- Page 1 Instruction TABLE SAW Manual TS315B IMPORTANT For your safety, read instructions carefully before assembling or using this product. Save this manual for Original Instruction future reference. V.1-201809...
-
Page 2: Table Of Contents
INDEX GENERAL INFORMATION FOREWORD MACHINE IDENTIFICATION CUSTOMER SERVICE RECOMMENDATIONS SAFETY PRECAUTIONS SAFETY REGULATIONS RESIDUAL RISKS SAFETY AND INFORMATION SIGNALS SPECIFICATIONS MAIN COMPONENTS TECHNICAL SPECIFICATION ELECTRICAL CONNECTION NOISE LEVEL DUST EXTRACTION SAFETY DEVICES INSTALLATION CONTENTS OF PACKAGE LIFTING AND UNLOADING INSTALLATION ZONE CHARACTERISTIC INSTALL OF LOOSE PARTS - INTRODUCTION ADJUSTMENT SCORER ADJUSTMENT... -
Page 3: General Information
1. GENERAL INFORMATION FOREWORD This machine is desinged to make straight and angle cut for wood material, especially for wood board cutting. Some information and illustrations in this manual may difer from the machine in your possession, since all the configurations inherent in the machine complete with all the optionals are described and illustrated. - Page 4 - Before carrying out adjustment, repair or cleaning work, disconnect the machine from the electric power and lock the disconnect switch in its “OFF” position by setting the main switch to stop. - After an initial bedding-in period or many hours of operation, the driving belts may slacken; this causes an increase in the tool stopping time (the stopping time must be less than 10 seconds).
-
Page 5: Residual Risks
- The operating method to be followed in the event of accident or breakdown, the machine should be turned off immediately and unplug from main power and ask for assistance for the authorized people. If a blockage is likely to occur, the workpiece should be move back a little and enable the equipment to be safely unblocked. -
Page 6: Specifications
3. SPECIFICATIONS MAIN COMPONENTS 1 - Right extension table 6 - Feet 10 - Slide 2 - Main table 7 - Sub-slide 11 - Material baffle composition 3 - Blade guard assembly 8 - saw blade deflects handwheel 12 - Sub-slide table(optional) 4 - Blade 9 - Composition 5 - Rear extension table... -
Page 9: Dust Extraction
3.4 NOISE LEVEL No load Load Sound Pressure Level < 80.4dB(A) < 85.7dB(A) Sound Power Level < 98.1dB(A) < 100.7dB(A) Associated uncertainty K=4dB Measurement made in accordance with EN ISO 3746:1995 and EN ISO 11202:1995 The noise levels measured are emission levels and not necessarily the safe working level. Although there is a correlation between the emission levels and the exposure levels, this cannot be used reliably to determine whether or not further precautions are required. -
Page 10: Installation
4. INSTALLATION CAUTION Assembly need to be done by an experienced and trained person. 4.1 CONTENTS OF PACKAGE - The machine is supplied partly assembled. Prior to use, further assembly is required. - When unpacking the machine the following components are included for the initial assembly. - If any parts are missing, do not attempt to assemble the machine;... -
Page 11: Lifting And Unloading
4.2 LIFTING AND UNLOADING WARNING Lifting and handing should only be carried out by skilled personel specially trained to execute this kind of operations. During loading and unloading, avoid knocks to prevent damages to persons and things. Make sure no one is standing under the overhung load and/or within the bridge crane working range during machine lifting and handing. -
Page 12: Install Of Loose Parts - Introduction
Fixing to the floor The machine must be fixed to the floor. -Use bolt/nut A to level the feet to ensure machine is well located. -Put expansion bolts D (not supplied) into ground, use washer/lock washer C and hex nut B to fasten the bolts. Fig.4.3 INSTALL OF LOOSE PARTS - INTRODUCTION A few elements will be disassembled from the machine main structure due to packaging and shipping requirements. - Page 13 4.4.3 INSTALL SQUARE SLIDING TABLE - Put the square sliding table C into the slot of sliding table A.(Deputy C/F not recommended installation) - Put the support rod D into the hole of square sliding table C and the hole on support arm E. - Lock the handle B.
-
Page 14: Adjustment
5.3 RIP FENCE PRECISION ADJUSTMENT Tools Required for Assembly: - 16mm fork wrench - Let B,C,D go through the frame, then fix on A (Don’t fix too tight, there are 2 sets) - Let the sliding table go through A, then align the sliding table to the frame according to E sticker - Position the sliding table towards the saw unit and fix the position. -
Page 15: Operating Procedures
5.3 RIP FENCE PRECISION ADJUSTMENT Tools Required for Assembly: - Straight edge, Angle gauge, Depth gauge - Feeler gauge - Wrench 18mm Fig.5.3.1 - Check the perpudicularity between the rip fence and table with triangle compass and feeler guage. Loosen 4pcs short shaft B, then adjust the guide rail up and down to get best perpudicularity. -
Page 16: Correct Use For This Machine
6.3.2 WORKING WITH RIP FENCE - Lock the sliding table. Put the workpiece against the side surface of rip fence. Push the workpiece forward across blade. - For your safety, please use the plastic push block. - When cutting off a small workpiece, please use the push stick to prevent accident cutting of hands. -
Page 17: Material And Blade
6.6 MATERIAL AND BLADE (JUST FOR REFERENCE) Diameter of Diameter of Diameter of Diameter of Cutting speed Material scoring blade scoring blade scoring blade scoring blade (m/s) D=250mm D=300mm D=350mm D=400mm soft woodpiece rip cutting 60-80 soft woodpiece cross cutting 60-80 hard workpiece rip cutting 60-80... -
Page 18: Maintenance
REPLACE BELT Tools Required for Assembly: - 4mm allen wrench - 6mm allen wrench -Open right side plate with 4mm allen wrench, then rotate the screw rod at A of figure 7.2 with 6mm allen wrench. -When rotating the wrench clockwise, belt becomes loose; when rotating the wrench anticlockwise, belt becomes tight. -
Page 19: Trouble Shooting
8. TROUBLE SHOOTING WARNING - For any information or problem contact your area dealer or our technical service center. The necessary interventions must be carried out by specialised technical personel. - Before carrying out any fault service or maintenance work, please always TRUN OFF THE SWITCH, UNPLUG POWER CABLE, WAIT FOR SAW BLADE TO COME TO STANDSTILL.
