XDM® -100

7.4 I/O and Aggregate Modules

7.4.1 I/O Modules

Eight slots are available in the XDM-100 shelf to accommodate the various types of
I/O modules. Each type of module (PIM, SIM, or EIS_M) can be inserted in any of
the I1 through I8 positions without limitation (the EIS_M occupies two slots).
PIMs and SIMs with electrical interfaces fully support direct connection to the
module without other external connection modules.
Table 7-2 provides a list of the XDM-100 I/O modules.
Module
Electrical
PIM2_21 21 x E1 (2 Mbps) PDH module for balanced and
unbalanced interfaces
PIM2_63 63 x E1 (2 Mbps) PDH module for balanced and
unbalanced interfaces
PIM15_28 21 x DS-1 (1.5 Mbps) Async module for balanced and
unbalanced interfaces
PIM345_3 3 x E3/DS-3 (34/45/51 Mbps) interfaces
SIM1_4e 4 x STM-1e/OC-3 (155 Mbps) interfaces
Optical
SIM1_4o 4 x STM-1o /OC-3 (155 Mbps) interfaces
SIM4_2 2 x STM-4/OC-12 (622 Mbps) interfaces
Mixed
SIM1_4/oe 2 x STM-1o/OC-3 + 2 x STM-1e/OC-3 (155 Mbps)
interfaces
Data
1
EIS_M See Table 4-1 in Chapter 4
1
The EIS_M module occupies a double slot in the I1 to I8 positions (I1+I2, I3+I4, I5+I6, I7+I8).
417006-2005-013-A02

Table 7-2: I/O interface modules

Ports/Bitrate
ECI Telecom Ltd. Proprietary
Physical Description
Total Interfaces
Module XDM-100
21 168
63 252
28 224
3 24
4 32
4 32
2 16
4 32
-- --
7-9
