Summary of Contents for Samsung SyncMaster 320PX

Page 1 SyncMaster 320PX Model Select Language Safety Instructions Install Programs PDF Manuals Registration Introduction Connections Using the Software Adjusting the LCD Display Troubleshooting Specifications Information Appendix © 2006 Samsung Electronics Co., Ltd. All rights reserved.
Page 2: Safety Instructions
Do not use a damaged or loose plug. This may cause electric shock or fire. Do not pull the plug out by the wire nor touch the plug with wet hands. This may cause electric shock or fire. Select Language Main Page Model SyncMaster 320PX Notational Power...
Page 3 Use only a properly grounded plug and receptacle. An improper ground may cause electric shock or equipment damage. Insert the power plug firmly so that it does not come loose. A bad connection may cause fire. Do not excessively bend the plug and wire nor place heavy objects upon them, which could cause damage.
Page 4 Do not drop the LCD Display when moving it. This may cause damage to the product or the person carrying it. Install the LCD Display base in a showcase or shelf so that the end of the base does not protrude from the showcase or shelf. Dropping the product may cause damage to the product or the person carrying it.
Page 5 The installation of the bracket must be done by a qualified professional. Installing the bracket by unqualified personnel may result in injury. Always use the mounting device specified in the owner's manual. When installing the product, make sure to keep it away from the wall (more than 10 cm / 4 inches) for ventilation purposes.
Page 6 Do not use any chemicals such as wax, benzene, alcohol, thinners, insecticide, air freshener, lubricant or detergent. Contact the SAMSUNG customer care center interior cleaning once a year. Keep the product's interior clean. Dust which has accumulated in the interior over an extended period of time may cause a malfunction or fire.
Page 7 Do not try to move the LCD Display by pulling only the wire or the signal cable. This may cause a breakdown, electric shock or fire due to damage to the cable. Do not move the LCD Display right or left by pulling only the wire or the signal cable.
Page 8 outlet and contact the Service Center. When viewing a fixed screen for an extended period of time, residual image or blurriness may appear. Change the mode to energy saving mode or set a screensaver to a changing picture when away from the LCD Display for an extended period of time.
Page 9 Place the product out of children’s reach, as they could damage by hanging onto it. A falling product may cause injury to the person or even fatality. When not using the product for an extended period of time, keep the product unplugged.
Page 11 Quick Setup Guide Cables Other contact your dealer. to buy optional items. LCD Display Warranty Card (Not available in all locations) D-Sub Cable Power Cord Select Language Main Page Model SyncMaster 320PX Package Contents User's Guide, MDC Software Speaker Wire Cable...
Page 12 Remote Control Batteries (AAA X 2) BNC to RCA Adaptor Jack Sold separately Wall Mount KIT DVI Cable Front MENU Opens the on-screen menu and exits from the menu or closes the adjustment menu. Navigate buttons (Up-Down buttons) Moves from one menu item to another vertically or adjusts selected menu values. Adjust buttons (Left-Right buttons)/ Volume buttons Moves from one menu item to another horizontally or adjusts selected menu values.
Page 13 Adjusts the audio volume. ENTER Activates a highlighted menu item. SOURCE Switches from PC mode to Video mode. Changing the source is only allowed for external devices that are connected to the LCD Display at the time. [PC] → [BNC] → [DVI] → [AV] → [S-Video] → [Component] >>...
Page 14 RS232C OUT/IN (RS232C Serial PORT) MDC(Multiple Display Control) Program Port DVI / PC IN [RGB] (PC Video Connection Terminal) Using a D -Sub Cable (15 pin D -Sub) - PC mode (Analog PC) DVI / PC IN [DVI(HDCP)] (PC Video Connection Terminal) Using a DVI Cable (DVI-D to DVI-D) - DVI mode (Digital PC)
Page 15 Note • The number of LCD Displays that can be connected to loopout may differ depending on the cables, signal source etc. With cables where there is no degradation or signal source, up to ten LCD Displays can be connected. Note •...
Page 16 ON / OFF Turns the LCD Display On/Off. MAGICNET MagicNet Quick Launch Button. - This fuction does not work for this monitor. MDC Quick Launch Button. LOCK Activates or deactivates all function keys on both the remote control and the LCD Display except for the Power and LOCK buttons.
Page 17 TV channels provide text information services via teletext. - This fuction does not work for this m onitor. MENU Opens the on-screen menu and exits from the menu screen or closes the screen adjustment menu. ENTER Activates a highlighted menu item. P.MODE When you press this button, current picture mode is displayed on the lower center of the screen.
