KAM SF6A Safety Information

SF6A
SAFETY INFORMATION
◆ Read all documentation before operating your equipment. Retain all
documentation for future reference.
◆ Save the carton and packing material even if the equipment has arrived in good
condition.
◆ Do not spill water or other liquids into the unit.
◆ Make sure power outlets conform to the power requirements listed on the back
of the unit.
◆ Do not use the unit if the electrical power cord is frayed or broken.
◆ Always operate the unit with the AC ground wire connected to the electrical
system ground.
◆ Have gain controls on amplifiers or consoles to any other voltage source, such
as a battery, mains source, or power supply, regardless of whether the
amplifier or console is turn on or off.
◆ Power down & disconnect units from mains voltage before making
connections.
◆ Do not use the unit near stoves, heat registers, radiators, or other heat
producing devices.
◆ Do not block fan intake or exhaust ports. Do not operate equipment on a
surface or in an environment which may distort the normal flow of air around
the unit. If the unit is used in an extremely dusty or smoky environment, the
unit should be periodically "blown free" of dust.
◆ Do not remove the cover. Removing the cover will expose you to potentially
dangerous voltages.
◆ Do not drive the inputs with a signal level greater than required to drive
equipment to full output.
◆ Do not run the output of any amplifier back into another input.
◆ Do not ground the red output terminal, never connect a red output terminal to
another red output terminal.
◆ In case of mal-function this device should be serviced by qualified service
personnel only.
TECHNICAL SPECIFICATIONS
Speaker
Rated power:50Wrms
Power [Max]:80W
Bass speaker:6.5"
Speakers:0.75" tweeter
Connections: 2-pole terminal
Sensitivity:89 dB@ 1W/1m
Dimension [H×W×D]: 350×210×205mm
Impedance:8Ohms
Frequency-range:55Hz~20KHz
Amplifier
Power output:50Wrms
Frequency-range:20Hz~20KHz
Equalization:2 bands EQ ±15 dB
Gain:30dB(max)
