Page 1 대 외 비 보 존 기 한 3 년 SyncM aster 320P (L BE32PS) Training M anual Training M anual SAMSUNG ELECTRONICS CO.,LTD Visual Display Division LCD Monitor Group...
Page 2: Index Index
Index Index Overview Introduction B lock D iagram M ain B oard Part Service B oard Part Troubleshooting D D C Entry W hat To D o after Board Replacement...
Page 3 Overview Overview 1. Background of Development ▶ To introduce into airports, cinemas, and other public facilities, where PDPs are currently predominant ▶ To create a new market using the advantages of LCD Monitors ▶ To address standardization/officialization by enabling distribution to all regions of a single model having no local derivation ▶...
Page 4: Product Features
Overview Overview 2. Product Features ▶ VMB (Vertical Marketing Business) Model ▶ MFM ( (Multi Function Monitor) : Receives diverse support other than PC (DVI, AV, S- video, Component) ▶ Response Time 8ms PVA adopted ▶ Sound function reinforced by adopting Dolby Virtual, BBE ▶...
Page 5: Specifications
Overview Overview 3. Specifications BE40PS Model Nam e SyncMaster 320P Panel AMLCD 32” ( LTA320W 2- L01) Opt i m um Res ol ut i on 1366x 768 (W XGA) 60Hz Di s pl ay Si ze 32” (16:9) Br i ght nes s...
Page 6: Viewing The Control Panel
Introduction Introduction (Front) (Front) Viewing the Control Panel MENU : Use this button to open the on-screen menu and exit from the menu screen or close screen adjustment menu. Up/Down button : Moves from one menu item to another vertically or adjusts selected menu values.
Page 7: Viewing The Connection Panel
Introduction Introduction (Rear) (Rear) Rear Viewing the Connection Panel 1. RS232C OUT/IN(RS232C Serial Port): MDC(Multiple Device Control) Program Port 2. DVI IN(HDCP) (PC Video Connection Terminal) : Using DVI Cable (DVI-D to DVI-D) - DVI mode (Digital PC) 3. PC IN(RGB) (PC Video Connection Terminal) : Using D-Sub Cable (15 pin D-Sub) - PC mode (Analog PC) 4.
Page 8 Introduction Introduction (Rear) (Rear) Rear Viewing the Connection Panel 8.AV AUDIO IN [L-AUDIO-R] (Monitor Audio Connection Terminal (Input)) 9.AV OUT [VIDEO](VIDEO Connection Terminal) : AV mode (Output) 10.AV IN [VIDEO](VIDEO Connection Terminal) (Input) 11. AV OUT [S-Video](S-Video Connection Terminal): S-Video mode (Output) 12.AV IN [S-Video](S-Video Connection Terminal) (Input) 13.EXT SPEAKER(8 Ω) (EXT Speaker Connection...
Page 9 Unpacking Unpacking Accessories 15pi n D- s ub cabl e BN39-00244B Speaker W i r e cabl e BN39-00315A Adapt or Connect or 3705-001262 Remote Control BN59-00464A...
Page 10 Unpacking Unpacking Accessories(Sold Separately)
Page 11 Comparison Comparison...
Page 12: Connecting To A Computer
Connecting the M onitor Connecting the M onitor Connecting to a Computer 1.Connect the power cord for your monitor to the power port on the 2-3. Using the BNC (Analog) connector on the video card. back of the monitor. Trun on power switch. Connect the BNC Cable to the BNC/COMPONENT IN - R, G, B, 2.There are 3 ways to connect the signal cable to your monitor.
Page 13 Connecting the M onitor Connecting the M onitor Connecting to a VCR 1.AV input devices like VCRs or Camcorders are connected to the AV IN [VIDEO] or AV IN [S-VIDEO] of the monitor using the S-VHS or BNC cable. 2. Connect the Audio (L) and Audio (R) terminals of a VCR or Camcorders to the monitor's MONITOR IN [L-AUDIO-R] using audio cables.
