
• Interior of cooler iced over or wet -> defrost • Wrong milk container -> Use original container • Wrong milk jugs Empty message is permanent up • Wrong container • Filled container positioned incorrectly User manual for WMF cooler... -
Page 26: Chapter 7 Accessories And Spare Parts
Hose guide screw 33 2142 2200 Hose guide nut 33 9510 0000 meter Milk hose (transparent) 00 0048 4948 meter Milk hose (blue), milk type 2 00 0048 4946 bottle Milk cleaner 33 0683 6000 User manual for WMF cooler... -
Page 27: Spare Parts For Under-Machine Cooler/Under-Counter Cooler 9469
