224 Ordering information
￭

LCL filters (+C183+C188 and +G304 or +G427)

LCL filter modules have to be ordered separately.
IGBT supply Frame
unit type size
ACS880-204-...
U = 400 V (Range 380 ... 415 V):
N
0420A-3 1×R8i
0580A-3 1×R8i
0810A-3 1×R8i
1130A-3 2×R8i
1330A-3 2×R8i
1580A-3 2×R8i
2350A-3 3×R8i
3110A-3 4×R8i
4620A-3 6×R8i
U = 500 V (Range 380 ... 500 V):
N
0400A-5 1×R8i
0530A-5 1×R8i
0730A-5 1×R8i
1040A-5 2×R8i
1420A-5 2×R8i
2120A-5 3×R8i
2800A-5 4×R8i
4150A-5 6×R8i
U = 690 V (Range 525 ... 690 V):
N
0310A-7 1×R8i
0370A-7 1×R8i
0540A-7 1×R8i
0720A-7 2×R8i
1050A-7 2×R8i
1570A-7 3×R8i
2070A-7 4×R8i
3080A-7 6×R8i
Type
BLCL-13-5+C183+C188+G304
BLCL-13-5+C183+C188+G304
BLCL-15-5+C183+C188+G304
BLCL-24-5+C183+C188+G427
BLCL-24-5+C183+C188+G427
BLCL-25-5+C183+C188+G427
BLCL-24-5+C183+C188+G427
BLCL-25-5+C183+C188+G427
BLCL-25-5+C183+C188+G427
BLCL-13-5+C183+C188
BLCL-13-5+C183+C188
BLCL-15-5+C183+C188
BLCL-24-5+C183+C188
BLCL-25-5+C183+C188
BLCL-24-5+C183+C188
BLCL-25-5+C183+C188
BLCL-25-5+C183+C188
BLCL-13-7+C183+C188
BLCL-13-7+C183+C188
BLCL-15-7+C183+C188
BLCL-24-7+C183+C188
BLCL-25-7+C183+C188
BLCL-24-7+C183+C188
BLCL-25-7+C183+C188
BLCL-25-7+C183+C188
LCL filter
Qty Ordering code
1 3AUA0000179948
1 3AUA0000179948
1 3AUA0000179949
1 3AUA0000180864
1 3AUA0000180864
1 3AUA0000180865
2 3AUA0000180864
2 3AUA0000180865
3 3AUA0000180865
1 3AUA0000179948
1 3AUA0000179948
1 3AUA0000179949
1 3AUA0000180864
1 3AUA0000180865
2 3AUA0000180864
2 3AUA0000180865
3 3AUA0000180865
1 3AUA0000179951
1 3AUA0000179951
1 3AUA0000179952
1 3AUA0000180866
1 3AUA0000180867
2 3AUA0000180866
2 3AUA0000180867
3 3AUA0000180867
Contents
• +C183: Internal heat-
ing element
• +C188: Direct-on-line
(DOL) cooling
fan
• +G304: 115 V AC 1-
phase fan supply for
BLCL-1x-x
• +G427: 208 V AC 3-
phase fan supply for
BLCL-2x-x
