- Page 1 User Manual WMF Syrup Station Accessories English Compatible with coffee machines 5000 S | 1500 S+ | 5000 S+ | 9000 S+ Series 9023 33 4193 8000 03.2018...
-
Page 2: Introduction And General Information
Technical Data chapter, Maintenance w User Manual coffee machine no liability is accepted for any resultant damage. > Follow the User Manual. > Maintenance and repair work may be performed only by the WMF Service-Center, using original spare parts. User Manual WMF Syrup Station... -
Page 3: Table Of Contents
Service and addresses Messages and instructions Error messages and malfunctions Safety and warranty Hazard to the device Directives Duties of the owner / operator Warranty claims Appendix: technical data technical data for syrup station Appendix: Accessories and spare parts User Manual WMF Syrup Station... -
Page 4: Safety
> Follow all the safety instructions. general safety instructions Hazards to the operator At WMF, safety is one of the most essential product features. The effectiveness of the safety devices can only be ensured if the following points are observed: >... - Page 5 > Children may not play with the device. > Cleaning and user maintenance must not be performed by children. User Manual WMF Syrup Station...
- Page 6 > Avoid damage to the power cord. Do not kink or crush it. > Never immerse the mains plug in water or other liquids, or pour water or other liquids over the mains plug. Always keeps the mains plug dry. User Manual WMF Syrup Station...
- Page 7 > Regularly check whether the coffee machine is leaking, and make sure no water is coming out. > Always use the cleaning set for cleaning in order to prevent liquids from escaping. > Always lock the adapters correctly. User Manual WMF Syrup Station...
- Page 8 All laws regarding the serving of alcoholic beverages must be followed. This means that alcoholic beverages may not be provided in self-service mode. Health hazard / hygiene CAUtIon • Do not use any liquids that need to be chilled. User Manual WMF Syrup Station...
-
Page 9: Intended Use
> The syrup station may be used only as intended. The WMF syrup station is intended for metering syrup as an additive when preparing beverages with a WMF coffee machine. This machine is intended for use in hotels, restaurants, and similar locations. The machine may be installed in self-service areas if a responsible person is on location while it is being used. -
Page 10: Conditions For Use And Installation
The work must be carried out by authorised installation technicians in compliance with general, country- specific and local regulations. The WMF service engineers may only connect the coffee machine to existing prepared connection points. WMF Service is neither authorised nor responsible for carrying out any on-site installation work prior to connection. -
Page 11: Designation Of Parts Of The Device
Designation of parts of the device Designation of parts of the device DI_0009 Raspberry Schnapps Syrup 1 Syrup 4 Syrup 2 Chocolate Syrup 3 Suction connection Syrup station Four Plug&Clean adapters Lockable Removable bottle rack Cleaning set User Manual WMF Syrup Station... - Page 12 Follow the Warranty chapter • for the installation location w starting on page 32 > Always follow the User Manual. Technical data w starting on page 33 note / tip notE • Instructions for safe use and tips for easier operation. User Manual WMF Syrup Station...
-
Page 13: Syrup Station Operation
DI_0001 Dispensing a beverage with syrup ™ Touch a button for a beverage with syrup The desired beverage is dispensed. espresso Café Crème Milk coffee Milk w Beverage recipe with syrup Milk+Choc cappuccino Latte Macchiato Milk foam page 20 User Manual WMF Syrup Station... -
Page 14: Post-Selection Function With Syrup
For example, the amount of the beverage, type of milk, and type of coffee can all be requested one after the other. without syrup Recipes settings w User Manual for the coffee machine Strawberry Banana Hazelnut Syrup 4 PostSelection User Manual WMF Syrup Station... -
Page 15: Postselection - Selecting The Type Of Syrup
Assign metered amounts page 18 “Assign metered PostSelection amounts”. Deactivated metering amounts are greyed out and cannot be selected. 4.4.3 Without syrup If no syrup is desired, then “No syrup” can be selected. Strawberry without syrup Strawberry User Manual WMF Syrup Station... -
Page 16: Configure Syrup Station
™ Connect the syrup bottle to the station using the Syrup 2 Plug&Clean adapter and place the bottle in position ™ Connect the rest of the syrup bottles Chocolate Syrup 3 Syrup filling w page 22 User Manual WMF Syrup Station... -
Page 17: Setting Up The Syrup Station
Up to three metered amounts can be defined. DS_0003 ™ Touch the “System” button in the main menu ™ Touch Syrup Syrup ™ Touch the bottle to be configured Syrup 1 Syrup 2 Syrup 3 Syrup 4 User Manual WMF Syrup Station... -
Page 18: Assign A Name For The Syrup
Each metered amount can be activated or deactivated. Deactivated syrup metering amounts are greyed out in PostSelection mode and cannot be selected. Active Active Active ™ Set the desired metering amounts Confirm value and selection with ™ Confirm the selection User Manual WMF Syrup Station... -
Page 19: Dispensing Test
Sample test Double ™ Touch the “Dispensing test” pad ™ Select which of the 3 metered amounts Sample test Big to dispense here ™ Confirm the selection ™ Save the setting values Deviations of 10–20 % due to differences in viscosity. User Manual WMF Syrup Station... -
Page 20: Configuring Beverages With Syrup
The additions that can be used for the recipe are shown here. ™ Press the desired addition and then touch the desired position in the recipe composition again The addition is immediately inserted at the desired position. User Manual WMF Syrup Station... - Page 21 ™ Set the amount in ml to be added to the beverage Test syrup addition w Test dispensing The syrup can be tested individually again here using page 19 test dispensing. Save recipes The modified recipe is saved. User Manual WMF Syrup Station...