Page 18 The image in the PIP window will appear on the main screen, and the main screen image will appear in the PIP window. SIZE Switches the PIP Picture Size. Rewind STOP Stop PLAY / PAUSE Play/Pause Fast forward Default Manual Change Mono © 1995~2007 SAMSUNG. ALL Rights Reserved...
Page 19: Mechanical Layout
Mechanical Layout Monitor Head Stand Speaker Installation VESA Bracket Wall Bracket Installation 1. Mechanical Layout 2. Monitor Head...
Page 20: Installation Vesa Bracket
After your order is placed, installation professionals will visit you and install the bracket. At least 2 persons are needed in order to move the LCD Monitor. Samsung is not responsible for any product damage or any injury caused by installation at customer's discretion. Dimensions...
Page 21: Wall Bracket Installation
6. Wall Bracket Installation Contact a technician for installing the wall bracket. Samsung Electronics is not responsible for any damages to the product or harm to customers when the installation is done by the customer. This product is for installing on cement walls. The product may not stay in place when installed on plaster or wood.
Page 22 1. Insert three Hangers of the set-bracket B into the grooves of the wall-bracket A. 2. Fix set-bracket B and wall-bracket A with screws D. Before installing the set on the wall, connect the cables to the set first.
Page 23 Note • Only the supplied bolts should be used. Caution Samsung Electronics will not be responsible for damages caused by using a base other than those specified. Installing the Semi Stand A 'Cover-Protector' is used to protect the hole at the bottom of the LCD Display , where the stand is inserted.
Page 24 This stand is designed for adjusting the screen angle. The company is not responsible for any problem caused when using this stand. Under no circumstances use the product as a stand for placing something on. Installing the Stand KIT (sold separately) A 'Cover-Protector' is used to protect the hole at the bottom of the LCD Display , where the stand is inserted.
Page 25 Connect the audio cable for your LCD Display to the audio port on the back of your computer. Note • Turn on both your computer and the LCD Display. Note • The DVI cable or BNC cable is optional. Contact a local Samsung Electronics Service Center to buy optional items.
Page 26 Connecting Digital DVD Note • Input devices such as digital DVD are connected to the DVI IN terminal of the monitor using the DVI cable. • Then, start the DVD with a DVD disc inserted. • Select Digital using the SOURCE button. Note •...
Page 27 Connect a set of audio cables between the COMPONENT AUDIO IN [L-AUDIO-R] on the LCD Display and the AUDIO OUT jacks on the DVD player. Connect a Component cable between the BNC/COMPONENT IN - P the P , Y, P jacks on the DVD player.
Page 28 • The audio-video cables shown here are usually included with a Camcorder. (If not, check your local electronics store.) If your camcorder is stereo, you need to connect a set of two cables. Connecting to a DTV Set Top Box Note •...
Page 29 The speaker-bracket for connecting the SET speaker my become damaged. Connecting to an Audio System Note • Connect a set of audio cables between the AUX L, R jacks on the AUDIO SYSTEM and the AUDIO OUT [L-AUDIO-R] on LCD Display. © 1995~2007 SAMSUNG. ALL Rights Reserved...
Page 30: Main Screen
Therefore, a serial cable should be connected between the serial port on a PC and the serial port on a display. Main Screen Click Start > Program > Samsung > MDC System to start the program. Select a set to see the volume of the selected set within the slider.
Page 31: Port Selection
Main Icons Remocon Safety Lock Port Selection 1. Use the main icons to switch into each screen. 2. Allows you to enable or disable the remote control signal receiving function of the display unit. 3. Set the Safety Lock function. When setting the Lock function, you can only operate power and lock buttons on the remote control and set.
Page 32: Power Control
1. The Multiple Display Control is originally set to COM1. 2. If any port other than COM1 is used, COM1 through COM4 can be selected in the Port Selection Menu. 3. If the exact port name that is connected to the LCD Display using a serial cable is not selected, communication will be unavailable.
Page 33 Info Grid shows some basic information necessary to Power Control. (Power Status) 2) Input 3) Image Size 4) On Timer 5) Off Timer 2. Use the Select All button or Check Box to choose a display to control. Power Control allows controlling some of the functions of the selected display. 1) Power On/Off...
Page 34: Input Source
- Turns the power of the selected display On/Off. 2) Volume - Controls the volume level of the selected display. It receives the volume value of the selected display from the sets and displays it in the slider. (When you cancel the selection or choose Select All, the value returns to the default value 10) (Mute On/Off) - Turns on/off the Mute function of the selected display.