Page 14 Connecting the M onitor Connecting the M onitor Connecting to a DVD Player 1.Connect a set of audio cables between the COMPONENT AUDIO IN [L-AUDIO-R] on the Monitor and the AUDIO OUT jacks on the DVD player. 2. Connect a Component cable between the BNC/COMPONENT IN - PR, Y, PB port on the Monitor and the PR, Y, PB jacks on the DVD player.
Page 15 Connecting the M onitor Connecting the M onitor Connecting Speakers...
Page 16 PC Compatibility PC Compatibility PV Stage Chip Maker Card Name 1 ATI Radone X800Pro Radone X300 RADEO N 9600 4 S 3 Prosavage 5 Matrox G550 6 nVIDIA GeForce FX5700 PCX5750 GeForce 6600 GeForce FX5200 10 Inter i915G...
Page 17 Cautions When Connecting External D evices Cautions When Connecting External D evices When connecting component of DVD or STB terminal, Y, Pb, Pr color must be distinguished for normal color to appear. DVD or STB terminal also has separate input and output, so output terminal must be connected to monitor.
Page 18 Installing Stand K it Installing Stand K it Installing the Semi Stand...
Page 19 Installing Stand K it Installing Stand K it Installing Stand Kit (Sold separately)
Page 20 A djusting Y our M onitor A djusting Y our M onitor (Input) (Input) Sour ce Li s t Use to select PC, BNC or other external input source connected to the Monitor. PI P When external A/V devices such as VCRs or DVDs are connected to the monitor, PIP allows you to watch video from those devices in a small window super-imposed on the PC Video signal.
Page 21 A djusting Y our M onitor A djusting Y our M onitor (Picture : PC/ B NC/ D V I) (Picture : PC/ B NC/ D V I) MagicBright™ MagicBright™ is a new feature providing the optimum viewing environment depending on the contents of the image you are watching. Currently four different modes are available: Entertain, Internet,Text and Custom.
Page 22 A djusting Y our M onitor A djusting Y our M onitor (Picture : A V / S-V ideo/ Component) (Picture : A V / S-V ideo/ Component) P.Mode The Monitor has four automatic picture settings ("Dynamic", "Standard", "Movie" and "Custom") that are preset at the factory. Custom : Change the contrast and brightness according to personal preference.
Page 23 A djusting Y our M onitor A djusting Y our M onitor (Sound) (Sound) Mode The Monitor has a built-in high fidelity stereo amplifier. : St andar d, Mus i c, Movi e, Speech, Cus t om Cus t om 1) Bass : Emphasize low frequency audio.
Page 24 A djusting Y our M onitor A djusting Y our M onitor (Setup) (Setup) Ti m e Use to choose one of 4 time settings, Clock Set, Sleep Timer, On Timer, and Off Timer. When you select turning Yes the On Timer or Off Timer when Clock Set is undefined, a guiding message pops up: "Set the clock first.".
Page 25 A djusting Y our M onitor A djusting Y our M onitor (M ulti Control) (M ulti Control) Mul t i Cont r ol Assigns individual ID to the SET. : I D Set up, I D I nput...
Page 26 D isassembly D isassembly Place monitor face down on cushioned table. Remove 12 screws from the rear cover Remove 12 screws from the Shield and lift up the Shield.
Page 27 D isassembly D isassembly Disconnect cables from the boards and remove 6 screws from the Power board. Remove 6 screws from the Main board.
Page 28 D isassembly D isassembly Remove 3 screws from the Bottom BRKT. Eliminate Main Board and SMPS, remove the bottom BRKT.
Page 29 Internal V iew Internal V iew Panel (32” PVA) Power Board (SMPS) ▶ Use of LCD general LTA320W 2- L01 panel, ▶Maker: Samsung Electronics PVA Panel with response speed of 8ms ▶Producer: Unix, outsourcing Inverter ▶ Panel the whole Main Board ▶...
