- Page 1 EPIK SWAN USER MANUAL 48V 500W OR 48V 350W Please, read before operating your new e-JOE electric bicycle...
- Page 2 Please, observe traffic regulations and do not lend your bicycle to anyone unfamiliar with it. It can only be legally used on the road by a person aged 14 years and older. e-JOE bikes are not designed for use by children. If you decide to use a child carrier, a child must be wearing a helmet and seated by the carrier manual.
-
Page 3: Opening Your Bicycle
OPENING YOUR BICYCLE EPIK SWAN low step-through folding electric bicycle is shipped 98% assembled in a box that contains the following items: ● Main body of the electric bike consisting of: ○ Frame ○ Front wheel with a front suspension fork ○... - Page 4 STRUCTURE OF YOUR E-BIKE NOTE: You can find the serial number on the head tube of the frame above the front suspension fork. The regular format is EJSW12345. The removable battery and controller are located inside the frame.
- Page 5 SIZING...
-
Page 6: Main Specifications
MAIN SPECIFICATIONS BIKE Weight (incl. battery) 45-50 lbs. (depending on bike configuration) Max Capacity 300 lbs. Dimensions (LxWxH) Unfolded: L62” x W25” x H45”; Folded: L32” x W22” x H29” Max Speed 20 mph Full Charge Distance up to 40 miles (depending on terrain and rider’s weight) Climbing Grade ≤... - Page 7 ASSEMBLY NOTICE: The following assembly steps are only a general guide to assist in the assembly of your e-JOE Bike and are not a complete or comprehensive manual of all aspects of assembly, maintenance, and repair. We recommend you consult a certified bicycle mechanic to assist in the assembly, repair, and maintenance of your bicycle.
- Page 8 EPIK SWAN comes with the multifunctional LCD power assist display. The display is mounted on the left side of the handlebar and has three main buttons (SW/UP/DOWN), and a monitor.
- Page 9 INTERFACE 1 Battery Capacity Single Trip Time (TM) Cruise, PAS, Throttle PAS Level (when in use) Walk Power Assist (when in use) Backlight/Headlight (when in use) Real Time Speed (in km/h or mph) Brakes (when applied) Single Trip Distance DST (in km/h or mph) INTERFACE 2 Battery Capacity Total Trip Time...
- Page 10 Pedal Assist System (PAS) – Level selection PAS comes with 5 levels of pedal assistance. There is no pedal assistance when the level is set to 0. To change the PAS level, click UP or DOWN button to increase or decrease the levels.
- Page 11 For more information about the display and its settings, visit the official LCD manual. THROTTLE EPIK SWAN is equipped with a throttle that allows to speed up to 20 mph without pedaling at all. The thumb throttle is mounted on the right side of the handlebar.
-
Page 12: Battery And Charger
NOTE: The keys are to unlock the battery only. Turning the key DOES NOT act as the ignition for the battery or motor. Keep in mind that e-JOE does not carry copies of the keys. It is recommended to store one key in a safe location in case the first key is lost. - Page 13 ● When you need to dispose of a lithium-ion battery, either dispose of the unwanted battery through an approved recycler or send it to e-JOE. We will make sure it is properly recycled. ● Never dispose of batteries in fire because they may explode.
- Page 14 — something that single gear is not capable of. EPIK SWAN comes with seven (7) gears. To change the gear while riding, press + or – of the shifter on the right side of the handlebar until you reach your desired gear. The gears are switched by the rear derailleur located on the right side of the rear wheel.
-
Page 15: Seat & Handlebar
SEAT & HANDLEBAR Appropriate adjustments can be made to seat (or saddle) & handlebar height according to personal preference. QUICK-RELEASE CLAMP The clamps that hold handlebar or seat posts in place are called quick-release clamps. If you need to tighten or loosen the clamp, use an adjustment knob located on the opposite side from the quick-release lever. -
Page 16: Folding Instructions
FOLDING INSTRUCTIONS FRAME The frame locking lever is located in the mid portion on the right side of the frame. To unlock the lever and fold the frame, slide the bottom lock towards the front of the bike and simultaneously pull the silver locking lever away from the frame. When unfolding the frame, push the lever against the frame until the lock clicks and secures the frame. - Page 17 GENERAL OPERATION & MAINTENANCE Like any other mean of transportation, electric bicycle and its components are subject to wear and tear. When comparing to regular bicycles, the rate of wear for electric bikes is higher due to its weight and speed; it does not mean the components are defective or of low quality.
-
Page 18: Warranty
10% of the product price in case the original product is returned in a bad manner, with the insufficient protective material, not by the instructions provided by e-JOE, or shows signs of excessive use, neglect, dirt, dust. - Page 19 Step 3 If the issue is deemed as manufacture defect in materials and workmanship, fill out the warranty claim form below. e-JOE shall repair or replace parts that are found by e-JOE to be defective and covered by the limited warranty.
-
Page 20: Simple Troubleshooting
1. Connect charger to outlet first. When indicator lights come on, connect charger to battery. the battery, it sparks 2. If sparks again, stop charging and contact e-JOE technical support K. When plugging in the charger into an outlet 1. It means battery is full or not charging. Check LCD indicator if the battery is fully charged and then into the battery, the green light stays 2. - Page 21 CONTACT US We hope you enjoy your new e-JOE bike! If you have any questions/comments/concerns or would like to share your e-JOE bike experience, please contact us at: Telephone: 855-888-1891 Email: sales@ejoebike.com Website: www.ejoebike.net Follow us on Facebook and Instagram! www.facebook.com/ejoebike...
