- Page 1 2017 EPIK SE USER MANUAL Please read before operating your new bicycle.
- Page 2 Even a small amount of alcohol will limit your ability to be safe on the road. When you need to replace your battery, please either dispose of it properly or send it back to us or your retailer and we will make sure it is properly recycled. Happy cycling! YOUR FRIENDS AT E-JOE BIKE...
-
Page 3: Warranty
LIMITED 30 DAYS FULL REPLACEMENT WARRANTY If an e-JOE bicycle is not working properly because of a major defect within the first 30 days, e-JOE Bike, Inc. will repair or replace any defective e-JOE Bicycle at its sole option and expense upon determining whether the damage, failure, or loss is due to a major defect. -
Page 4: Opening Your Bicycle
● Front and rear LED lights ● Pedals (2) ● Battery charger - in a separate box ● Mini tool kit for assembly and/or repairs ● Keys (2) Please contact your dealer or e-JOE Bicycle if any of these parts are missing. - Page 5 STRUCTURE OF YOUR E-BIKE Currently electric bicycles can be divided into two classes: TAG (Twist And Go) and PAS (Pedal Assistance System). The EPIK SE belongs in the second classification. Refer to the picture below for structure and parts.
-
Page 6: Main Specifications: Epik Se
MAIN SPECIFICATIONS: EPIK SE BIKE Weight 42 lbs. Max Capacity 300 lbs. Dimension 65” x 27” x 46” Max Speed 20 mph ≤ 55 miles (depending on terrain and rider’s weight) Full Charge Distance ≤ 10% Climbing Grade MOTOR Description Rear drive brushless hub motor Max Riding Noise 60 db... - Page 7 BRAKES There are two types of braking mechanisms that e-JOE installs on its electronic bicycles, the “V-brake,” and the “Disk brake.” The Epik SE has a Disk brake installed on both the rear and front brake and is used to control the entire braking system of the bicycle,...
-
Page 8: Seat And Handlebar Safe Height Mark
SEAT AND HANDLEBAR SAFE HEIGHT MARK Vertical Handle Stem Position Appropriate adjustments can be made for the vertical handle stem according to personal preference or driving habit, but it is forbidden to expose the infix notation (also called, the safety line). If used in an inappropriate way, it may cause serious injury to the rider. - Page 9 BATTERY AND CHARGER ACCESS Battery Access Slot Make sure the batter is properly seated against its housing in the frame. Insert the key into the lock on the top of the battery head.. Turn the key to remove/lock the battery in the frame. ●...
- Page 10 ● Do not use any other charger other than the one that came with your electric bike. If you need another charger, contact your local dealer or e-JOE Bicycle. ● Do not attempt to open or repair your charger, the electronics contain high-pressure circuits, so do not dismantle by yourself without a professional.
-
Page 11: General Operating Instructions
GENERAL OPERATING INSTRUCTIONS Electric Assist - LED Operating Instructions When you first turn on your electric bike, your LED Electric Assist Display will automatically go into the default setting: Pedal Assist System (PAS) will be turned on, thumb throttle will be turned on, and battery level indicator will be turned on. ●... - Page 12 Before You Ride for the First Time: ● Check that lever for the handlebar stem is properly tightened. ● Check that locking lever for folding pipe is tightened and the safety clip ring is in place. ● Check that the folding lever for the frame is tightened and safety clip is in place. ●...
-
Page 13: Folding Instructions
FOLDING INSTRUCTIONS The Epik SE can be folded for easy storage and travel. Pedals: Fold the pedals by pressing the end of the pedal inward and then upwards. Folding Pipe: Locate the locking lever at the base of the folding pipe. First sliding the safety clip ring away from the lever, and then pull the locking lever out and down towards the floor. -
Page 14: Maintenance
MAINTENANCE ● IMPORTANT! DO not attempt to open the casings of the battery, motor, or controller; it could be dangerous and will void any warranties by doing so. If you experience and problem, please contact our service department or your retailer. ●... -
Page 15: Simple Troubleshooting
SIMPLE TROUBLESHOOTING PROBLEM SOLUTIONS A. Top speed too slow 1. Fully recharge battery B. Power on but motor not working 1. Reinstall battery/ Replace fuse C. Driving shorter distance per recharge 1. Check tire pressures 2. Recharge completely or have charger re-inspected 3. - Page 16 CONTACT US We thoroughly hope you enjoy your new e-JOE bike! If you have any questions/comments/concerns, or would like to share your e-JOE bike experience with us, please contact us at: Telephone: 855-888-1891 Email: sales@ejoebike.com Website: www.ejoebike.com Like us on Facebook!