Page 30 Block D iagram Block D iagram (M ain Circuit) (M ain Circuit) Main Main-R TA2024 Main R/L Sound Amplifier TMDS Main-L 24Pin R/G/B/H/V BA7657F 15Pi n-Sub 128MB R/G /B/H/V Video Switch BN Cx 5 Y/Pb/Pr (i n pu t) GM1501H MDIN150 uPD64084 -.Twin scaler...
Page 31 Block D iagram Block D iagram (M ain - Power) (M ain - Power) Main Power Tree...
Page 32 Board Connections – M ain Board Connections – M ain LVDS Power Connect or Connect or (Connect to SMPS) (Connect to Panel) Power Connect or (Connect to SMPS) Power Connect or (Connect to SMPS) Funct i o AC Power RS232 BNC/ Com ponent / Audi PC ( D- SUB/ DVI / Aud...
Page 33 Board Connections – SM PS Board Connections – SM PS Power Connect or (Connect to MAIN board) I nver t er Connect or (From rear side, Power Connect or Connect to Left (Connect to MAIN board) Inverter) Connect t o AC s ocket Power Connect or (Connect to MAIN board)
Page 34 Schematics : Power 1 Schematics : Power 1 CN 600 Connect to SMPS(14p) CN 601 Connect to SMPS(4p)
Page 35 Schematics : Power 1 Schematics : Power 1 CN 720 Connect to (5p) IC606 5V -> 3.3V IC605 CN 603 7V -> 5V Connect to SMPS(3p)
Page 36 Schematics : Power 1 Schematics : Power 1 IC608 12V -> 8V IC609 8V -> 5V...
Page 37 Schematics : Power 1 Schematics : Power 1 5V -> 3.3V, 2.5V...
Page 38 Schematics : Power 2 Schematics : Power 2...
Page 39 Schematics : PC/ D V I Input Schematics : PC/ D V I Input CN 101 PC Signal In IC300 (Scaler) CN 102 DVI Signal In...
Page 40 Schematics : PC Input Schematics : PC Input CN 503 PC Sound In IC300 (Scaler) IC 100,101 : If EEPROM E_DDC_CTL signal containing DDC data is High, write cannot be done. Enter Factory mode for signal to be Low to be able to write.
Page 41 Schematics : BNC / Component Input Schematics : BNC / Component Input CN 103~107 BNC/Component Signal Input IC105 (Switch) IC300 (Scaler) BNC/ Component Input...
Page 42 Schematics : V ideo Input Schematics : V ideo Input S-Video Input Connector CN108 External Input - External Sound Input - Video CN505 CN109...
Page 43 Schematics : Signal Processing V CTi Schematics : Signal Processing V CTi Audio In/Out Video Out ADC(MST9886) In Video In...
Page 44 Schematics : Scaler gm1501H Schematics : Scaler gm1501H Video In PC In IC 203 :Memory IC Input from MDIN Out IC804 DNIe-pro In...
Page 45 Schematics : D NIe-pro Schematics : D NIe-pro IC 805,806 : Memory IC Input from MDIN Out IC401 LVDS In...
Page 46 Schematics : A D C (M ST9886), M D IN-150 Schematics : A D C (M ST9886), M D IN-150 Input from VCTi Out IC300 Scaler In...
Page 47 Schematics : Upd64084 Schematics : Upd64084 To VCTi In IC802 Upd64084 AV Signal...
Page 48 Schematics : A udio (Input) Schematics : A udio (Input)
Page 49 Schematics : A udio (L ip_sync Circuit) Schematics : A udio (L ip_sync Circuit)
Page 50 Schematics : A udio A M P Schematics : A udio A M P Speaker Out...
Page 51 Schematics : A udio A M P Schematics : A udio A M P Audio Switch Audio ADC/DAC...
