- Page 1 MAVIC DISCLAIMER AND SAFETY GUIDELINES 2016.09 V1.0...
-
Page 2: Table Of Contents
Contents Safety At a Glance NOTICE Glossary Pre-flight Checklist Disclaimer and Warning Before You Begin Individual Parts Regarding Genuine and Functional Parts Remote Controller Camera Gimbal Compass Propulsion Systems Firmware Internal Storage Device Product Care Storage and Transportation Maintenance and Upkeep Flight Condition Requirements Weather Conditions and Surrounding Environment Interference with Flight Controller, Communications, and... -
Page 3: Safety At A Glance
Intelligent Flight Pause button at all times, in case of an emergency. 4. Maintenance and Upkeep DO NOT use aged, chipped or broken propellers. Recommended storage temperature: between 71° and 82° F (22° and 28° C). Refer to the Mavic Pro Intelligent Flight Battery Safety Guidelines for more information about the safe use of the battery. - Page 4 5. Observe Local Laws and Regulations DO NOT fly in the No Fly Zones. You can find a complete list of these areas at http://www.dji.com/flysafe The DJI No Fly Zone is not a replacement for local government regulations or good judgment. Avoid flying in areas where rescue teams are actively using the airspace. Fly in Open Areas Strong GPS Signal Maintain Line of Sight Fly Below 400 feet (120 m) Avoid flying over or near obstacles, crowds, high voltage power lines, trees or bodies of water. DO NOT fly near strong electromagnetic sources such as power lines and base stations as it may affect the onboard compass.
-
Page 5: Notice
NOTICE All instructions and other collateral documents are subject to change at the sole discretion of SZ DJI TECHNOLOGY CO., LTD. For up-to-date product information, visit http://www.dji.com and click on the Mavic Pro product page. Glossary The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:... -
Page 6: Disclaimer And Warning
This product is NOT a toy and is not suitable for children under the age of 18. Adults should keep the Mavic Pro out of the reach of children and exercise caution when operating this aircraft in the presence of children. - Page 7 DJI has made and may make available. DJI accepts no liability for damage, injury or any legal responsibility incurred directly or indirectly from the use of this product. The user shall observe safe and lawful practices including, but not limited to, those set forth in these Safety Guidelines.
- Page 8 DJI reserves the right to update this disclaimer and the safety guidelines. Please visit www.dji.com and check your email periodically for the latest version. This disclaimer is made in various language versions;...
-
Page 9: Before You Begin
User Manual in the app or on DJI’s official website for more comprehensive information. Make sure you fully understand the functionality of each individual part, the flight condition requirements, the key contingency warning functions/systems, and all government regulations before each flight. If you have any questions or problems during the assembly, maintenance or use of this product, please contact DJI or a DJI authorized dealer. Individual Parts Regarding Genuine and Functional Parts To avoid component malfunction, serious injury, and property damage, ... -
Page 10: Remote Controller
5. Be sure to power off the Intelligent Flight Battery correctly, otherwise your camera parameters will NOT be saved and any recorded videos may be damaged. NOTE: Regardless of the reason, DJI will not be responsible for any failure of an image or video to be recorded or having been... -
Page 11: Gimbal
2. DO NOT carry ferromagnetic materials with you during calibration such as cellular phones. 3. The DJI GO app will prompt you to resolve the compass issue if the compass is affected by strong interference after calibration is complete. Follow the prompted instructions to resolve the compass issue. -
Page 12: App
2. Always power off the aircraft before touching the propellers. 3. Be aware of the sharp edges of the propellers when mounting or removing the propellers. Wear gloves or take other protective measures when touching the propellers. 4. Whenever necessary, use tools (e.g., wrench, screwdriver, pliers, etc.) to remove or install the propellers. 5. Ensure the propellers are securely mounted to prevent them from falling off the motors. 6. DO NOT turn on the motors when propellers are mounted and there are other people or animals in the immediate vicinity. Motors 1. Ensure the motors are securely mounted and rotating smoothly. 2. DO NOT attempt to modify the structure of the motors. 3. DO NOT touch or let your hands or body come in contact with the motors after flight as they may be hot. To avoid possible serious injury and property damage, observe the following rules: 1. DO NOT block any of the ventilation holes on the motors. 2. -
Page 13: Firmware
2. Firmware upgrade notifications will prompt you to proceed with an update immediately or to update the firmware within three days. If you choose to ignore the current firmware update, you are required to accept the prompted disclaimer. You further understand and agree that the data including but not limited to flight telemetry data and user selection records may be uploaded to and maintained on a DJI-designated server. 3. Be sure to download the firmware package file from the official DJI website. Verify the firmware package file’s integrity before upgrading. 4. Be sure to update the remote controller’s firmware to the latest version after you update the aircraft’s firmware. 5. The remote controller may become unlinked from the aircraft after updating. Re-link the remote controller and aircraft. -
