Photo Transmission Specific Options; Gsm/Phone Specific Options - Interlogix Advisor Advanced ATS 000A Series Installation And Programming Manual

Photo transmission specific options

Additionally to "IP and GSM/GPRS specific options" described on page 168, it is
necessary to set the options below.
9.1.n.4.4 Vid dest port
4 Vid dest port
>9000<
The destination port is used to send the pictures to a host set up in "9.1.n.4.1
Dest name" on page 168.
9.1.n.4.5 Encryption
5 Encryption
>No<
If the Encryption option is set to Yes, the pictures are sent encrypted with AES
algorithm.

GSM/phone specific options

9.1.n.4 Destination
1>Type
Phone
The Destination menu contains the configuration of the reporting receiver.
9.1.n.4.1 Type
1 Type
>Phone<
The Type submenu defines who receives the reports directed to the specified
central station:
• Phone: The report is sent to a specified phone number. Menu "9.1.n.4.2
Phone/User/UG" on page 171 configures this phone number.
• User: The report is sent to a specified user's phone number. This user is
selected via menu "9.1.n.4.2 Phone/User/UG" on page 171.
•
User Group: The report is sent to all users that belong to the user group that
is set via menu "9.1.n.4.2 Phone/User/UG" on page 171.
User and user group reporting require the following:
• Users must have their phone numbers set in "3.1.n.7.1 User phone" on page
87.
• The SMS reporting must be enabled for these users. See "3.1.n.7.2 SMS
reporting" on page 88.
•
At least one of the user groups must allow these users to receive SMS
reports. See "3.2.n.5 User group options" on page 91).
170 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