Page 52 Schematics : EPROM Schematics : EPROM Function (CN200) RS232 (IC306) VCTi JIG (CN302) for R&D EEPROM, 24C64 (IC201)
Page 53 M ain board part M ain board part 1. MST9886 - 8- bit ADC VCTi output - 1 input 1 output - Component input (Y,Pb,Pr  R (D)) - VCT input Component (R,G,B (A)  R (D)) DTV STB, DVD Input MDIN150 Input DTV STB, DVD Input MDIN150 Input...
Page 54 M ain board part M ain board part 2.VSP(Inside VCTi) - 3 Inputs, 1 Output - CVBS, S- Video CVBS,S-video Ext. Video Signal In MST9886 In Ext. Video Signal In MST9886 In Pin 143 Video(AV) Pin 144 Pin 60 (VCR) Pin 1 VCTI S-Video...
Page 55 M ain board part M ain board part 3. gm1501H - GENESIS Scaler IC - Micro- processor Inside - Supporting RxTx - Supporting OSD and PIP DNI-Pro In DNI-Pro In Pin AE8~AE10 R (8bit) Pin AF10~AF13 Pin B23 ~ C19 R,G,B (8bit) G (8bit) Pin AE13~AE16...
Page 56 M ain board part M ain board part 4. uPD64084 - 10 bit ADC CVBS - 3 input 1 output - 3D- comb filter Inside - Using it to Component 480i, Video1(CVBS), Video2(S- Video) VCTi In VCTi In VCTi Out VCTi Out Pin 93 Pin 88...
Page 57 M ain board part M ain board part 5. MDIN150 - Deinterlacer - Noise reduction & Signal enhancement - Programmable brightness, contrast, tint, saturation, CVBS,S-video - Using it to CVBS and S- Video gm1501H In gm1501H In MST9886 Out MST9886 Out Pin 110~114,116~118 R (8bit) Pin 134,136~139,141,142,144...
Page 58 M ain board part M ain board part 6. DNI- pro - Digital Natural Image Engine - Noise reduction - Detail enhancement - Contrast enhancement, black and white stretch gm1501H Out gm1501H Out LVDS In LVDS In Pin W12~V14 Pin B13~C11 R (0:7) R (8bit) Pin W7~V9...
Page 59 M ain board part M ain board part 7. MSP (Inside VCTI) - Global version (All sound standard) - BBE , Virtual Dolby Sound,Mute - Amplifier : TA2024 PC,DVI AV,S-video Line-out Component gm1501H Out gm1501H Out TPA3002 In TPA3002 In Pin 6,23 PC sound R/L Pin 9,20...
Page 60 Service M ode Service M ode Entering Main Board Factory Menu Power OFF -> Mute -> 1 -> 8 -> 2 -> Power ON   Using Factory Remote: Info + Factory...
Page 61 Function board part Function board part Connecting Function Board Connect to Main B’d Connect to CN200 on Connect to CN200 on Main Board Main Board Funct i on Connect or (Connect to Main Board) Attached to Front...
Page 62 Service M ode Service M ode 1. How t o Ent er Ser vi ce Mode us i ng REMOCON Adjust AutoColor of PC and Component ( 1) Power Of f + MUTE + 1+ 8 + 2 + Power On Adjust DDP register in VCTI ( 2) I NFO +...
Page 63 DDP (Display and Deflection Processor) DDP (Display and Deflection Processor) Service Menu DDP Part CUTOFF MST9886 WHITE DRIVE White Balance BLUE STRETCH AutoColor Panel Info AV Size PEAKING Spread Spectrum Adjust Misc Reset LUMAMIX Option MATRIX Checksum Non-linear Color space Enhancer (NCE) M-CK_II40WW-0860 04.10.14 : Controls the gamma of AV, S-video source.
Page 64 DDP (Display and Deflection Processor) DDP (Display and Deflection Processor) Service Menu DDP Part BLE MODE 0:no 1:auto 2:dyna 3:static MST9886 CUTOFF BLE GAIN WHITE DRIVE White Balance BLE TILT BLUE STRETCH AutoColor STATIC BLE Panel Info AV Size PEAKING Spread Spectrum Adjust Misc Reset...
