General Specifications and Dimensions

SUPPLY VOLTAGE...............................115, 230 V
CONTROL VOLTAGE............................24 V
MOTOR.................................................Continuous duty 1/2, 3/4, 1 horsepower
OPERATOR OUTPUT SPEED..............46 RPM
NET WEIGHT (Operator only)...............98 Lbs (45 Kg)
STANDARD WIRING TYPE..................C2 (momentary contact to open/stop and constant-pressure-to-close)
APPLICATION.......................................Ultra high-end heavy duty v-belt drive for sectional doors, rolling doors and
DUTY.....................................................>35 cycles/hour or >150 cycles/day
Table 1 - Operator Selection Guide
Rolling Doors
Steel Grilles
Insulated 16 ga
HP
Steel Steel
½ 157 236
¾ 206 294
1 255 358
For technical support, please call 1-800-361-2260 or visit
AC
class 2 transformer, 2 amp fuse type ACG
AC
grilles
Figure 1 - MSJ Dimensions
Maximum Area in Square Feet (general guideline)
Alu. Grilles
Alu. Door
20 ga 22 ga 24 ga
Steel Steel
Steel
260 319 358
358 451 515
446 574 613
4
single-phase, 208, 460, 575 V
Steel
Steel
18 ga
18 ga ins.
20 ga ins.
196 245
270 319
294 392
www.manaras.com
three-phase
AC
Sectional Doors
Wood
Alu. Steel
Steel 20 ga,
22 & 24
22 & 24 ga
ga
ins.
314 343
441 490
490 564
for more information
Fiberglass
392
549
613
