City Theatrical Multiverse Node 5902 Quick Start Manual

475 Barell Ave., Carlstadt, NJ 07072
Voice: 800-230-9497, 201-549-1160
Fax: 201-549-1161
Antenna
(folded forward)
Mode
Current SHoW ID
or Universe
Clickable Buttons:
Menu, Up Arrow,
Down Arrow, Enter
Part Number
*Note: This power supply connector is not compatible with SHoW Baby.
®
A Multiverse
for use in North America only). It can be set up as a transmitter in a single universe system
broadcasting to one or more other Multiverse Nodes, or it can be set up as a receiver in a
system with a Multiverse Transmitter.
Setting Up a Multiverse Node to Multiverse Node(s) System

Transmitter Setup

1. Install the Multiverse Node you will use as a transmitter in a convenient location where
you can reach it with the DMX cable from your console or controller. For best results,
locate the unit as high in the air as possible to enable it to be clear of obstructions.
Consider where you will put your Multiverse Node receivers and place the Multiverse
Node transmitter where its antenna will be within line of sight with the receivers, if
possible.
USB Port
DMX out
Receiver Mode
Node 900MHz/2.4GHz is a wireless DMX transceiver (this product is licensed
Multiverse
Quick Start Guide

SETUP AND OPERATION:

Signal Quality
(bars)
Locking DC Jack,
5.5mm x 2.1mm,
center positive,
12.1mm mating
depth*
®
Node (5902)
DMX in DMX out
Transmitter Mode