Page 65 DDP (Display and Deflection Processor) DDP (Display and Deflection Processor) Service Menu DDP Part R CUTOFF B CUTOFF G CUTOFF MST9886 CUTOFF White Balance WHITE DRIVE AutoColor R DRIVE BLUE STRETCH Panel Info B DRIVE AV Size G DRIVE PEAKING Spread Spectrum Adjust Misc Reset...
Page 66 DDP (Display and Deflection Processor) DDP (Display and Deflection Processor) Service Menu DDP Part LTI CORING LTI GAIN CUTOFF MST9886 WHITE DRIVE White Balance CTI CORING BLUE STRETCH AutoColor CTI GAIN Panel Info AV Size PEAKING Spread Spectrum Adjust Misc Reset LUMAMIX MATRIX...
Page 67 DDP (Display and Deflection Processor) DDP (Display and Deflection Processor) Service Menu DDP Part MST9886 CUTOFF White Balance WHITE DRIVE AutoColor BLUE STRETCH Pos Peak Panel Info Neg Peak AV Size Peak Coring PEAKING Spread Spectrum Adjust Misc Reset LUMAMIX Option MATRIX Checksum...
Page 68 DDP (Display and Deflection Processor) DDP (Display and Deflection Processor) Service Menu DDP Part MST9886 CUTOFF Brightness White Balance WHITE DRIVE Contrast AutoColor BLUE STRETCH Saturation Panel Info Tint AV Size Int Brightness Spread Spectrum PEAKING Reset Adjust Misc LUMAMIX Option MATRIX Checksum...
Page 69 DDP (Display and Deflection Processor) DDP (Display and Deflection Processor) Service Menu DDP Part MST9886 CUTOFF White Balance WHITE DRIVE AutoColor BLUE STRETCH LMIXGAIN 4 Panel Info LMIXOFS AV Size Spread Spectrum PEAKING Reset Adjust Misc LUMAMIX Option MATRIX Checksum M-CK_II40WW-0860 04.10.14 Mixing Coefficient Gain, Offset Control (AV,S-Video)
Page 70 DDP (Display and Deflection Processor) DDP (Display and Deflection Processor) Service Menu DDP Part MST9886 CUTOFF MR1M White Balance WHITE DRIVE MR2M AutoColor BLUE STRETCH MG1M Panel Info MG2M AV Size MB1M Spread Spectrum PEAKING MB2M Reset Adjust Misc LUMAMIX Option MATRIX Checksum...
Page 71 VSP (Video Processor) part VSP (Video Processor) part Service Menu Brightness Contrast Cb Saturation Cr Saturation Tint MST9886 Ckill White Balance Ckills AutoColor YC del Panel Info AV Size Spread Spectrum Reset Option Checksum YCrCb Control Adjust contrast,brightness,color saturation, and tint of RGB M-CK_II40WW-0860 04.10.14 –...
Page 72 MSP(Multistandard Sound Processor) MSP(Multistandard Sound Processor) Service Menu Source Prescaling FM_AM_Presc MST9886 NICAM_Presc SCART_Presc White Balance AutoColor Panel Info AV Size Spread Spectrum Reset Option Checksum FM, NICAM, SCART Control M-CK_II40WW-0860 04.10.14...
Page 73 MST9886 part MST9886 part Used for color control. But excessive setting may saturate the color. Ext r em e caut i on needed. ! ! Service Menu Ext r em e caut i on needed. ! ! MST9886 Gain/Offset MST9886 White Balance RED Gain AutoColor...
Page 74 W hite Balance W hite Balance Used for color control. But excessive setting may saturate the color. Ext r em e caut i on needed. ! ! Service Menu Ext r em e caut i on needed. ! ! White Bal [DNIe] Gain/Offset MST9886 White Balance RED Gain...
