VERANDA HRV80-ZIP-2P
WARNINGS
Installation must be carried out by qualified personnel in compliance with EN and local safety regulations relating to
domestic electrical systems.
See also product technical data document.
Consult these instructions before you start using this product.
The tightening of springs creates significant forces. Be very careful and ensure solid footing whilst operating.
Provide sufficient light in the installation area. Remove obstacles and dirt. Make sure that, except for the fitters, no
other people are present in the installation area. Unauthorised persons might be in the way, thus jeopardising
themselves and others.
This symbol indicates the possibility of injury to persons or damage to the product.
This symbol denotes a warning.
This symbol means it is necessary to use force during the operation shown.
Use electric screwdrivers set the correct torque value.
This symbol indicates the need of a visual control.
This symbol indicates an optional element.
The manufacturer accepts no liability for any inaccuracies or printing errors that may be contained in this manual. The
manufacturer reserves the right to introduce any modifications to the product that are considered necessary or in the
interests of the user and which do not alter the essential operational and safety characteristics of the appliance. No
modification of the design or configuration may be carried out without first consulting the manufacturer. The end user
must receive the product's operation instructions.
Document validity: 12.8.2019
.05.2019
MEASUREMENT AND ASSEMBLY MANUAL
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VERANDA HRV80-ZIP-2P and is the answer not in the manual?

Questions and answers

Related Manuals for Isotra VERANDA HRV80-ZIP-2P

Summary of Contents for Isotra VERANDA HRV80-ZIP-2P

  • Page 1 MEASUREMENT AND ASSEMBLY MANUAL VERANDA HRV80-ZIP-2P WARNINGS Installation must be carried out by qualified personnel in compliance with EN and local safety regulations relating to domestic electrical systems. See also product technical data document. Consult these instructions before you start using this product.

  • Page 2: General Guidelines

    MEASUREMENT AND ASSEMBLY MANUAL GENERAL GUIDELINES Several safety measures must be taken for safe use and maintenance of this product. Comply with the following instructions for your safety and the safety of others. If in doubt, contact your supplier. This manual describes how to use and control standard shading products. In addition to instructions given in this document, instructions given in other documents may apply to some components (e.g.

  • Page 3: Operation

    MEASUREMENT AND ASSEMBLY MANUAL CAUTION: SPRINGS IN THE BOTTOM SECTION AND THE PULL CORDS ARE UNDER A HEAVY MECHANICAL STRESS. NEVER ATTEMPT TO REPAIR, ADJUST, OR REMOVE THEM ON YOUR OWN. The above may pose risk to persons or cause injury. Send for a qualified technician! Consult this manual before installation and each repair of the product.

  • Page 4: Improper Use

    MEASUREMENT AND ASSEMBLY MANUAL STOPPING Press the stop button on the switching unit, remote controller or automatic control device. CLOSING Press the “up” button on the switching unit, remote controller or automatic control device (or keep the button pressed – applies to button switches). CLOSING THE SUN SCREEN BEAR THE FOLLOWING IN MIND WHEN CLOSING THE SUN SCREEN: TO PREVENT THE RISK OF BEING SQUEEZED, KEEP YOUR HEAD, FINGERS AND OTHER BODY PARTS...

  • Page 5: Safety Elements

    MEASUREMENT AND ASSEMBLY MANUAL SAFETY ELEMENTS Automatic controller: wind protection. Automatic controller: wind/sun control system. Read the operation manual carefully. Note: The user must always be aware whether the screen is open, or closed. The automatic controller may malfunction in abnormal conditions like power failure, defect, sudden storm, etc., and this may lead to the awning damage and risk of falling.
  • Page 6 MEASUREMENT AND ASSEMBLY MANUAL  Lubrication of castors under the end of the guiding sections (at least once a year).  Lubrication of bearings opposite the operating side (at least once a year).  Lubrication of cylinder bearings (at least once a year). ...
  • Page 7 Veranda HRV80-ZIP-2P is equipped with a zipper system that ensures the fabric stays properly taut in every position of the bottom section and avoids fabric slipping out from the guide rails. The individual parts of the fabric are always fitted with a zipper on both the left and right side, while the thicker part locks with the plastic zipper section inserted in an aluminium guide rail.
  • Page 8 Make sure the box and the bottom profile can always be opened and that the mechanical parts inside are accessible at all times. Should you fail to follow this rule, ISOTRA cannot be held responsible for the cost of demolition work! 3.1 Wall bracket (standard)
  • Page 9 MEASUREMENT AND ASSEMBLY MANUAL 4. Measuring Guidelines for correct measuring Ensure the system is perfectly parallel and squared. An accurate measurement ensures a quicker and easier assembly. Ensure exact levelling of the system. Ensure that the foundation is sufficiently solid to install the foot supports. Be careful with relatively weak walls: the standard fixings are not part of the supply.
  • Page 10 IN ORDER TO ENSURE GOOD WATER DRAINING ON THE FRONT SIDE. If the system inclination (A) is insufficient for good water draining, ISOTRA only guarantees the product function as sun screen; in this case, complaint cannot be filed against the company in case of a breakdown or damage caused by poor water draining.
  • Page 11 Make sure it is possible to open the box and lower section at all times to provide access to the mechanical parts inside. If this rule is not followed, ISOTRA cannot be held responsible for the cost of demolition work! Document validity: 12.8.2019...
  • Page 12 MEASUREMENT AND ASSEMBLY MANUAL OPTIONS Wall insert If necessary, it is possible to place a wall insert to the gap between the box and the wall to create a water-tight seal. Aluminium sections are placed on each side and complemented with cover sheets. A rubber band is inserted to the section where it touches the box.
  • Page 13 Fixtures and fittings for the walls and anchoring to the ground are not part of the supply. 7. Packing The Veranda HRV80-ZIP-2P is supplied packed in robust cardboard boxes. 8. Use and maintenance Proper use and maintenance greatly increases the lifetime of the sun screen.
  • Page 14 MEASUREMENT AND ASSEMBLY MANUAL • The LED strip is always to be installed across the sun screen width. Less light may be experienced at the ends, depending on the LED strip length. • The LED strip is powered by 24 VDC supply unit, 9.6 W/m. •...