Page 35: Image Size
Info Grid shows some basic information necessary to Input Source Control. 1) PC - Changes the Input Source of the selected display to PC. 2) BNC - Changes the Input Source of the selected display to BNC. 3) DVI - Changes the Input Source of the selected display to DVI. 4) TV - Changes the Input Source of the selected display to TV.
Page 36 Info Grid shows some basic information necessary to Image Size Control. ( Power Status) - Shows the power status of the current display. 2) Image Size - Shows the current Image Size of the display in use. 3) Input - Shows the current Input Source of the display in use. 4) Info Grid displays only the displays whose Input Source is PC, BNC, DVI.
Page 37 Info Grid shows some basic information necessary to Image Size Control. 1) Click the Video Source tab to adjust Image Size for TV, AV, S-Video, Component. , DVI(HDCP). Click Select All or use Check Box to select a display to control. 2) Info Grid displays only the display having TV, AV, S-Video, Component or DVI(HDCP) as input source.
Page 38: Pip Size
Info Grid shows some basic information necessary to Time Control. 1) Current Time - Set the current time for the selected display (PC Time). - To change the current time, first change the PC Time. 2) On Time Setup - Set the Hour, Minute, AM/PM of On Time Setup, Status, Source, Volume of the selected display. 3) Off Time Setup - Set the Hour, Minute, and AM/PM, Status for Off Time Setup of the selected display.
Page 39: Pip Source
Info Grid shows some basic information necessary to PIP Size Control. 1) PIP Size - Shows the current PIP Size of the display in use. 2) OFF - Turns off the PIP of the selected display. 3) Large - Turns on the PIP of the selected display and changes the size to Large. 4) Small - Turns on the PIP of the selected display and changes the size to Small.
Page 40 • PIP S-Video Mode Info Grid shows some basic information necessary to PIP Source Control. 1) PIP Source - PIP Source can be controlled with turning on the LCD Display power. 2) PC - Changes the source of the PIP of the selected display to PC. 3) BNC - Changes the source of the PIP of the selected display to BNC.
Page 41 6) AV - Changes the source of the PIP of the selected display to AV. 7) S-Video - Changes the source of the PIP of the selected display to S-Video. 8) Component - Changes the source of the PIP of the selected display to Component. 9) Channel - Channel arrow appears when the PIP Source is TV.
Page 42: Picture Pc
- Adjusts Tint of the selected display. - Available only for NT. 7) Color Tone - Adjusts the Color Tone for the selected display. The Input source of MagicNet works only on MagicNet model. The Input source of TV works only on TV model. This feature is available only for the displays whose power status is ON and if no selection is made, the factory default is displayed.
Page 43: Image Lock
This feature is available only for the displays whose power status is ON and if no selection is made, the factory default is displayed. Settings Audio 1. Click Settings of the main icons and the Settings Control screen appears. Info Grid shows some basic information necessary to Settings Control. When each function is selected, the set value of the selected function is displayed in the slide.
Page 44: Maintenance
1. Click Settings of the main icons and the Settings Control screen appears. Info Grid shows some basic information necessary to Settings Control. 1) Image Lock - Available only for PC, BNC. 2) Coarse - Adjusts Coarse of the selected display. 3) Fine - Adjusts Fine of the selected display.
Page 45 An "Info Grid" showing several basic data items appears. 1) Maintenance - Allows the Maintenance Control function for all input sources. 2) Auto Lamp Control - Automatically adjusts the backlight of the selected display at a specified time. The Manual Lamp Control automatically turns off if you adjust using the Auto Lamp Control. 3) Manual Lamp Control - Allows you to adjust the backlight of the selected display regardless of the time.
Page 46: Video Wall
1) Safety Screen - Eliminates the afterimages that can result when the selected display stays in Pause mode for an extended period of time. You can set the repeat cycle timer by selecting the "Interval" by hour and "Second" by second. It can be set to Scroll, Pixel, Bar and Eraser by Screen Type.
Page 47 You can select a number of screens with a different layout when dividing. Select a mode from Screen divider. Select a display from Display Selection. The place will be set up by pressing a number in the selected mode. The MDC program supplied by Samsung supports over 4*4. 3) On / Off...
Page 48: Troubleshooting
- Turns on/off the Video Wall function of the selected display. 4) Format - The format can be selected to see a divided screen. Full Natural You may not operate this function in MagicNet. The Input source of TV works only on TV model. The Maintenance Control function is available only for the displays where the power status is ON.
Page 49 4. Selected all sets using Select All: Returns to the Factory Default Value.
