Soundforce series
12-12A-15-15A
M A N U A L
V E R S I O N
1 . 0
1 8 / 0 6 / 1 2
Due to continuous product development, please ensure that you have downloaded
the latest instruction manual for this product from the Kam website at www.kam.co.uk
For the latest updates and information on the entire Kam range visit:
www.kam.co.uk
Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ
Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com
Due to continuous product development, specifications and appearance are subject to change. © Copyright Lamba plc 2012. E&OE.
M
A
D
E
I
N
C
H
I
N
A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KAM Soundforce 12
Summary of Contents for KAM Soundforce 12
- Page 1 For the latest updates and information on the entire Kam range visit: www.kam.co.uk Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com...
- Page 2 Thank you for purchasing this Kam product, we are sure that it will serve you for many years to come. To optimise the performance of this product, please read these operating instructions carefully to familiarise yourself with the basic operations of this unit. Please retain them for future reference.This unit has been tested at the factory before being shipped to you.
- Page 3 The Kam Soundforce speaker range is available in passive or active models. Soundforce 12 and Soundforce 15 passive The connection to your soundforce passive is via a speakeron socket. Connect a suitable cable from the output of your amplifier to the input socket on the rear of your Soundforce passive speaker.
- Page 4 Linking It is possible to link one active speaker to another. 1. Connect your signal cable to the active speaker using one of the line in sockets (11) or (12). 2. Connect a lead from one of the line out sockets (8) or (9). 3.
- Page 5 Rear panel Soundforce 15a Mains fused input Power on / off switch Mains voltage selector 115/240v AC iPod / iPhone docking station Power LED Clip LED Master output level XLR Line level output 6.35mm jack line level output Line level input volume control Balanced XLR line level input socket RCA / phono line level inputs Microphone volume level...
- Page 6 Using the docking station 1. Insert your iPod / iPhone into the docking station. 2. Do not force your unit into the docking station but make sure it is located correctly. 3. Ensure the iPod / Mp3 player switch (17) is in the correct position. 4.
- Page 7 Soundforce V2 15 Two way injection moulded passive speaker Power handling @ 8 Ohms: 300w continuous RMS | 600w program power | 1200w peak power Nominal impedance: 8 Ohms High quality woofer and tweeter with crossover 15 inch driver / Steel woofer chassis Tweeter: Ti.Compression / Sensitivity: 97dB -1w/1m Frequency response: 55Hz - 20KHz 3dB Audio input/output/thru connections: Speakeron...
