Summary of Contents for Diono everett NXT fix
- Page 1 NXT fix High Back Booster designed to grow. Built to last. IMPORTANT READ INSTRUCTION MANUAL before using this child restraint...
- Page 3 NXT fix Important Before using your child seat, ensure to review and familiarise yourself with the features and functions of the child seat by reference to this user manual. Follow the instructions to the letter and keep them for future reference.
- Page 4 NXT fix NOTICE Groups 2 and 3 (from 15 to 36 kg) – securing with vehicle belt This is a “Universal” child restraint. It is approved to Regulation No. 44, 04 series of amendments, for general use in vehicles and it will fit most, but not all, car seats.
- Page 5 NXT fix Groups 2 and 3 (from 15 to 36 kg) – securing with vehicle belt and isofit connectors (Semi Universal – See fitting list) This child restraint is classified for Semi-universal use and is suitable for fixing into the seat positions of the cars listed in the fitting list annexed to this manual.
- Page 6 NXT fix IMPORTANT INFORMATION Safety • Warning: for groups 2 and 3 fixed with the isofit system: always use the isofit system together with the vehicle’s safety belt. Do not fix the child seat by means of the isofit attachment points only.
- Page 7 NXT fix • Do not leave the child seat in the vehicle when the vehicle is parked in the sun: steel and plastic parts of the child seat may become very hot. • Make sure that any luggage or other objects liable to cause injuries in the event of a collision are properly secured.
- Page 8 NXT fix PREPARATORY WORK Components of the child seat Identify the components of the child seat before using it. 1 headrest 2 backrest 3 belt guide 4 seat base 5 isofit locking arms 6 isofit locking button 7 headrest adjustment handle...
- Page 9 NXT fix Adjusting the headrest height • Caution: adjust the height of the headrest before fitting the child seat in the vehicle seat. • Caution: adjust the headrest so that there is a space two fingers wide between the headrest and your child’s shoulder.
- Page 10 NXT fix Move the headrest to the desired height. Release the adjustment handle to lock the headrest at the desired height. You will hear a CLICK sound. • Warning: After having released the handle, check that the headrest is locked in the new position.
- Page 11 NXT fix • Warning: always use the isofit connectors together with the vehicle safety belt. Do not fix the child seat by means of the isofit attachment points only. • Warning: Do not put anything between the child seat and the vehicle seat.
- Page 12 NXT fix TIP: the isofix attachment points are located between the surface and the backrest of the vehicle seat. Push the isofit release button and rotate the isofix connectors.
- Page 13 NXT fix Grasp the child seat with both hands and slide the two locking arms into the insert guides until both isofit connectors engage with a “click” sound on both sides. Check that the green safety buttons are visible on both sides.
- Page 14 NXT fix Place the child in the child seat. Ensure they are as far back and upright as possible. Pull out the vehicle seat belt and guide it in front of your child to the vehicle seat buckle. •...
- Page 15 NXT fix Pull the diagonal section of the vehicle belt to tighten it. • Warning: Make sure that the diagonal seat belt section runs over your child‘s chest, and not in front of her or his neck. • Warning: During the journey periodically check that the child has not freed itself from the child seat.
- Page 16 NXT fix Removing the child seat To release the isofit connectors, pull the red button, first on one side, then on the other. Release the vehicle seat belt, unthread it from the child seat and allow it to retract.
- Page 17 NXT fix CARE AND MAINTENANCE Cleaning Clean plastic parts with a wet cloth. Do not use harsh cleaning agents. Never use chemical cleaning or bleaching agents. Cover Take the covers off completely to wash them. Follow the washing instructions reported on the label attached to the fabric.
- Page 18 NXT fix Removing the cover Disassemble the seat base from the back support by pushing down on the seat base whilst pushing the back support backwards until the two projecting tabs on the back support disconnect with the openings in the seat base.
- Page 19 NXT fix...
- Page 20 #MadeOfSeattle Made in China © 2018 Diono UK 2nd Floor | Dale House | 35 Dale Street | Manchester | M1 2HF | United Kingdom #DI-000242 diono.com...