Page 75 Auto Color Auto Color PC analog Only ( 1360x768@60 16 gray pattern) Service Menu Color control operates normally only in certain modes of certain patterns, but in other cases, the operation may distort color. Also, color control is not normal when MST9886 controlling color in a mode other than White Balance...
Page 76 Panel Info/Reset/Auto adj. Panel Info/Reset/Auto adj. Time Reset : Push the Service Menu Menu button on the front for five seconds Panel Information Total Hr: Time Ch.No MST9886 White Balance AutoColor Factory Reset Panel Info (Turn the Power off and on after AV Size Reset.) Spread Spectrum...
Page 77 Option/Checksum Option/Checksum Service Menu Only AV Size / Position H Size MST9886 V Size H Position 0 White Balance V Position 0 AutoColor Panel Info AV Size Spread Spectrum Reset Adjust AV size and position. Option H,V size / H,V Position Checksum M-CK_II40WW-0860 04.10.14...
Page 78: Factory Reset
Option/Checksum Option/Checksum Spread Spectrum Service Menu Spread sp 0:Disable 1:Enable Amplitude Period MST9886 White Balance Adjust Spread Spectrum AutoColor Check the Spread spectrum Panel Info AV Size Set the Amplitude and Period Spread Spectrum Reset Factory reset Option Checksum M-CK_II40WW-0860 04.10.14...
Page 79 Option/Checksum Option/Checksum Option Baudrate 19200 / 115200 Remocon Enabled / Disabled Service Menu nMFM ON / OFF DNIe Demo ON / OFF Scroll Control  Scroll Period off /1/2/…/10 Scroll Second off/1/2/…/5 MST9886 Adjust Option White Balance AutoColor Set the Baudrate Panel Info Set the Remote Control AV Size...
Page 80 Trouble Shooting Trouble Shooting NO POWER Does proper 12V appear Check Adaptor at Pin No. 9,10,11 CN601 ? (+12.0V_NW) Does proper 12V appear at FT620 ? Check related circuit of CN604 Does proper 5V appear at FT7002 ? Check related circuit of IC609 (+5V_IN) Does proper 3.3V appear at C6339 ? Check related circuit of IC610...
Page 81 Trouble Shooting Trouble Shooting PC (D-SUB) No Screen Check power board. Does proper +5V at FT602? *Refer to 1.no power (previous page) Does proper 5V appear at Pin 5,6,7 Check LED on and 8 of IC5709 ? after pushing the power button. Check cable connection.
Page 82 Trouble Shooting Trouble Shooting PC (Digital) No Screen Check power board. Does proper +5V at FT602? *Refer to 1.no power (previous page) Does proper 5V appear at Pin 5,6,7 Check LED on and 8 of IC5709 ? after pushing the power button. Check cable connection.
Page 83 Trouble Shooting Trouble Shooting BNC No screen Check power board. Does proper +5V at FT602? *Refer to 1.no power (previous page) Does proper 5V appear at Pin 5,6,7 Check LED on and 8 of IC5709 ? after pushing the power button. Check cable connection.
Page 84 Trouble Shooting Trouble Shooting Component No screen Check power board. Does proper +5V at FT602? *Refer to 1.no power (previous page) Does proper 5V appear at Pin 5,6,7 Check LED on and 8 of IC5709 ? after pushing the power button. Does the picture appear at BD100 (Pb), IC104 defect change main board.
Page 85 Trouble Shooting Trouble Shooting AV, S-video No screen Check power board. Does proper +5V at FT602? *Refer to 1.no power (previous page) Does proper 5V appear at Pin 5,6,7 Check LED on and 8 of IC5709 ? after pushing the power button. Does the picture appear at Pin 1, 144,143 CN903 defect change main board.
Page 86 Trouble Shooting Trouble Shooting No Communication using serial port (RS-232C) IC311 defect. Does proper +5V_IN at Pin 16 of IC204? Change main board. Does the picture appear at Pin 9, 11 (TX), IC311 defect. 10,12 (RX) of IC204 ? Change main board. Check RS-232C cable.
