KAM Soundforce 15A Quick Start Manual page 2

The PC-15A Powered loudspeaker is a very compact, easy to use, plug and play,
music distribution system. It consists of one amplified loudspeaker with a 15 " woofer
and a quality high frequency speaker .
1. MIC VOLUME CONTROL
With this button you can easily set the desired volume of the microphone
2. VOLUME CONTROL
With this button you can easily set the desired volume.
3. TREBLE CONTROL
Herewith you can add or decrease the high frequency. Adding high frequency can
improve the intelligibility. Adjust it to the desired level. In the center position the
sound should be neutral.
4. BASS CONTROL
By adding bass you can add warmth to your music. Decreasing bass can improve the
intelligibility of spoken messages.
5. MIC INPUT
Here you can connect your microphone.
6. LINE INPUT
Here you can connect your sound source. These inputs have to be fed with a music
signal at LINE LEVEL(cd, dve, vhs, tuner, mixing table......)..
7. LINE OUTPUT
These speakon(1+,1-) should be used to free passive
loudspeakers can give bad result and even cause damage to the main
NC unit.
8. ON/OFF
When the AC plug is connected to the mains circuit, you can turn the unit on or off
with this button..
9. MANIS SOCKET
The unit can be branched to the mains circuit by a standard IEC type power cord. This
socket contains a 3A slow blow fuse. Use a screw driver to flip out the fuse
compartment and to replace it. When this fuse blows frequently you should bring the
loudspeaker. Using other
NC to a qualified service center. First check whether you didn't use a quick-blow fuse!
