Please send to the customer who is used this operation manual without fail.
◆
Thank you very much for purchasing Hot-air generator this time.
◆
Please confirm the model, type, and voltage by the name plate of this machine.
TSK Hot-air generator
･
TSK-18
･
TSK-23, 33
･
TSK-42, 52
･
TSK-52HT
･
TSK-56
･
TSK-62, 72
･
TSK-82
･
TSK-92, 102
･
TSK-122, 132
Hot-air generator
Operation manual
●
Please read without fail before use.
Kansai Electric Heat Corp.
Preservation type
C-type series
Total edition
1. Attention on use
2. Installation
3. Piping
4. Power supply
5. Maintenance inspection
6. Name of every part
7. Service terminal
8. Warning detection
Guarantee
Contents of this operation manual are changed
without notice. The figure and display in the
operation manual does not guarantee actual
specification. We prohibit that changes this
operation manual without taking our permission.
Advertisement
Table of Contents
Summary of Contents for kansai TSK-23
- Page 1 ･ TSK-122, 132 Contents of this operation manual are changed without notice. The figure and display in the operation manual does not guarantee actual specification. We prohibit that changes this operation manual without taking our permission. Kansai Electric Heat Corp.
-
Page 2: Attention On Use
1.Attention on use ※ Please confirm without fail before use. For the hot-air generator is used without malfunctioning ◆ Important matters that demand special attention that became the cause of malfunction that occurred in the past is entered. Please inquire with the use method of your company. ●... -
Page 3: Installation
2. Installation ① Please establish to the horizontal position. Please refer to the figure of the right about the around of inclination. And, please establish to the horizontal position about the right and left. ② Please fix it firmly as occasion demands. 15°... -
Page 4: Maintenance Inspection
5. Maintenance inspection Test button This is such a test button that confirms whether the breaker (NFB) of this machine operates normally at the time of overheat. One time in a month, please continue to push the button for several seconds in operation stoppage condition (Electricity is flowing). - Page 5 6. Name of every part Control panel (All machine type community) ⑫ ⑪ ⑬ ⑦ ⑭ ⑧ ⑨ ② ⑩ ① ④ ⑤ ③ ⑥ ⑮ ⑯ ⑲ ⑱ ⑰ ① ⑩ STOP switch TIMER display This is the stop switch of blow operation and hot-air operation, Setting time of the timer is displayed.
- Page 6 ： MODEL TSK-52 Handle Heatproof blower (Hot-air circulation type) Hot-air outlet Outlet temp. sensor (Thermocouple JISK) Breaker (NFB) Control panel Service terminal ： MODEL TSK-102 Eye bolt Hot-air outlet Heatproof blower (Hot-air circulation type) with demi-filte Outlet temp. sensor (Thermocouple JISK) Power cord Caster Control panel...
-
Page 7: Service Terminal
7. Service terminal ● Service terminal of the input and output is equipped to all types. Please use as occasion demands. 【 】 Type that is used TSK-18, 23, 33, 42, 52, 56 ： Connector for connection of Remote controller This is the connector for connection of remote cable in the case that the remote controller of the option is E. -
Page 8: Input Terminal
【 】 Type that is used TSK-52HT, 62, 72, 82, 92, 102, 122, 132 《 》 ･ Input terminal M3 20P The upper row of the terminal Tightening torque : 0.5N ： External operation ON/OFF terminal This is used in the case that the hot-air generator is operated by the outside signal. - Page 9 Output situation of each output terminal TSK-18, 23, 33, 42, 56, 56 Blow output Temp. alarm Hot-air output Temp. warning Blower warning Overheat output Action of the hot-air generator output terminal output terminal output terminal terminal terminal terminal T. W. T.
- Page 10 ◆ Buzzer sounds at the same time as the warning detection about TSK-52HT, 62 - 132. Even 8. Warning detection buzzer sound stops when warning was canceled by the return method of each warning. 8-1 Overheat Overheat is detected in the case that the inside of the heater case became an abnormal high temp. Or, burnout is detected in the case that the overheat sensor for the temp.
- Page 11 8-2 Temp. warning Hot-air generator is stopped or become blow operation when outlet and inlet temp. exceeded the upper limit, each sensor becomes the burnout by snapping of a wire etc., or the inside temp. of the hot-air generator became warning too. ●...
- Page 12 ● At the time of the burnout of the inlet sensor TEMP. WARN. lamp (Red) is lighted and "---" is flickered to HOT-AIR TEMP., "Tcc" to SETTING TEMP. And, all the operation stop. 《 》 Main cause ・ Snapping of a wire of the inlet sensor ・...
- Page 13 ： ・ TSK-18 Back side of the control panel service terminal ・ ： ・ TSK-23 The inside of the back panel ・ ： ・ TSK-42 The inside of the control panel (Please open the control panel and please confirm.) ：...
-
Page 14: Other Warning
8-4 Other warning ● Frequency warning (Only TSK-52HT, TSK-62 - 132) "SYS" is flickered to HOT-AIR TEMP., "ALM" to SETTING TEMP. in the case that the frequency that is supplied from the primary power supply exceeded ± 3Hz of the ratings. And, all the operation stop. 《... - Page 15 ● At the time of the burnout of the external sensor Hot-air generator is stopped when the external sensor became the burnout of snapping of a wire etc. in the case that the temp. of the place that parted is controlled by using the external sensor of the option. "---"...
- Page 16 Inquiry regarding the hot-air generator ..www.kansaidennetsu.co.jp Homepage sales@kansaidennetsu.co.jp E-mail...
