Controls & Functions
.
-
.
-
~
- -
-
-
Controls
..
-
-
& Functions
.
BASS
BOOST
I%i\
0
+ I 2 6 8
PWR(Power): Thi s G R E E N L E D will illuminate when the amplifier is turned "ON". If it fails
BY usina the bass boost function, bass notes at 50Hz are em~hasized as much as 12dB.
to illuminate, check the power connections to the Amplifier and fuses.
I
LlNE OUT LlNE IN
JJNE@..
LlNE OUT
CH~,.'"'
CHI
.--
C H I
I
power up the amplifier again.
These inputs are for signal cables from the source. Always use high quality shielded
R C A cables.
LlNE OUT LlNE IN
LINE IN
UNEOUT
CH3
CHI
CHI.."-".
.
. a
PROT(h0tection): T h e amplifier protection circuitry will disable the amplifier if input overload.
shod circuit or extremely high temperature conditions are detected. When the protection
mode is in operation, the L E D indicator on the side panel will be illuminated, indicating the
amplifier has gone into a self-preservation mode.
If you observe that the Protection L E D i s lit, please check the system carefully to determine
what has caused the protection clrcuit to engage. T h e amplifier can be reset by turning the
remote power off and then on again. If the amplifier shut down due to a thermal overload
condition, please allow it to cool down before restarting. If the amplifier shut down because
of an input overload or short circuit, be sure to repair these conditions before attempting to
T h e L l N E O U T allows you to build multiple amplifier systems without having to use splitter
cords to distribute the signal. Now it i s simply a matter of bringing one set of R C A S into
the first amplifier, then using the line out R C A jacks as the feed to the next amplifier.
Power
...
! *
+IL~:..
Rnmmtn ~ n m a
I
I
- -
I
Due to the power requirements of the Amplifier, this connection should be made
directly to the positive(+) terminal of battery. For safety measure, install an in-line
fuse Holder (not included) as close to the battery positive(+) terminal as possible with
an ampere rating
;
not to exceed total value of fuses in Amp.
I
r
- - - ,
.
m
Power
I
I
I
I
. .
.....
I