-
Page 22: Activating The Postselection Function
™ Please follow the display instructions for the remaining steps Follow all safety instructions in the user CAUtIon manual. In particular, read and follow the Follow the Safety chapter Safety chapter before using the syrup station. w starting on page 4 User Manual WMF Syrup Station... - Page 23 Adjust the hose length in the bottle ™ Pull the nozzle off of the end of the hose ™ Cut the hose to the correct length ™ Attach the nozzle again User Manual WMF Syrup Station...
-
Page 24: Care
Care Cleaning programs Syrup cleaning w page 25 Clean the syrup hoses Clean the Plug&Clean adapter Clean the syrup station spout Clean the syrup station manually w page 27 User Manual WMF Syrup Station... -
Page 25: Clean The Syrup Station
Otherwise all beverages configured with syrup will be blocked. If the machine is switched off after a syrup cleaning, a note will be displayed as soon as the coffee machine is switched on again. Recommendation: perform syrup cleaning once a day. User Manual WMF Syrup Station... -
Page 26: Syrup Bottle Change
™ Touch “Syrup bottle change” ™ Select the symbol for the bottle to be changed ™ Follow the instructions on the display ™ Perform “Syrup filling” to fill it up again notE Clean the syrup hoses with clear water as needed. User Manual WMF Syrup Station... -
Page 27: Clean The Syrup Station Manually
™ Clean the bottle holder with warm water ™ Clean the syrup station with a clean, damp cloth ™ Clean the inside of the syrup station with a damp cloth ™ Replace the bottle rack ™ Insert syrup bottle User Manual WMF Syrup Station... -
Page 28: Service And Addresses
Service and addresses Service and addresses You can reach WMF Service if the local service point is not known. WMF Group GmbH Eberhardstraße 35 Coffee Machines Export Department D-73312 Geislingen (Steige) Messages and instructions Error messages and malfunctions no syrup • Plug&Clean adapter is not seated properly Wrong syrup • Assignments of syrup to bottles has been mixed up... -
Page 29: Safety And Warranty
• We recommend damage prevention measures: - e.g. installation of smoke alarms. • After shut off for several days we recommend thorough cleaning. User Manual WMF Syrup Station... -
Page 30: Directives
Safety and warranty Directives Manufacturer: WMF Group GmbH, 73312 Geislingen (Germany) The device fulfils the requirements of all applicable regulations in the listed directives. The EC declaration of conformity is included with the device. • Directives MD (MR) 2006/42/EU, • Directive 2014/30/EU, • Directive 2011/65/EU (ROHS), • Directive 2012/19/EU (WEEE). -
Page 31: Duties Of The Owner / Operator
These measures are conducted by WMF Service or by WMF authorised service personnel as part of the maintenance work. The manufacturer's specifications regarding maintenance cycles and frequency of maintenance Maintenance) must be followed. -
Page 32: Warranty Claims
• With respect to the consequences of improper modifications undertaken without the consent of WMF, or by repair or reconditioning work on the part of the purchaser or by third parties. • With respect to faults caused by inappropriate or improper use. -
Page 33: Appendix: Technical Data
Appendix: Technical data Appendix: technical data technical data for syrup station Suitable for 5000 S, 1500 S+, 5000 S+, 9000 S+ External dimensions Width 261 mm Height 530 mm Depth 469 mm Weight empty 16 kg User Manual WMF Syrup Station... -
Page 34: Appendix: Accessories And Spare Parts
33 2942 9000 Universal bottle 33 4193 0000 Syrup bottle hose set 33 2943 0000 Standard base 33 1389 3000 Bottle rack 33 2942 5000 Plug&Clean adapter 33 4201 8000 Feet accessory set 100 mm 33 3320 3000 User Manual WMF Syrup Station... - Page 35 User Manual WMF Syrup Station...
- Page 36 Your nearest WMF Service: © 2018 WMF Group GmbH All rights reserved, in particular duplication, distribution, and translation rights. No part of this manual may be reproduced in any form or processed, duplicated, or distributed using electronic systems without written consent. Design and production / typesetting and print presentation: TecDoc GmbH;...