Page 14: Internal Storage Device
6. Be sure to check all connections and remove the propellers from the motors before performing the firmware update. Internal Storage Device 1. The aircraft contains an internal storage device that may store data and operations records (including still and motion imagery data from one or more sensors in the aircraft). Still and motion imagery data may be automatically generated from the one or more sensors when you operate the aircraft. -
Page 15: Maintenance And Upkeep
Maintenance and Upkeep 1. Check every part of the aircraft after any crash or violent impact. If you have any problems or questions, please contact a DJI authorized dealer. 2. Regularly check the Battery Level Indicators to see the current battery level and overall battery life. When the battery life reaches 0%, it can no longer be used. -
Page 16: Operating The Aircraft Responsibly
equipment. Make sure to turn off the Wi-Fi on your mobile device. 3. DO NOT fly near areas with magnetic or radio interference. These include but are NOT limited to: high voltage lines, large scale power transmission stations or mobile base stations and broadcasting towers. Failing to do so may compromise the transmission quality of this product or cause remote controller and video transmission errors which may affect flight ... -
Page 17: Flight Modes, Functions And Warnings
Flight Modes, Functions and Warnings Flight Modes To avoid serious injury and property damage, observe the following rule: 1. DO NOT switch from P-mode to S-mode unless you are sufficiently familiar with the aircraft’s behavior for each flight mode, since disabling GPS may result in being unable to land the aircraft safely. P-mode or S-mode is preferred for most flight scenarios. When flying in Atti mode, take EXTRA precautions because some features are NOT available in A-mode. 1. P-mode (Positioning): P-mode works best when the GPS signal is strong. The aircraft utilizes the GPS and Obstacle Sensing System to automatically stabilize itself, navigate between obstacles or track a moving object. -
Page 18: Low Battery
5. Only use the Failsafe and Return-to-Home functions in case of emergency, as they may be affected by the weather, the environment, or any nearby magnetic fields. 6. The aircraft cannot avoid obstacles during the Failsafe RTH when lighting condition is not ideal; therefore it is important to set an appropriate Failsafe altitude before each flight. -
Page 19: Tapfly
Flying over inclined surfaces that will deflect sound waves away from the aircraft 6. Camera calibration is required if the aircraft suffers from crashing. Calibrate the front cameras if DJI GO app prompt you to do so. TapFly To prevent serious injury or property damage, observe the following guidelines: 1. ... -
Page 20: Compliance With Regulations & No Fly Zones
branches and power lines) or transparent objects (e.g. glass and water) along the desired tracking path. 2. Watch out for potential obstacles in your surrounding area (especially on the rear, left, and right sides of the aircraft) and stay clear of them to avoid accidents. 3. Be prepared to take control of the aircraft or press the “STOP” button on press the “STOP” button on the screen or the Intelligent Flight Pause button at all times, in case of an emergency of an emergency. 4. -
Page 21: No Fly Zones
No Fly Zones DJI always stresses safety during flight, and has therefore developed various aids to help users comply with local rules and regulations while flying. We strongly recommend that you update the firmware to the latest ... - Page 22 2. If you intend to fly above the default altitude limit, you are required to accept the prompted disclaimer to enable the new altitude limit. If a new altitude limit is set, you further understand and agree that data including but not limited to flight telemetry data and altitude limit changes could be uploaded to and maintained on a DJI-designated server.
-
Page 23: Compliance Information
Compliance Information FCC Compliance Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 24 SZ DJI TECHNOLOGY CO., LTD. hereby declares that this device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive. A copy of the EU Declaration of Conformity is available online at www.dji. com/euro-compliance EU contact address: DJI GmbH, Industrie Strasse. 12, 97618, Niederlauer, Germany .
- Page 25 (1) 이 기기는 가정용으로 전자파적합등록을 한 기기로서 주거지역에서는 물론 모든 지역에서 사용할 수 있습니다 . (2) 당해 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서 비스는 할 수 없음。 根據 NCC 低功率電波輻射性電機管理辦法 規定 : (1) 第十二條經型式認證合格之低功率射頻電機，非經許可，公司、商號或使 用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。 (2) 第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發 現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之 干擾。 เครื ่ อ งโทรคมนาคมและ อุ ป กรณ์ น ี ้ มี ค วามสอดคล้ อ งตามข้ อ กำ า หนดของ กทช . “La operación de este equipo está...
- Page 26 This content is subject to change. Download the latest version from www.dji.com/support If you have any questions about this document, please contact DJI by sending a message to DocSupport@dji.com. MAVIC is a trademark of DJI. Copyright © 2016 DJI All Rights Reserved. Printed in China.
