- Page 1 USER GUIDE Read Before Use! Read Before Use! Applies to Model Numbers: 620 & 626 www.BulletTools.com • 208-772-0175 PRT-INS-0600Rev.D.8.19 ©2019 Bullet Tools...
- Page 2 15. Warning: The dust generated by cutting certain wood, wood fiber, fiber cement, and/or PVC products can be injurious to your health. 16 Bullet Tools™ does not endorse or warrant inferior "knock off" imitations of our designs. Using these may be dangerous — please contact the manufacturer about any defects with these.
-
Page 3: Hardware Kit
set up Please Review and Verify Parts Included in Box: 1. Power Assembly 2. Handle Assembly 3. Fences (2) 4. Table 5. Tail 6. Rails (2) 7. Hone Stone 8. Angle Bracket 9. Mount Bracket 10. Hardware Kit Hardware Kit Item A. - Page 4 set up 3. attach table a. Attach table to tail using Item E self tapping screws. Do not tighten screws until after step B. B. Attach table to base working outward from center. Start all screws by hand, using Item D machine screws. Tighten Item D machine screws from center out.
-
Page 5: Safety Lock
6. Mount to stanD or cut-station Hook square bracket k under the lower flange of the base. Set shear in place on chopsaw-stand or on a pair of (fastened) 2x2s (38mm X 89mm) spaced 24.5” (622mm) apart and bolt or lag into place. Bolts and lag-screws not included. -
Page 6: Custom Settings
custoM settings Set to cut over 3/4" Factory Setting backstroke stop or 19mm To cut approved products over 3/4" / 19mm thick, loosen Phillips head screw on the Backstroke Stop; turn the Backstroke Stop 180º and tighten screw. For more convenience when cutting thinner products, restore factory setting. -
Page 7: Maintenance
Maintenance When to hone to hone There are three situations when it is very important With the blade in the machine, it is quick and to hone the blade (remove burrs) on the flat side easy to hone; Simply pull the Magnum™ Siding of the blade. -
Page 8: Changing The Blade
Maintenance changing the blaDe Warning Blade is extremely sharp! Use hand protection when removing, honing, or sharpening blade! Jack Screws 1. turn shear upsiDe DoWn Tip: put the shear on the edge of a sturdy table. 2. loosen blaDe Using a Phillips screwdriver, remove the Item D screws. -
Page 9: Available Accessories
Maintenance kit An essential tool care product engineered to extend the life of any Bullet Tools shear. Each kit is specially designed and assembled for your shear. Features a 1-year extended warranty on new and current Bullet Tools warranty. Includes replacement blade. -
Page 10: Warranty
Any and all warranties, written or implied, are void with any alterations Soft Plastic to the product. Note: Bullet Tools shall not be liable for any special, incidental or consequential damages, including Please note: Approved materials may vary but not limited to lost revenue, lost profits, rental or in density and hardness.