Page 50 4) AV 5) S-Video 6) Component [The direct button on the remote control is the 'SOURCE' button.] Note • PIP turns off when the LCD Display is switched to an external source. Select Language Main Page Model SyncMaster 320PX Input...
Page 51 When external A/V devices such as VCRs or DVDs are connected to the LCD Display , PIP allows you to watch video from those devices in a small window super-imposed on the PC Video signal. (Off/On) Note • More than one PIP cannot be overlapped on screen as BNC and the component use the same terminal. 1) PIP [ME NU] →...
Page 52 5) S-Video 6) Component Available Modes PC / BNC / DVI S-Video Component DVI -Video MagicBright™ [ME NU] → [ ∧ / ∨ ] → [ENTER] → [ENTER] → [ ∧ / ∨ ] → [ENTER] MagicBright™ is a new feature providing the optimum viewing environment depending on the contents of the image you are watching.
Page 53 1) Contrast Adjusts the Contrast. 2) Brightness Adjusts the Brightness. Note • By adjusting the picture using the Custom function, MagicBright will change to Custom mode. Color Tone [ME NU] → [ ∧ / ∨ ] → [ENTER] → [ ∧ / ∨ ] → [ENTER] → [ ∧ / ∨ ] → [ENTER] The color tones can be changed.
Page 54 [ME NU] → [ ∧ / ∨ ] → [ENTER] → [ ∧ / ∨ ] → [ENTER] The values of Fine, Coarse, Position are adjusted automatically. By changing the resolution in the control panel, the auto function is performed. (Available in PC, BNC mode only) [The direct button on the remote control is the 'AUTO' button.] Signal Balance...
Page 55 Available Modes PC / BNC / DVI S-Video Component DVI -Video Mode [ME NU] → [ ∧ / ∨ ] → [ENTER] → [ENTER] → [ ∧ / ∨ ] → [ENTER] The LCD Display has four automatic picture settings ("Dynamic", "Standard", "Movie" and "Custom") that are preset at the factory.
Page 56 The color tones can be changed. The individual Color components are also user adjustable. 1) Cool 2 2) Cool 1 3) Normal 4) Warm1 5) Warm2 Size [ME NU] → [ ∧ / ∨ ] → [ENTER] → [ ∧ / ∨ ] → [ENTER] → [ ∧ / ∨ ] → [ENTER] The Size can be switched.
Page 57 Available Modes PC / BNC / DVI S-Video Component DVI -Video Mode [ME NU] → [ ∧ / ∨ ] → [ENTER] → [ENTER] → [ ∧ / ∨ ] → [ENTER] The LCD Display has a built-in high fidelity stereo amplifier. 1) Standard Selects Standard for the standard factory settings.
Page 58 [ME NU] → [ ∧ / ∨ ] → [ENTER] → [ ∧ / ∨ ] → [ENTER] → [ ∧ / ∨ ] → [ENTER] Reduces the difference in volume control between broadcasters. 1) Off 2) On SRS TSXT [ME NU] →...
Page 59 [ME NU] → [ ∧ / ∨ ] → [ENTER] → [ENTER] → [ ∧ / ∨ ] → [ENTER] You can choose from 11 languages. Note • The language chosen affects only the language of the OSD. It has no effect on any software running on the computer. Time Selects from one of 4 time settings, Clock Set, Sleep Timer, On Timer, and Off Timer.
Page 60 The picture parameters are replaced with the factory default values. 1) On 2) Off Video Wall A Video Wall is a set of video screens connected together, so that each screen shows a part of the whole picture or where the same picture is repeated on each screen. When the Video Wall is on, you can adjust the Video Wall screen setting.
Page 61 1~10 Hour 3) Second [ME NU] → [ ∧ / ∨ ] → [ENTER] → [ ∧ / ∨ ] → [ENTER] → [ ∧ / ∨ ] → [ENTER] → [ ∧ / ∨ ] → [ENTER] Determines the time period to run the Screen Scroll operation. (1~5 Second) By default, the time is set to 5 seconds.
Page 62 Available Modes PC / BNC / DVI S-Video Component DVI -Video Multi Control Assigns an individual ID to the SET. 1) ID Setup [ME NU] → [ ∧ / ∨ ] → [ENTER] → [ ∧ / ∨ ] → [ENTER] → [ENTER] → [0~9] Assigns distinctive IDs to the SET.
Page 63 The preset password on the LCD Display is "0000". Note • Resetting the password for the function key lock. Press INFO → EXIT → MUTE. The password will be reset to '0000'. resetting the password. The remote control is required for © 1995~2007 SAMSUNG. ALL Rights Reserved...
