LEARN MODE (A):
How to program the buttons of TV remote
with the included remote control?
1
Press and hold
it for 5 seconds
Press and hold the " " button for 3s. When the LED indicator on the remote control lightens
continuously, press the " " button. The buzzer will beep once. After the IR receiver lighten, the
system enters learning mode.
2
slow flash
Press the " " button. The buzzer will beep twice,
and the IR receiver will flash slowly.
4
Press the " " button. The buzzer will beeps 4 times, and the IR receiver turn off. The duplication is
successful.
Note: If the buzzer only beeps once, it indicates that the TV remote can't support the learning mode.
•
Repeat the same process to duplicate the functions of "
Note:
If the operation of any of the steps shown above is over 20s, the system will automatically
exit the learning mode.
9
For this progamming
sequence the included
remote is needed!
turn on
3
fast flash
Target your TV remote control at the IR receiver, and
press a button that is correspondent with the function
of " " button. Then, the buzzer beeps three times,
and the IR receiver flashes quickly.
turn off
" and " " buttons
LEARN MODE (B):
How to program "Power" button on
the TV remote?
• Left and Right movement is done w/o programming.
1
Press and hold
it for 5 seconds
Press and hold the " " button for 3s. When the LED indicator on the remote control lightens
continuously, press the " " button. The buzzer will beep once. After the IR receiver lighten, the
system enters learning mode.
2
slow flash
Long press the " " button for 3s. The buzzer
will beep twice, and the IR receiver will flash slowly.
4
Press the " " button. The buzzer will beeps 4 times, and the IR receiver turn off. The duplication is successful.
Note: If the buzzer only beeps once, it indicates that the TV remote can't support the learning mode.
The learning mode only duplicate the functions of "
1
2 No all of the TV remote controls are compatible with the learning mode.
3 Please select the buttons on the TV remote control that won't activate changes in both TV and TV mount.
4 With learn mode there is no need to switch between remote controls.
For this progamming
sequence two remotes
are needed!
turn on
3
Target your TV remote control at the IR receiver, and
press a button that is correspondent with the function
of " " button. Then, the buzzer beeps three
times, and the IR receiver flashes quickly.
turn off
IMPORTANT:
", " ", " OK " and " " buttons.
fast flash