Page 87 Trouble Shooting Trouble Shooting PC No Sound – (1) Check cable connection and Does the picture appear at R3014 ,R9414 ? Connector stereo cable. Check power board. Does proper +12V at Pin 9,10,11 CN601? *Refer to 1.no power (previous page) Check LED on Does proper +8V appear at BD301 ? after pushing the power button.
Page 88 Trouble Shooting Trouble Shooting PC No Sound – (1) CN601 BD300 IC501 IC911,910 IC105...
Page 89 Trouble Shooting Trouble Shooting PC No Sound – (2) Does the picture appear at Pin 124 IC302 defect change main board. (LOUD_OUT_L) 123(LOUD_OUT_R) of IC302? Does the picture appear at Pin 15 IC500 defect change main board. (SP_LIN) 11(SP_RIN) of IC500 ? Does the picture appear at Pin 31 IC500 defect change main board.
Page 90 Trouble Shooting Trouble Shooting PC No Sound – (2) IC500 C500 IC501 CN61...
Page 91 Trouble Shooting Trouble Shooting ** PC , BNC Sound Does the picture appear at Pin 6 (PC_AL) IC304 defect change main board. 23 (PC_AR) of IC304 ? ** Component Sound Does the picture appear at Pin 5 IC304 defect change main board. (COM_AL) , 24 (COM_AR) of IC304 ? ** Video, S-video Sound Does the picture...
Page 92 D D C Entry D D C Entry DDC file name: BE32A.DDC / BE32D.DDC You must enter Service Mode to enter DDC: Release DDC Protection 1: Open file 2: Select port 1(D-SUB) / select port 2(DVI) 3: Select DDC file 4: Click Next (OK) button...
Page 93 D D C Entry D D C Entry DDC file name: BE32A.DDC / BE32D.DDC 5: Press Enter after entering the serial number of the monitor After Analog input, repeat 2~5 times for Digital input...
Page 94 Program Upgrading - Program Upgrading - M A IN M A IN Connecting the Parallel port (printer port) of the PC with the D-SUB cable of the Monitor to be upgraded Connect to computer Connect to Monitor to be printer port Upgraded...
Page 95 Program Upgrading - Program Upgrading - M A IN M A IN Malibu Flash Downloader 1.7 File Malibu Flash Downloader 1.7 File After running the Exe. File and pressing “OK”, press “Next” to Install, and installation is complete (see attachment) This can be operated regardless of the W indows OS system.
Page 96 Program Upgrading Program Upgrading - M A IN - M A IN I n t he Fi l e Sel ect m enu, Fl as h Downl oad  Set up as s hown i n pi ct ur e Chi p Model : 1MB s houl d be s et up f i r s t...
Page 97 Program Upgrading Program Upgrading - M A IN - M A IN After installing the program Connect i on  Set up as s hown i n pi ct ur e DDC2Bi 3b LPT1 200000 After installing the program Pi n Conf i gur at i on ...
Page 98 Program Upgrading - Program Upgrading - M A IN M A IN 1MB Fl as h I s p16_1M . Hex  Set t i ng i s done aut om at i cal l y...
Page 99 Program Upgrading - Program Upgrading - M A IN M A IN I n Br ows e, s el ect t he f i l e t o be downl oaded Pr es s 5 t o Downl oad I f Downl oad i s com pl et ed wi t hout er r or s , and downl oad s ucces s m es s age com es up...
Page 100: Main Board
What To D o after B oard Replacement What To D o after B oard Replacement Main Board Check PC color control status  DDC input (Both Analog and Digital input required)  After entering service mode and resetting, turn Hard power off ...
Page 101 32” SM PS B lock D iagram 32” SM PS B lock D iagram...
Page 102 32” SM PS Trouble Shooting 32” SM PS Trouble Shooting NO POWER System R equirements Vin : 90~264V, 47~63HZ...
Page 103 32” SM PS 32” SM PS Schematics (Adapter) Acrobat Document...
