FEATURES
FRONT/REAR DIFFERENTIAL BEVEL GEAR
SINGLE SPPED TRANSMISSION AND
4WD SYSTEM
POWERFUL 540 MOTOR
OIL-FILLED SHOCK ABSORBER
ESC WITH ALUMINUM HEAT SINK
ITEM NO.:102470
FEATURES
OIL-FILLED SHOCK ABSORBER
POWERFUL 540 MOTOR
DUST-PROOF C-HUB
FORD 1968 MUSTANG LISENCED CAR BODY
HARD RUBBER SLICK DRIFT TIRE
REALISTIC LIGHT SYSTEM (HEAD.TAIL.
TURNING.BRAKE LIGHT INCLUDED)
WWW.SMARTECHRACING.COM
SMARTECH MODEL
1:10 SCALE 4WD ELETRIC-POWERED
ON-ROAD CAR
ITEM NO.:102430
TECHNICAL DATA
Length
Width
Height
Wheelbase
Tread(F/R)
Wheel Diameter
Gear Rate
Weight
Motor
Our company reserve the right to change
or modify this manual without notice.
385mm
190mm
150mm
260mm
194mm
66*26mm
6.89:1
1.34Kg
RC540
Advertisement
Table of Contents
Related Manuals for Smartech 102430
Summary of Contents for Smartech 102430
- Page 1 SMARTECH MODEL 1:10 SCALE 4WD ELETRIC-POWERED ON-ROAD CAR ITEM NO.:102430 FEATURES FRONT/REAR DIFFERENTIAL BEVEL GEAR SINGLE SPPED TRANSMISSION AND 4WD SYSTEM POWERFUL 540 MOTOR OIL-FILLED SHOCK ABSORBER ESC WITH ALUMINUM HEAT SINK ITEM NO.:102470 TECHNICAL DATA Length 385mm Width 190mm...
- Page 2 NOTICE BEFORE ASSEMBLY The following tools which apart from the kits we provide are required for the vehicle .You must purchase from local hobby shop. Additional tools needed to buy Tools needed for assembly Inner hex screw driver 1.5mm Inner hex screw driver 2.0mm Inner hex screw driver 2.5mm Electronic speed...
-
Page 3: Safety Precaution
MAINTENANCE GUIDE PROBLEMS REASON SOLUTIONS The battery dry off. Replace the battey or recharge. The motor wire breaks off or the motor is broken. Replace the motor or weld the wire. The switch doesn’t open or the Voltmeter is broken. Turn the receiver switch on or replace Voltmeter. -
Page 4: Front Gear Case Assembly
102430 Front and Rear Diff. Assembly 103480(E2.3) 103079 103100 103480(E2.3) (TPF2*8) 103079 103042 103080 103042 103080 103080 103100 103080 103082 102470 Front and Rear Diff. Assembly ISO2x4 103079 103042 103042 103079 102019 103079 E-clip φ2.3 Diff. bevel gear axle Washer φ16 xφ10 x0.5 Diff. -
Page 5: Rear Gear Case Assembly
Rear Gear Case Assembly (1) 240053 240053(E2.3) 240053 103041 103041 103078 103104 102020 103104 TPF3x30 E-clipφ2.3 TPF3x30 Rear Gear Case Assembly (2) 240052 240052 102021 240052(E4.0) (TPF3x6) 102023(M4x3) 102023 Inner hex headless screw M4x3 E-clipφ4 TPF3x6 Wheel position pinφ2.0x9... - Page 6 Front and Rear Shock Absorber Assembly 102022 102022 102022 102022 (P3) （E2.3） 102022 102022 102022 （E2.3） 102022 102022 Fill with 80% shock absorber oil Six Gear E-clip φ2.5 Postons O Ring clip O Ring P3 Washer...
- Page 7 Front Section part Assembly (1) 104039 104056 104026 104047 103442 240076 103041 102024 (ISO3*12) 102024 104056 104026 ISO3x12 Ball head cover Wheel position pin Inner hex headless M3x10 M5 Ball end head screw Front Section Part Assembly (2) 102025(E2.3) 102026 102025 104027 104027(TT3*18)
-
Page 8: Shock Absorber Assembly
Shock Absorber Assembly 104027 102022 M3 Ball end head Screw TM3x18 Bumper Section Assembly (1) 102001 102004 102002 102004 104058 104058 10mm 102001 102002 102001(Eφ7) E-clipφ7 M3 Ball head screw short special ball head... - Page 9 Bumper Section and Chassis Assembly (2) ISO3x12 ISO3x12 Front Bumper Unit Assembly (3) 104046 104046 104046 104046 104046 104045 104045(TT3*15) TT3x15...
