C h a p t e r 1 : S a f e t y
i n s t ru c t i o n s a n d w a rra n t y
s t a t e m e n t
Safety
34
The ROTEX GasSolarUnit
36
(GSU)/ GasCompactUnit (GCU)
36
is designed exclusively for
36
heating hot water heating systems.
36
36
Carry out all installation, inspection,
maintenance and repair work in line with
38
these instructions. Strictly observe all
40
safety requirements and regulations, to
40
which these instructions refer. Non-
40
observation or incorrect operation can
result in dangerous situations with risks to
41
health, individuals, equipment and the
41
building.
42
Before any work on the heating system,
42
switch OFF the mains electrical isolator
42
and protect against unauthorised
42
reconnection.
42
Any work on the heating system must only
43
be carried out by authorised and
appropriately trained personnel (heating
contractor). Observe all applicable Health
& Safety and accident prevention
49
regulations.
51
51
The electrical installation must only be
51
carried out by an authorised electrician,
who must observe all local and national
regulations. In addition, observe the
requirements specified by the relevant
52
electricity supply company.
Maintain the minimum clearances
towards walls and other objects as
56
detailed in chapter 3.
63
When installing the ROTEX GasSolar-
Unit/GasCompactUnit ensure, that the
and provides a sufficiently sizeable safety
margin. Check the correct installation of
64
the temperature sensor and the pressure
gauge prior to commissioning.
The GasSolarUnit/GasCompactUnit must
only be operated with fitted thermal
insulation and/or silencer hood (risk of
burning).
Before connecting the equipment to the
power supply, compare the rated voltage
stated on the type plate (230 V, 50 Hz) with
the supply voltage. Install this heating
system in accordance with the safety
requirements in EN 12828 as an open or
sealed system.
All safety valves must be compliant with
DIN EN ISO 4126-1 and must be
type-tested. The blow-off line must
correspond to the highest rated output of
the ROTEX GasSolarUnit/GasCompactUnit.
In sealed systems, use only safety valves
marked with an "H" in the type-test
symbol. Install them in the safety flow.
For filling and commissioning the heating
system, observe VDI 2035 [or local
regulations].
The ROTEX GasSolarUnit/GasCompactUnit
has been tested and certified in accor-
dance with DIN EN 483, DIN EN 677 and
DIN EN 625.
The GasSolarUnit/GasCompactUnit is
categorised as NOx class 5. It performs
substantially better than the minimum
efficiency for condensing boilers specified
by EN 677. It meets the requirements of
the 1st BImSchV and those of the "Blue
Angel" RAL-UZ 61 [Germany].
For connection to the sanitary system
observe the regulations in DIN EN 806 and
DIN 1988 [or local regulations]. The
connecting pressure should not exceed
6 bar and must, under no circumstances,
be higher than 10 bar. When installing gas
2
fired heating systems, observe TRGI G 600,
TRF or the respectively applicable national
regulations, as well as the requirements of
the gas supply company.
The gas supply pressure should be
between 5 and 55 mbar.
Compare the gas details specified on the
equipment label with the supply details
specified by your gas supply company.
[ 3 ]