Page 64 85Hz, you will see the black screen because the LCD Display does not support over 85Hz. Note • Refer to Display. Specifications > Preset Timing Modes for the resolutions or frequencies supported by the LCD Select Language Main Page Model SyncMaster 320PX Self-Test Feature Check...
Page 65 Do not use benzene, thinner or other flammable substances, or a wet cloth. • We recommend that a Samsung cleansing agent is used to prevent damage to the screen. Maintaining the Flat Panel Display Screen. Clean with a soft cloth (cotton flannel) smoothly.
Page 66 Problems related to the Screen Note • Problems related to the LCD Display screen and their solutions are listed. Problems The screen is blank and the power indicator is off. "Check Signal Cable" message. "Not Optimum Mode " message. The picture rolls vertically. The image is not clear;...
Page 67 Windows ME/2000: Set the resolution at the Control Panel → Display → Screen Saver. Set the function in the BIOS -SETUP of the computer. (Refer to the Windows / Computer Manual). © 1995~2007 SAMSUNG. ALL Rights Reserved Q & A...
Page 68: Specifications
Environmental considerations Operating Storage Audio Characteristics Audio Input 1 Select Language SyncMaster 320PX 32 " Diagonal (80 cm) 697.6845 mm (H) x 392.256 mm (V) 0.51075 mm (H) x 0.51075 mm (V) 30 ~ 81 kHz 56 ~ 75 Hz 16.7 M Colors...
Page 69 Green, Blinking Amber Less than 1 W Less than 1 W (Off-mode) (Power button) ® compliant and ENERGY2000 ® Partner, SAMSUNG has determined that this ® guidelines for energy efficiency. Preset Timing Modes Vertical Pixel Clock Frequency (MHz) (Hz) 66.667 30.240...
Page 70 Vertical Frequency or Refresh Rate. Unit: Hz 70.087 28.322 75.000 31.500 72.809 31.500 85.008 36.000 56.250 36.000 60.317 40.000 72.188 50.000 75.000 49.500 85.000 56.250 60.004 65.000 70.069 75.000 75.029 78.750 85.997 94.500 60.000 85.500 © 1995~2007 SAMSUNG. ALL Rights Reserved...
Page 71 To prevent this, the accumulated voltage difference must be decreased. For example, the number of TFT LCD sub pixels contained in this product are 3,133,440. PRODUCT INFORMATION (Image Retention Free) Select Language Main Page Model SyncMaster 320PX For Better Display...
Page 72 Power Off, Screen Saver, or Power Save Mode Turn the power off for 4 hours after 20 hours in use Turn the power off for 2 hours after 12 hours in use Set the Monitor to power off with the PC Display Properties Power Scheme. Use a Screen saver if possible - Screen saver in one color or a moving image is recommended.
Page 73 Every 30 minutes, change the characters with movement. All area display Moving image together with Logo periodically. - Cycle: Display moving image together with Logo for 60 seconds after 4 hours in use. The best way to protect your monitor from Image retention is to turn Power off, or set your PC, or System to operate a Screen Saver program when you are not using it.
Page 74 . Time Interval : 1 ~ 10 hours ( Recommend : 1 ) . Time Period : 10 ~ 50 second ( Recommend : 50 ) Note • ( Please check CD's User Guide at "OSD Function", some model's will not available ) © 1995~2007 SAMSUNG. ALL Rights Reserved...
Page 75 Information Appendix Appendix Contact SAMSUNG WORLDWIDE Terms Correct Disposal Authority Note • If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. U.S.A CANADA MEXICO ARGENTINE BRAZIL CHILE COLOMBIA COSTA RICA...
Page 76 09 693 79 554 FRANCE 08 25 3260 (€ 0,15/min) GERMANY 01805-121213 ( € 0,14/Min) HUNGARY 06-80-SAMSUNG (7267864) ITALIA 800 SAMSUNG (7267864) LUXEMBURG 02 261 03 710 NETHERLANDS 0900 20 200 88 (€ 0,10/Min) NORWAY 231 627 22 POLAND 0 801 801 881...
Page 77 Middle East & Africa SOUTH AFRICA 0860 7267864 (SAMSUNG) 800SAMSUNG (7267864) U.A.E 8000-4726 Sync Signal Sync (Synchronized) Signals refer to the standard signals that are required to display desired colors on the LCD Display. They are divided into Vertical and Horizontal Sync Signals. These signals display normal color images by the set resolution and frequency.
Page 78 Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