- Page 10 Front Section and Chassis Assembly (4) TPF3x10 TPF3x10 TPF3x12 TPF3x10 TPF3x18 TPF3x12 TPF3x18 Rear Gear Box and Chassis Assembly 102006 TFP3x12 TFP3x12...
- Page 11 Rear Section Assembly (1) 240076 102007 103041 103042 104037 243021 102008 (ISO3*12) 102008 243021 10mm Ｗｈｅｅｌ ｐｏｓｉｔｉｏｎ ｐｉｎ 102008 (TT3*25) ＩＳＯ３ｘ１２ ＴＭ３ｘ２５ Rear Section Assembly (2) 102011 102011 TPF3x18 102011（TPF3*18） Rear Lower Susp. arm pin...
- Page 12 Rear Section Assembly （３） 104043 104043(TM3*12) 104028 102009(TM3*12) 102009(TT3*10) 104028 (TM3*18) 104028(TT3*10) TM3*12 TT3*10 TM3*18 Shock Absorber Assembly 102022 104028 (TM3*18) 102022 M3 Ball head screw TM3 x18...
- Page 13 Front and Rear Gear Mount Assembly 102012 (TT3*10) 102013 102012 (TT3*10) 102013 TT3 x10 Servo System and Chassis Assembly Servo System Assembly 240069 240069 240042 (TPB2.6*6) 240042 (TM3*10) 240074 TPF3x10 TM3x10 M3 Lock nut TPF3*10 Short special ball head screw...
-
Page 14: Motor Assembly
Motor Assembly 102014 240075 M3 Lock nut M3x30 102014(M3) Battery Holder Assembly 102005 (M3*12) 102005 102028 (M3*12) 240050 (PB2*10) 240050... - Page 15 Tire and Car body Assembly 104052 Tire for 102430 The car body for 102470 247001 M3 Lock nut M3x30...
- Page 16 102430/102470 PART LIST (1) 102001-Bumper Unit 102002-Bumper 102003-Linker 104058-Front Steering Tie Rods M3*5 X1 ISO3*12 X1 ISO3*12 X1 ISO3*12 X2 102004-M3 Ball End Screw 104046-Front Bumper/Collar 104045-Front Bumper 240069-Rim Spaler M3*5 X1 TPF3*10 X2 M3 Lock NutX1 TT3*15 X2 TPF3*18 X1 TPB2.6*6 X1...
- Page 17 102430/102470 PART LIST (2) 103079-Female Gear 103080-Diff. Pinion Gear (L) 103081-Transmission Bevel 103082-Diff. Pinion Gear (S) Gear Washer x4 103100-Diff. Gear Box 103078-Diff. Gear Box Unit 102019-Transmission Outdrive 102020-Directaxis Diff. Gear 103104-Rear Gear Box 103105-Front Gear Box (F&R) 240053-Driving Gear 102021-Decelerate Gear (F&R)
- Page 18 102430/102470 PART LIST(3) 104044-Adjustor A/B/C 247001-Tie Unit (For 102470) 104052-Tie Unit (For 102430) 104051-Tie/ Rim 103041-Bearingφ10*φ5*4 103042-Bearingφ15*φ10*4 102028-Bearing Cover 401270-Hot sink (copper) (copper) PB2*10 X2 103075-Bearingφ10*φ5*4 103076-Bearingφ15*φ10*4 101106-Car Body(For102430) 112800-Wheel Hub (metal) M4 Nut 243022-Sticker(For 102430) 302480-Car Body(For102470) 247009-Sticker(For102470) 243023-Instruction Manual...
- Page 19 102430/102470 Explosive Chart 104043 103078 240074 240042 240069 103104 103078 140027 240052 240053 103104 102026 102025 102021 240053 240052 103078 240052 102023 103078 102027 104044 102028 103078 102023 103105 103078 102013 103081 103081 140028 104037 103105 102005 103078 102006 103042...
