WoodFast HB350A Instruction Manual

Sawmill
Hide thumbs Also See for HB350A:

Advertisement

Quick Links

SAWMILL
HB350A
Instruction
Manual
IMPORTANT
For your safety, read
instructions carefully
before assembling or
using this product.
Save this manual for
future reference.
Original Instruction
V. 1-201809

Advertisement

loading
Need help?

Need help?

Do you have a question about the HB350A and is the answer not in the manual?

Questions and answers

Summary of Contents for WoodFast HB350A

  • Page 1 Instruction Manual SAWMILL HB350A IMPORTANT For your safety, read instructions carefully before assembling or using this product. Save this manual for Original Instruction future reference. V. 1-201809...
  • Page 2: Table Of Contents

    INDEX GENERAL INFORMATION FOREWORD MACHINE IDENTIFICATION CUSTOMER SERVICE RECOMMENDATIONS SAFETY PRECAUTIONS SAFETY REGULATIONS RESIDUAL RISKS SAFETY AND INFORMATION SIGNALS SPECIFICATIONS MAIN COMPONENTS TECHNICAL SPECIFICATION ELECTRICAL CONNECTION NOISE LEVEL DUST EXTRACTION INSTALLATION AND OPERATION INSTALLATION ZONE CHARACTERISTICS INSTALL OF LOOSE PARTS-INTRODUCTION MAINTENANCE CHANGING AND SETTING THE BLADE BLADE GUIDING...
  • Page 3: General Information

    1. GENERAL INFORMATION FOREWORD Some information and illustrations in this manual may differ from the machine in your hand, since all the configurations inherent in the machine complete with all the optional are described and illustrated. Therefore, refer only to that information strictly related with the machine configuration you have purchased.
  • Page 4 -The working area around the machine must be kept always clean and clear, in order to have an immediate and easy access to the switchboard. -Never insert materials which are different from those which are prescribed for the machine utilization. -Never process pieces which may be too small or too wide to the machine capacity.
  • Page 5: Safety Regulations

    Accident caused by unqualified electrical element which connect machine and unconventional WARNING installation, manufacturer assumes no responsibility. Accident cause by change machine function or change spare part arbitrarily, manufacturer WARNING assumes no responsibility. Accident caused by operation under missing part or damage condition,manufacturer assumes no WARNING responsibility RESIDUAL RISKS...
  • Page 6: Specifications

    3. SPECIFICATIONS MAIN COMPONENTS 1-Blade tension knob 9-Guide Rail 2-Guide rod 10-Hand wheel 3-Upper door 11-Lock handle 4-Lower door 12-Blade guard 5-Switch 13-Upper wheel 6-Motor 14-Lower wheel 7-Dust port 8-Bracket TECHNICAL SPECIFICATION SPECIFICATION HB350 Motor voltage 230V/50Hz Power 2200W Blade length 3114mm Blade width 19-26mm...
  • Page 7: Electrical Connection

    3.3 ELECTRICAL CONNECTION - Electrical installation should be carried out by competent, qualified personnel. - The mains connection should be made using the terminal box. - Replacement of the power supply cable should only be done by a qualified electrician. To avoid electrocution or fire, any maintenance or repair to electrical system should be done only WARNING by qualified electricians using genuine replacement parts.
  • Page 8: Installation And Operation

    4. INSTALLATION AND OPERATION INSTALLATION ZONE CHARACTERISTICS WARNING It is prohibited to install the machine in explosive environments. The installation zone must be selected evaluating the work space required depending on the dimension of the pieces to be machined,and taking into account that a free space of at least 800 mm must be left around the machine.It is also necessary to check The floor capacity and its surface, so that the machine base is evenly resting on its four supports.A power outlet and a chip-suction system connection shall be closeto the selected machine setting and it must be conveniently lighted.
  • Page 9: Maintenance

    4.2.3 INSTALL THE FRAME - Match frame A with mounting holes on frame B. - Connect A to B with eight hexagon screws 1, eight washers 2 and eight washers 3. - Be sure to tighten all bolts and nuts. 5.
  • Page 10: Fix Flange

    5.3 FIX FLANGE - Adjust the installation of fixed flange B so that it is matched with gear connecting rod D without interference. When rotating the handwheel A, vertical support C can slide smoothly on the guide rail, and tighten two hexagon screws on B.
  • Page 11: Trouble Shooting

    6. TROUBLE SHOOTING WARNING - For any information or problem contact your area dealer or our technical service center. The necessary interventions must be carried out by specialised technical personel. - Before carrying out any fault service or maintenance work, please always TRUN OFF THE SWITCH, UNPLUG POWER CABLE, WAIT FOR SAW BLADE TO COME TO STANDSTILL.
