as follows:
Temperature: 40° to 100 F (Operating)
-40° to 160° F (Storage)
Humidity: 5% to 90% (no condensation) - Operating
0% to 95% - Storage
Electrical: 117 VAC 410%. 60 Hz, 5 amps
117/234 VAC 10%, 50 Hz, 5 amps
2.2 SHIPPING CRATE
The printer is shipped in a crate approximately 20 inches high, 27
inches deep and 32 inches wide. The crate is made of weatherized, triple-
walled cardboard: When properly strapped, the packing crate and printer is
capable of fork lift operation with a seven-high stacking capability.
Shipped with the printer are the following items:
(1)
(4)
(5)
(6)
If a special interface is used, the interface card is included
with the printer. For certain interfaces such as the RS232, a
special cable is also shipped. Cabling requirements for the
standard parallel interface are defined in Appendix C.
A standard vertical format paper tape providing six line feeds
(one inch) for each vertical tab and 66 line feeds (11 inches)
for each form feed code. This tape is a part of the Vertical
Format Unit. Refer to the Operators Manual for duplicating the
existing tape, or if a different format is desired, for generating
a new tape.
Documentation - All documentation describing that particular
printer is included in a plastic bag under the printer. This doc-
umentation includes a technical manual for the printer and any
Optional interface, and a notice of all approved changes incor-
porated in the printer but not documented in the manual. Please
keep this documentation with the printer at all times so that
accurate information will be available for troubleshooting purposes.
Pin Feed Knobs - These knobs are contained in a small plastic bag
stapled to the guide bar for the pin feed unit.
Print Sample - A sample printout from that particular printer is
included in the upper paper pan.
Unpacking/Repacking and Set-up Instruction Sheet.
Shipped in a separate container is the paper guide and stacker assembly.
Installation instructions for this assembly are included with the assembly and
also in Section 2.3.
2-2
