e-Joe Koda User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

KODA USER MANUAL
Please, read before operating your new bicycle

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Koda and is the answer not in the manual?

Questions and answers

Related Manuals for e-Joe Koda

Summary of Contents for e-Joe Koda

  • Page 1 KODA USER MANUAL Please, read before operating your new bicycle...
  • Page 2 Even a small amount of alcohol will limit your ability to be safe on the road. When you need to replace your battery, please, either dispose it properly or send it back to us or your retailer and we will make sure it is properly recycled. Happy cycling! YOUR FRIENDS AT E-JOE BIKE...

  • Page 3: Warranty

    LIMITED 30 DAYS FULL REPLACEMENT WARRANTY If an e-JOE bicycle is not working properly because of a major defect within the first 30 days, e-JOE will repair or replace any defective e-JOE Bike at its sole option and expense upon determining whether the damage, failure, or loss is due to a major defect.

  • Page 4: Opening Your Bicycle

    ● Battery keys (2) After unpacking, please, do not discard the box and protective material until you test the bike and make certain it is in good working condition. Contact your dealer or e-JOE Bicycle if any of these parts are missing.
  • Page 5 STRUCTURE OF YOUR E-BIKE...

  • Page 6: Main Specifications

    MAIN SPECIFICATIONS BIKE Weight (with battery) 54 lbs. Max Capacity 350 lbs. Dimension 71” x 27” x 44” Max Speed 20 mph Full Charge Distance up to 50 miles (depending on terrain and rider’s weight) Climbing Grade ≤ 10% Pedal Assist System Side Thumb Throttle Control &...
  • Page 7 ASSEMBLY KODA electric bicycle is shipped 98% assembled. In order to fully assemble the bike and prepare it for the first use, follow these simple steps: Step 1: Packing Material Remove all packing and protective material and put aside. Do not discard the box or any shipping material until you test the bike and make certain it is in good working order.
  • Page 8 NOTE: The keys provided are ONLY used to lock and unlock the battery. Turning the key DOES NOT act as an ignition for the battery or motor. Please, keep in mind that e-JOE does not carry copies of the keys. It is recommended to store one key in a safe location in case the first key is misplaced or lost.

  • Page 9: General Operating Instructions

    GENERAL OPERATING INSTRUCTIONS Before You Ride for the First Time: ● Check that the handlebar and handlebar stem are properly tightened. ● Check all other nuts and bolts and fixings are properly tightened, paying particular attention to the motor fixings, kickstand, yoke, and steering head bearings.

  • Page 10: Display Unit

    LCD OPERATING INSTRUCTIONS KODA is equipped with the multifunctional LCD power assist display. Depending on the year of production, two types of displays are used: 1) Settings of the Display #1 Contain the Following: ● Display ○ Battery capacity (power) ○...
  • Page 11 Other LCD Functions: ● Trip Clearance: Press [mode] and [down] buttons simultaneously to clear trip distance ● Distance Display: Short press [up] to switch between ride distance and total distance ● Error Codes ○ 04: Throttle no homing ○ 05: Throttle Abnormality ○...
  • Page 12 When the display is turned on, hold both UP and DOWN for 2.5 seconds at the same time to enter the settings. The first setting parameter is a wheel diameter. The default setting for KODA is 26 inch. Do not change this setting. After the confirmation of the wheel size, short press MODE to reserve it and enter into the max speed setting.

  • Page 13: Maintenance

    Make sure that the chain runs freely and retighten the axle nuts. ● KODA is equipped with the hydraulic brake system which should be regularly inspected. With use over time, brake fluid will become contaminated with dirt and moisture and should be replaced. It is recommended to use mineral oil for brake fluid replacement.

  • Page 14: Simple Troubleshooting

    SIMPLE TROUBLESHOOTING PROBLEM SOLUTIONS A. Top speed too slow 1. Fully recharge battery B. Power on but motor not working 1. Reinstall battery/ Replace fuse C. Driving shorter distance per recharge 1. Check tire pressures 2. Recharge completely or have charger re-inspected 3.
  • Page 15 CONTACT US We hope you enjoy your new e-JOE bike! If you have any questions/comments/concerns, or would like to share your e-JOE bike experience, please contact us at: Telephone: 855-888-1891 Email: sales@ejoebike.com Website: www.ejoebike.net Follow us on Facebook and Instagram! www.facebook.com/ejoebike...