Page 104 L CD Theory L CD Theory Understanding the Optical C haracteristics of L C D Understanding the Optical C haracteristics of L C D...
Page 105 When shutter is open, it’s On, when shutter is shut, it’s Off: the role of the shutter is played by liquid crystal.
Page 106 TFT-L C D Operation Principles TFT-L C D Operation Principles Signal V oltage Data Signal L ine Gate (Option) Pixel electrode...
Page 107 Expression Expression GRA TSCA L E(COL OR) GRA TSCA L E(COL OR) # of Color = 2 ( R ) x 2 ( G ) x 2 ( B ) = 2 # of Color = 2 ( ) x 2 ( ) x 2 ( ) = 2 n= # of bit / (RGB)
Page 108 C haracteristics of Polarizer C haracteristics of Polarizer...
Page 109 Characteristics of L C Characteristics of L C Anisotropy of refraction rate ( ≠  Determines the optical characteristics of LCD  ≠ ε Anisotropy of permittivity rate (ε  Enables electrical control of LC ...
Page 110 C hanges in L ight Travel Speed Depending on the M edium C hanges in L ight Travel Speed Depending on the M edium Slow Slow M edium that is n M edium that is n > If design is made If design is made Fast Fast...
Page 111 L C Types (Structure) L C Types (Structure) Smectic  Maintains regularity of molecular  positions toward one direction Nematic  Maintains the order of direction  without regularity of molecular positions cholesteric  Molecular arrangement within a  layer is in the long axis direction The surface of layers have a ...
Page 112 Control of L iquid Crystals Orientation Control of L iquid Crystals Orientation Homogeneous Twisted Grandjean Homeotropic Hybrid Focal-conic...
Page 113 L C M olecular A lignment L C M olecular A lignment Vertical Alignment  Horizontal A lignment ...
Page 114 Panel Structure Panel Structure Cas e Top LCD Panel Di f f us er s & Pr i s m s Li ght Gui de Ref l ect or Lam p Hous i ng Lam p D- I C( on TCP) Suppor Mai n Bot t om Cover...
Page 115 PVA Mode ...
Page 116 PVA Operation Principles PVA Operation Principles PVA : Patterned Vertical Alignment  OFF State (Black) On State (White)
Page 117 PVA Advantages and Disadvantages PVA Advantages and Disadvantages Advantages  W ide view angle  High productivity (no rubbing process)  Strong with Image Sticking  High contrast ratio  Disadvantages  W eak to impact (vertical alignment characteristic)  High unit price LC (new color filter,LC, alignment material) ...
Page 118 Terms Terms Dot Pitch Dot Pitch The image on a monitor is composed of red, green and blue dots. The closer the dots, the higher the resolution. The distance between two dots of the same color is called the 'Dot Pitch'. Unit: mm Vertical Frequency Vertical Frequency The screen must be redrawn several times per second in order to create and display an image for the user.
Page 119 Terms Terms Types of Sync Signals Types of Sync Signals • Separate: This is a scheme of transmitting individual vertical sync signals to the monitor. Separate: This is a scheme of transmitting individual vertical sync signals to the monitor. • Composite: This is a scheme of combining vertical sync signals into one composite signal and transmitting it to the Composite: This is a scheme of combining vertical sync signals into one composite signal and transmitting it to the monitor.
Page 120 Terms Terms This system uses two carriers to transmit voice data. Countries such as South Korea and Germany use this system. This system uses two carriers to transmit voice data. Countries such as South Korea and Germany use this system. BTSC Broadcast Television System Committee BTSC...
Page 121 Terms Terms CATV CATV "CATV" refers to the broadcasting service offered at hotels, schools and other buildings through their own broadcasting "CATV" refers to the broadcasting service offered at hotels, schools and other buildings through their own broadcasting system, apart from VHF or UHF broadcasting by terrestrial broadcasters. The CATV programs may include movies, system, apart from VHF or UHF broadcasting by terrestrial broadcasters.
